Summary of Contents for MKS 260 PS-7
- Page 1 121739-P1 Rev A, 5/98 Instruction Manual MKS Type 260 PS-7 Power Supply Six Shattuck Road Fax: (978) 975-0093 Andover, MA 01810-2449 E-mail: mks@mksinst.com (800) 227-8766 or (978) 975-2350 Web site: http://www.mksinst.com...
- Page 2 For the period commencing with the date of shipment of this equipment and ending two years later, MKS will, at its option, either repair or replace any part which is defective in materials or workmanship or with respect to the date-related operations warranty without charge to the purchaser.
- Page 3 121739-P1 Rev A, 5/98 MKS Type 260 PS-7 Power Supply...
- Page 4 All rights reserved. No part of this work may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or by any information storage or retrieval system, except as may be expressly permitted in writing by MKS Instruments, Inc.
-
Page 5: Table Of Contents
Introduction ....................... 17 How This Manual is Organized.................. 18 Customer Support ...................... 18 Chapter Two: Installation ...................... 19 How To Unpack the Type 260 PS-7 Unit ..............19 Unpacking Checklist ..................19 Interface Cables ......................20 Generic Shielded Cable Guidelines..............21 Product Location and Requirements................ - Page 6 Table of Contents Setup..........................24 Dimensions....................24 Mounting Instructions..................25 Electrical Information....................26 Fuses ......................26 Grounding .....................26 How To Set the Line Voltage.................27 Connectors .........................28 DC Power Connectors..................28 Chapter Three: Overview .......................31 Front Panel Controls ....................31 Power LED Indicators..................31 Rear Panel Controls....................32 Power Entry Module..................32 AC Line Cord Connector ................32 Power On/Off Switch..................32 Fuses ......................32...
- Page 7 Table of Contents Appendix B: Model Code Explanation .................. 41 Model Code....................... 41 Index............................43...
- Page 8 Table of Contents...
- Page 9 List of Figures and Tables List of Figures and Tables Figures Figure 1: Preferred Method To Connect an Overall Metal Braided Shielded Cable ....22 Figure 2: Alternate Method To Connect an Overall Metal Braided Shielded Cable ....22 Figure 3: Front Panel Dimensions ..................24 Figure 4: Rear Panel Dimensions...................
- Page 10 List of Figures and Tables viii...
-
Page 11: Safety Information
Safety Information Safety Information Symbols Used in This Instruction Manual Definitions of WARNING, CAUTION, and NOTE messages used throughout the manual. Warning The WARNING sign denotes a hazard. It calls attention to a procedure, practice, condition, or the like, which, if not correctly performed or adhered to, could result in injury to personnel. -
Page 12: Symbols Found On The Unit
Safety Information Symbols Found on the Unit The following table describes symbols that may be found on the unit. Definition of Symbols Found on the Unit Protective earth (ground) Off (Supply) Earth (ground) On (Supply) IEC 417, No.5019 IEC 417, No.5017 IEC 417, No.5008 IEC 417, No.5007 Frame or chassis... -
Page 13: Safety Procedures And Precautions
DO NOT SUBSTITUTE PARTS OR MODIFY INSTRUMENT Do not install substitute parts or perform any unauthorized modification to the instrument. Return the instrument to an MKS Calibration and Service Center for service and repair to ensure that all safety features are maintained. - Page 14 Safety Information USE THE PROPER POWER SOURCE This product is intended to operate from a power source that does not apply more voltage between the supply conductors, or between either of the supply conductors and ground, than that specified in the manual. USE THE PROPER FUSE Use only a fuse of the correct type, voltage rating, and current rating, as specified for your product.
