EXTERNAL CONTROL OF GLIDE AND FINAL DECAY.
The rocker switches in the left hand controller section
have replaced the momentary push buttons used previously.
have been added so that the performer can connect foot switches
to engage GLIDE and DECAY functions.
these momentary switches available as an accessory.
With no external switch connected and the GLIDE switch turned
"off" there will be no portamento.
"on" the pitch will glide between notes at a rate set by control 2
(see page 8 paragraph 12).
foot switch, he can momentarily engage portamento when the GLIDE
switch is off by depressing the switch button.
no effect if the GLIDE switch is already on.
The external control of the DECAY function works in an analogous
f a s h i o n .
To prevent confusion of the external foot switch cords with
input and output audio and control voltage cords, the jacks for
DECAY and GLIDE are 0.206" dia. instead of 0.250" dia.
jacks mate with Switchcraft S-260 plugs instead of ordinary 1/4"
phone plugs.
The external switch is a normally closed type.
the button is depressed.
JULY, 1971

LEFT HAND CONTROLLER

R. A. Moog will soon make
When the GLIDE switch is turned
When the performer connects the external
Jacks
The foot switch has
The
It opens when
7 0 - 0 1 9
