INSTALLATION
14. Place the fridge door back on. Ensure the
fridge door is aligned horizontally and
vertically so that the seals are closed on
all sides before finally tightening the top
hinge.
15. Insert the hinge bracket and screw it to
the top of the unit.
16. Use a spanner to tighten it if necessary.
17. Put the top cover back and tighten it
with the screws. Reverse steps 1 to 3 for
details.
Double check that the fridge door
is aligned correctly and all the seals
are closed on all sides. If necessary,
re-adjust the levelling feet.