-
Page 15: Sicherheitshinweise
Sicherheitshinweise Sicherheitshinweise In dieser Betriebsanleitung vorkommende Symbole Definition der mit WARNUNG!, VORSICHT! und HINWEIS überschriebenen Abschnitte in dieser Betriebsanleitung. Warnung! &CU 5[ODQN 9#4070) YGKUV CWH GKPG )GHCJTGPSWGNNG JKP 'U OCEJV CWH GKPGP #TDGKVUCDNCWH GKPG #TDGKVUYGKUG GKPGP <WUVCPF QFGT GKPG UQPUVKIG )GIGDGPJGKV CWHOGTMUCO FGTGP WPUCEJIGO·G #WUHÒJTWPI D\Y WPIGPÒIGPFG $GTÒEMUKEJVKIWPI \W -ÌTRGTXGTNGV\WPI HÒJTGP MCPP 8QTUKEJV... -
Page 16: Am Gerät Angebrachte Symbole
Sicherheitshinweise Am Gerät angebrachte Symbole Der untenstehenden Tabelle sind die Bedeutungen der Symbole zu entnehmen, die an dem Gerät angebracht sind. Definitionen der am Gerät angebrachten Symbole Ein (Netz) Aus (Netz) Erde Schutzleiter IEC 417, Nr. 5007 IEC 417, Nr. 5008 IEC 417, Nr. -
Page 17: Sicherheitsvorschriften Und Vorsichtsmaßnahmen
Bauen Sie in das Instrument keine Ersatzteile ein, und nehmen Sie keine eigenmächtigen Änderungen am Gerät vor! Schicken Sie das Instrument zu Wartungs- und Reparatur-zwecken an einen MKS-Kalibrierungs- und -Kundendienst ein! Dadurch wird sicher-gestellt, daß alle Sicherheitseinrichtungen voll funktionsfähig bleiben. - Page 18 Sicherheitshinweise Erdung und Verwendung geeigneter elektrischer Armaturen! In diesem Instrument liegen gefährliche Spannungen an. Alle verwendeten elektrischen Armaturen und Kabel müssen dem angegebenen Typ entsprechen und sich in einwand-freiem Zustand befinden. Alle elektrischen Armaturen sind vorschriftsmäßig anzubringen und zu erden. Richtiges Netzkabel verwenden! Das verwendete Netzkabel muß...
-
Page 19: Informations Relatives À La Sécurité
Informations relatives à la sécurité Informations relatives à la sécurité Symboles utilisés dans ce manuel d'utilisation Définition des indications AVERTISSEMENT, ATTENTION et REMARQUE utilisées dans ce manuel. #XGTVKUUGOGPV . KPFKECVKQP #8'46+55'/'06 UKIPCNG WP FCPIGT RQVGPVKGN 'NNG GUV FGUVKP¾G ¯ CVVKTGT N CVVGPVKQP UWT WPG RTQE¾FWTG WPG WVKNKUCVKQP WPG UKVWCVKQP QW VQWVG CWVTG EJQUG RT¾UGPVCPV WP TKUSWG FG DNGUUWTG GP ECU F GZ¾EWVKQP KPEQTTGEVG QW FG PQPTGURGEV FGU EQPUKIPGU #VVGPVKQP... -
Page 20: Symboles Apparaissant Sur L'appareil
Informations relatives à la sécurité Symboles apparaissant sur l'appareil Le tableau suivant décrit les symboles apparaissant sur l'appareil. Définition des symboles apparaissant sur l'appareil Terre de protection Marche (sous tension) Arrêt (hors tension) Terre (masse) (masse) IEC 417, No. 5007 IEC 417, No. -
Page 21: Mesures De Sécurité Et Mises En Garde
NE PAS SUBSTITUER DES PIÈCES OU MODIFIER L'APPAREIL Ne pas utiliser de pièces détachées autres que celles vendues par MKS Instruments, Inc. ou modifier l'appareil sans l'autorisation préalable de MKS Instruments, Inc. Renvoyer l'appareil à... - Page 22 Informations relatives à la sécurité UTILISATION D'UN CORDON D'ALIMENTATION APPROPRIÉ Utiliser uniquement un cordon d'alimentation en bon état et conforme aux exigences de puissance d'entrée spécifiées dans le manuel. Utiliser uniquement un cordon d'alimentation amovible avec des conducteurs dont la section est égale ou supérieure à...
-
Page 23: Información Sobre Seguridad
Información sobre seguridad Información sobre seguridad Símbolos usados en el manual de instrucciones Definiciones de los mensajes de ADVERTENCIA, PRECAUCIÓN Y OBSERVACIÓN usados en el manual. #FXGTVGPEKC 'N UÃODQNQ FG #&8'46'0%+# KPFKEC WP TKGUIQ 2QPG FG TGNKGXG WP RTQEGFKOKGPVQ RT±EVKEC EQPFKEKÉP GVE SWG FG PQ TGCNK\CTUG W QDUGTXCTUG EQTTGEVCOGPVG RQFTÃC ECWUCT NGUKQPGU C NQU GORNGCFQU 2TGECWEKÉP... -
Page 24: Símbolos Que Aparecen En La Unidad
Información sobre seguridad Símbolos que aparecen en la unidad En la tabla que figura a continuación se indican los símbolos que aparecen en la unidad. Definición de los símbolos que aparecen en la unidad Encendido Apagado (alimentación eléctrica) (alimentación eléctrica) Puesta a tierra Protección a tierra IEC 417, N.°... -
Page 25: Procedimientos Y Precauciones De Seguridad
No se debe instalar piezas que no sean originales ni modificar el instrumento sin autorización. Para garantizar que las prestaciones de seguridad se observen en todo momento, enviar el instrumento al Centro de servicio y calibración de MKS cuando sea necesaria su reparación y servicio de mantenimiento. - Page 26 Información sobre seguridad USAR EL CABLE ELÉCTRICO ADECUADO Usar únicamente un cable eléctrico que se encuentre en buenas condiciones y que cumpla los requisitos de alimentación de entrada indicados en el manual. Usar únicamente un cable desmontable instalado con conductores que tengan un área de sección transversal equivalente o superior a 0,75mm².
