Table of Contents

1. Introduction................................................................................................................................... 3
2. J1939 Setup ................................................................................................................................. 4
3. OMNEX R170 J1939 Data Frame Structure ................................................................................ 5
4. J1939 Standard Joystick Message Configuration ........................................................................ 7
5. Firmware Upgrade...................................................................................................................... 12
6. R170 Pin Assignments ............................................................................................................... 14
7. Appendix A: Setting Up HyperTerminal...................................................................................... 15
8. Appendix B: BJM Button Menus................................................................................................. 17
9. Appendix C: BJM Position Menus .............................................................................................. 18
Safety Precautions
NOTE: These instructions are intended only for configuring the remote control equipment described here. This is not a complete Op-
erator's Manual. For complete operating instructions, please read the Operator's Manual appropriate for your particular machine.
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
Failure to follow the SAFETY PRECAUTIONS may result in radio equipment failure and serious personal injury.
Installation
PROVIDE A SAFETY CUTOFF SWITCH. If maintenance is required, the radio must be disconnected from power .
USE PROPER WIRING. Loose or frayed wires can cause system failure, intermittent operation, machine damage, etc.
DO NOT INSTALL IN HOT AREAS. This apparatus can be damaged by heat in excess of 158° F (70° C).
Personal Safety
MAKE SURE MACHINERY AND SURROUNDING AREA IS CLEAR BEFORE OPERATING. Do not activate the re-
mote system unless it is safe to do so.
TURN THE RECEIVER POWER OFF BEFORE WORKING ON MACHINERY. Always disconnect the remote system
before doing any maintenance to prevent accidental operation of the machine.
Care
KEEP DRY. Do not clean the transmitter / receiver under high pressure. If water or other liquids get inside the transmit-
ter battery or receiver compartment, immediately dry the unit. Remove the case and let the unit air dry.
CLEAN THE UNIT AFTER OPERATION. Remove any mud, dirt, concrete, etc. from the unit to prevent clogging of but-
tons, switches, etc. by using a damp cloth.
Maintenance / Welding
DISCONNECT THE RADIO RECEIVER BEFORE WELDING on the machine the radio is connected to. Failure to dis-
connect will result in the destruction of the radio receiver.
DMAN-xxxx-xx
READ ALL INSTRUCTIONS
www.omnexcontrols.com
2
call toll free: 1-800-663-8806
