HP Hub-8TXE Installation and Reference Guide
: If the Link LED does not light up when a device is connected to its corre-
Troubleshooting
sponding port, check that both the hub and connected device are powered on. For devices
connected to the hub using twisted-pair cable, check that the cable length does not exceed
100 meters. You should have standard, straight-through cables and not crossover or other
specialized cables.
Traffic
Color: Green
Function: Indicates traffic entering the port.
Condition
BLINKING Indicates the port is receiving packets; blinking is
proportional to the traffic entering the port.
OFF No packets are being received by this port.

RJ-45 Fast Ethernet Ports

This hub includes 8 Fast Ethernet ports on the front panel; of which Port 8 can
also serve as a cascade port. Connect the MDI-X ports to network devices such
as workstations or servers, and the MDI port to a network interconnection
device such as another hub or switch. Remember that you cannot connect to
port 8 MDI-X and Port 8 MDI at the same time.
Note: Use Category 5 straight-through twisted-pair cable (STP or UTP) for all standard
connections. However, if you must cascade between two hubs using similar port types
at both ends of the cable, use crossover cable.
Indication
Hardware Reference 4-5