-
Page 27: Chapter One: General Information
MKS Type 1153 Mass Flow Controller and the MKS Type 243A Controller and Readout. The 260 PS-7 unit provides the ±15 VDC ± 5% @ 1 amp required to power the pressure transducers in the 1153 MFC and to power the 243 controller, as well as the 24 VAC @ 8 amps required to power the heater in the 1153 unit. -
Page 28: How This Manual Is Organized
Calibration and Service Center before shipping. The ERA Number expedites handling and ensures proper servicing of your instrument. Please refer to the inside of the back cover of this manual for a list of MKS Calibration and Service Centers. Warning All returns to MKS Instruments must be free of harmful, corrosive, radioactive, or toxic materials. -
Page 29: Chapter Two: Installation
Chapter Two: Installation How To Unpack the Type 260 PS-7 Unit MKS has carefully packed the Type 260 PS-7 unit so that it will reach you in perfect operating order. Upon receiving the unit, however, you should check for defects, cracks, broken connectors, etc., to be certain that damage has not occurred during shipment. -
Page 30: Interface Cables
An overall metal braided shielded cable, properly grounded at both ends, is required during use to meet CE specifications. Interface cables can be purchased from MKS (refer to Table 5), or can be made provided that the appropriate specifications contained herein are maintained. For cables connecting to non-MKS products, MKS can provide normal shielding or braided shielded cable assemblies in a nominal 6’... -
Page 31: Generic Shielded Cable Guidelines
Chapter Two: Installation Interface Cables Generic Shielded Cable Guidelines Should you choose to manufacture your own cables, follow the guidelines listed below: 1. The cable must have an overall metal braided shield, covering all wires. Neither aluminum foil nor spiral shielding will be as effective; using either may nullify regulatory compliance. 2. -
Page 32: Figure 1: Preferred Method To Connect An Overall Metal Braided Shielded Cable
Interface Cables Chapter Two: Installation Example 1: Preferred Method To Connect Cable (shown on a transducer) Metal Cable Clamp Screw Transducer Split Lock Washer Overall Insulation External Tooth Lock Washer (if present) Bare Metal Cable Clamp Transducer Housing Making Firm Contact To Braid Braid Here Is Desirable Optional Plastic or Metal Cable (but not usually necessary) -
Page 33: Product Location And Requirements
Ventilation requirements include sufficient air circulation • Connect the power cord into a grounded outlet Safety Conditions The 260 PS-7 unit poses no safety risk under the following environmental conditions. • Altitude: up to 2000 m • Maximum relative humidity: 80% for temperatures up to 31° C, decreasing linearly to... -
Page 34: Setup
Setup Chapter Two: Installation Setup Dimensions Note All dimensions are listed in inches with millimeters referenced in parentheses. 3.47 (88.11) 3.00 (76.23) 8.88 (225.50) 9.47 (240.51) Figure 3: Front Panel Dimensions 2.05 (52.18) 2.55 3.38 (64.89) (85.73) 1.98 (50.41) 3.48 (88.51) 4.98 (126.61) -
Page 35: Mounting Instructions
Mounting Instructions The 260 PS-7 unit can be used as a bench top instrument, or can be mounted in a panel cutout or in a half-rack. A rack mounting kit (RM-6) is available from MKS for single or dual unit rack mounting. -
Page 36: Electrical Information
Power Entry Module in the rear panel of the unit (refer to Figure 7, page 32). The fuse values are listed in Table 6. Fuse Information Voltage Setting Fuse Type MKS Part Number 100 / 120 VAC 3.15 A (T) / 250 V 024-1604 220 /240 VAC 1.6 A (T) / 250 V... -
Page 37: How To Set The Line Voltage
How To Set the Line Voltage The Line Voltage Selector configures the 260 PS-7 unit to accept the value of the selected line voltage of 100, 120, 220, or 240 VAC input voltage. The value is visible through the window in the cover of the Power Entry Module. -
Page 38: Connectors
Connectors Chapter Two: Installation Connectors The 260 PS-7 unit’s three connectors are located on its rear panel (refer to Figure 7, page 32). The interface cables are listed in Table 5, page 20. DC Power Connectors The two 9-pin male Type “D” connectors provide the ±15 VDC power required for the pressure transducers in 1153 MFC and to power the 243 controller. -
Page 39: Table 8: Ac Power Connector Pinout
Chapter Two: Installation Connectors 24 VAC Power Connector The 15-pin female Type “D” connector provides the 24 VAC required to power the heater in the 1153 MFC. 24 VAC Power Connector Pinout Pin Number Assignment + 24 VAC Out + 24 VAC Common + 24 VAC Out + 24 VAC Common + 24 VAC Out... - Page 40 Connectors Chapter Two: Installation This page intentionally left blank.
