Page 1: Instruction Manual
Touch Screen Embroidery Machine PTCS1501/1201/0601-TS Instruction Manual Ricoma (Shenzhen) Co., Ltd. www.ricoma.cn... - Page 2 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn Caution Note： The touch screen computer shall be shut down before power off the embroidery machine with the following method: press switch button on the right side of screen (as shown in the following picture), and then shut down the main power on the back of machine after screen off;...
- Page 3 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn Introduction to embroidery work interface Functions of each key are described as follows: Parameter setting interface is shown as follows: Add.: Building B, ShenChangGang Science Park, Jinlong Road 1, Baolong Industrial Town, Longgang District, Shenzhen, P.R.C...
- Page 4 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn Speedy embroidery Before delivery, each embroidery machine has been correctly set with parameters, thus, under no special circumstances and guidance, the machine will render you the first embroidery experience.
- Page 5 Instruction Manual of Embroidery Machine or the relevant video record attached with machine. It is required during framing to know sizes of each RICOMA frame so as to select proper frame in the computer as well as select in the touch screen computer according to the real item photo of frame;...
- Page 6 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn 5. Design input Press the key to call patterns saved in computer into the machine, as shown in the following picture: Select the needed embroidery pattern by clicking on “OK”, waiting for the pattern information, and operate until the prompt “READY”...
- Page 7 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn Note: it can be valid only by checking in the parameter setting or it will be manual color switch. 7. Pattern frame. Position of pattern in the frame means the position of actual...
- Page 8 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn click on to proceed with the embroidery. The above description is the complete operation process of embroidery. Parameter Setting: With more unique performance and simplified handling, the serial embroidery machine will bring you a thrilling embroidery experience to your liking.
- Page 9 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn Hook-line motor: Select stepping motor; Start angle for hook-line: With default value 320; Principal axis max speed: With default setting 1200rmp; Sequins function: With default setting “Close”; Start angle for cutting: With default setting degree 260;...
- Page 10 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn Auto jump stiches: It means auto jump when stitch length is bigger than the setting value, with default value 75，meaning auto jump when stitch length is bigger than 7.5mm; setting range 65—85，meaning6.5mm---8.5mm；...
- Page 11 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn jumps, with default value 80, meaning 80% of original speed, and the setting range 60—90, meaning 60%--90%； Stop frame of moving: It means if to stop working when receiving the stop instruction, with default status Yes；...
- Page 12 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn Display file stitch num: With default status Yes，meaning display the stitch number; Skip blank stitches: With default status Yes; Colour for screen: With default status Yes; Frame control type: Curve of frame moving, which can be used to adjust the actual embroidery effect, with default value 0 and setting rang 0-4;...
- Page 13 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn Thread break up: It means if to lift the undercarriage when there is thread breakup, with default value 0 and setting range 0/1; Delay while move frame: It means the compensation time for frame moving,...
- Page 14 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn Undercarriage type: It means the lifting mode of undercarriage, with default status Yes，no real setting meaning; Thread cut switch: With default status Yes，meaning start the thread cut function; Thread break backward stitches: With default value 4 and setting range 0-9 stitches;...
- Page 15 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn Seven cloth frames are available, with frame center point position and their size shown as bellow: Frame 1: Frame 2: Frame 3: Add.: Building B, ShenChangGang Science Park, Jinlong Road 1, Baolong Industrial Town, Longgang District, Shenzhen, P.R.C...
- Page 16 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn Frame 4: Frame 5: Frame 6: Frame 7: (Custom) Note: after setting, click on OK to save before quit. If any uncertainty about Add.: Building B, ShenChangGang Science Park, Jinlong Road 1, Baolong Industrial Town, Longgang District, Shenzhen, P.R.C...
- Page 17 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn setting, you can restore the default setting by clicking on IV 功能介绍 IV Function 1. Change the background color display: The function can be used to select proper background color, according to...
- Page 18 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn through file transmission (with status bar displaying Transfer firmware), till the status bar displaying READY; as shown in the following picture: Add.: Building B, ShenChangGang Science Park, Jinlong Road 1, Baolong Industrial Town, Longgang District, Shenzhen, P.R.C...
- Page 19 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn Warning Warning: during the upgrade, it is forbidden to cut off power and loosen the USB connection, otherwise serous costs resulted by damage to the master control board might be caused.
- Page 20 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn 5. Operational Control of Background Software Click on before start , check the running condition of background program, and terminate running of unnecessary program to ensure the normal operation of embroidery software, with interface shown as follows: 6.
- Page 21 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn With finger tip pressing on the center of round cross on the screen, and loosen finger when hearing the sound “ticktock” about two seconds later, and make calibration to other three points with the same way, save before quit.
- Page 22 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn 7. Function test: The practical function test can be used to conduct sorts of malfunction test and find causes by clicking on before starting , shown as follows: Function test such as hook-line, thread cut, sequins and cord grip are available;...
- Page 23 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn 10. Applique embroidery: The software can also be used to conduct repetitive appliqué operations by adding the operation of frame quit during the process of color switch sequence setting, as show in...
- Page 24 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn Color setting for thread roller The function can be used to set the actual color of thread on the wire coil in the computer, thus real time setting of color can be set according to the color of pattern, without pay attention to the stitch color on the wire rack and wire coil, during color sequence setting.
- Page 25 Visit us at www.ricoma.cn 12. Pattern making software-DISC As a powerful full touch screen pattern making software developed by RiCOMA, DISC can be used to realize one-stop operation of design and embroidery in combination with the embroidery software. Click on...
- Page 26 A Passion for Excellence Visit us at www.ricoma.cn Ampler additional devices developed by RICOMA have been reserved in the machine to meet different pattern embroidery needs of customers, such as silk banner, pillowcase, sleeve, glove, pants edge, briefcase, shoulder tape and shoes,...
- Page 27 ID (Password), you can achieve directly on-line interaction with RICOMA service personal; ● On-line text chat with sorts of machine malfunctions; ● On-line voice and video communication; (video devices are required for client) ●...
- Page 28 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn Caution In any time, embroidery machine have to be operated under the READY status. 1. When machine status bar displaying , please loosen the emergency stop switch to resume normal operation;...
- Page 29 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn Needle display 5. Trouble shooting for improper thread cut Errors prompt shown as follows means no effective induction from the thread cut sensor. Click on error prompt message, cutter automatically reset for induction; if the message still exists, watch out if any mechanical failure and prevent the cutter reset;...
- Page 30 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn Note: pay attention to operational safety, keep hands way from the cutter and needle rod; 6. Trouble shooting for principal axis not being at zero position: Errors shown as follows means the principal axis is not at zero (i.e. 100 degree) , then click on directly the error prompt message, with principal axis motor automatically working and turning to 100 degree.
- Page 31 RiCOMA (Shenzhen) Co.,Ltd A Passion for Excellence Visit us at www.ricoma.cn If any other error prompt message, please contact distributor or RiCOMA service www.ricoma.cn personal, or log on for newest solutions. Add.: Building B, ShenChangGang Science Park, Jinlong Road 1, Baolong Industrial Town, Longgang District, Shenzhen, P.R.C...
