Basic Features - HP AdvanceStack 100Base-T Hub-8TXE Installation And Reference Manual

HP Hub-8TXE Installation and Reference Guide

Basic Features

•
Transmits data at 100 Mbits/s for demanding applications
•
Conforms to the IEEE 802.3u repeater specification for 100Base-TX
•
Provides 8 RJ-45 100Base-TX ports (using MDI-X wiring)
•
Port 8 can serve as an MDI-X port (for connection to network devices such
as workstations or servers) or as an MDI daisy-chain port (for connection to
network devices such as hubs or switches), eliminating the need for
crossover cables
•
Supports 100
•
Friendly design that monitors network utilization, collisions, link and port
partition status
•
LED indicator panel includes Utilization and Collision rate indicators for
reporting hub activity and facilitating problem diagnosis
•
Automatically partitions bad ports to protect the network system
•
Automatic polarity detection and correction permits automatic adjustment
for wiring errors
•
Plug-and-play operation
The HP Hub-8TXE also supports the following basic system safeguards:
•
This hub features automatic partitioning and reconnection, jabber lockup
protection, and automatic polarity detection for network cabling.
•
With automatic partitioning and reconnection, any port is automatically
isolated if excessive collisions occur on it. When the condition is corrected,
the port is automatically reconnected.
1-2
Ω
Category 5 shielded or unshielded cable (STP or UTP)
Product Overview