-
Page 41: Chapter Three: Overview
Chapter Three: Overview Front Panel Controls Chapter Three: Overview Front Panel Controls +15 V Power LED Indicator -15 V Power LED Indicator Figure 6: Front Panel Controls Power LED Indicators These two LEDs illuminate green when ±15 VDC power is being supplied to the unit. -
Page 42: Rear Panel Controls
The Power On/Off Switch controls power to the 260 PS-7 unit. Fuses The fuse protects the internal circuitry of the 260 PS-7 unit; both sides of the line are fused. The fuse values are listed in Table 6, page 26. -
Page 43: Line Voltage Selector
Rear Panel Controls Line Voltage Selector The Line Voltage Selector configures the 260 PS-7 unit to accept either 100, 120, 220, or 240 VAC input voltage. The value of the selected line voltage is visible through the window in the cover of the Power Entry Module. -
Page 44: Labels
CE mark signifying compliance with the European CE regulations. Serial #: 0123456789 Model #: 260 PS-7 MKS Instruments, Inc. Made in the USA Figure 8: Serial Number Label Voltage/Fuse Label The voltage/fuse label, located on the rear panel of the unit, lists the recommended fuse values for each voltage setting. -
Page 45: Chapter Four: Operation
4. Connect the 1153 MFC and the Type 243 controller to the connectors on the rear panel of the 260 PS-7 unit (refer to Figure 7, page 32) using the proper interface cables. The interface cables are listed in Table 5, page 20. - Page 46 General Information Chapter Four: Operation This page intentionally left blank.
-
Page 47: Chapter Five: Maintenance And Troubleshooting
MKS Instruments immediately. If it is necessary to return the unit to MKS, obtain an ERA number (Equipment Return Authorization Number) from a MKS Service Center before shipping. Please refer to the inside back cover of this manual for a list of MKS Calibration and Service Centers. -
Page 48: Troubleshooting
If the power supply is not operating properly, check for obvious problems such as whether the power is off, there is an open fuse, defective line cord, input power failure, or loose connections. If, after checking these items the unit still does not function properly, contact MKS for assistance. -
Page 49: Appendix A: Product Specifications
Appendix A: Product Specifications Appendix A: Product Specifications CE Compliance EMC Directive 89/336/EEC Electromagnetic Compatibility Low-Voltage Directive 73/23/EEC Low-Voltage Requirements II, according to EN 61010-1 Installation Category 2, according to IEC 664 Pollution Degree Product Safety Directive 92/59/EEC Product Safety and Liability Fuse Ratings 100/120 VAC Setting 3.15 A (T) - Page 50 Appendix A: Product Specifications This page intentionally left blank.
- Page 51 Appendix B: Model Code Explanation Model Code Appendix B: Model Code Explanation Model Code The type number designates the model number of the instrument. The power supply is identified as the Type 260 PS-7.
- Page 52 Model Code Appendix B: Model Code Explanation This page intentionally left blank.
- Page 53 Index Index Cables, 20 Labels CE mark, 20 serial number, 34 Connectors voltage/fuse, 34 AC power, 29, 33 Line voltage selector, 27, 33 DC power, 28, 33 Customer support, 18 Maintenance, 37 Manual organization, 18 Description, 17 Dimensions, 24–25 Operating temperature, 23 Fuses, 26 Pollution Degree, 23 replacement, 37...
