1. 958 FOOT PEDAL
This controller can be used to control the volume of the
output, pitch of the oscillators, or the cutoff frequency
of the filter (timbre).
ously to control all of these functions.
2. 959 X-Y CONTROLLER
This "joystick" simultaneously controls any two of the
functions mentioned above.
to produce vowel-like sounds by controlling the filter
and pitch.
3. SEQUENTIAL CONTROLLER SYSTEM
a. 960 Sequencer
b. 961 Interface (optional)
c. 962 Sequential Switch (optional)
d. 910 Power Supply for above units
e. Cabinet (portable or walnut console)
This system will automatically and simultaneously control
all three functions (pitch, timbre, and volume) in a repeating
eight-event sequence.
at the onset of each event.
sequence of one function to up to 24 events (example: 24 note
repeating bass line).
the contour generators and can be used to synchronize the MINI
MOOG with external equipment (example: tape recorded click
t r a c k ) .
1 . FOOT SWITCH
A pair of these will allow the performer to engage momentar-
ily GLIDE and DECAY functions.*
2. DUAL FOOT PEDAL
Essentially this device will contain two 958 Foot Pedals
for simultaneous control of timbre and volume.
* With a different plug the foot switch will supply an external
S - T r i g g e r .
JULY, 1971
OPTIONAL ACCESSORIES NOW AVAILABLE
FOR USE WITH MINI MOOG MODEL D
Up to three may be used simultane-
For instance, it can be used
It also triggers the contour generators
The 962 allows one to extend a
The 961 extends flexibility in triggering
AVAILABLE SOON
7 0 - 0 1 6
