IDE Primary Master/Primary Slave/Secondary Master/Secondary Slave
Press PgUp/<+> or PgDn/<-> to select the hard disk drive type. The
specification of hard disk drive will show up on the right hand according to
your selection.
Access Mode
Capacity
Cylinder
Head
Precomp
Landing Zone
Sector
Drive A/B
This item allows you to set the type of floppy drives installed. Available
options: None, 360K, 5.25 in., 1.2M, 5.25 in., 720K, 3.5 in., 1.44M, 3.5 in.,
2.88M, 3.5 in..
Video
The item sets the type of video adapter used for the primary monitor of the
system . Available options: EGA/VGA , CGA 40, CGA 80 and MONO.
IDE Primary Master
The settings are Auto, CHS, LBA and Large.
The formatted size of the storage device.
Number of cylinders.
Number of heads.
Write precompensation cylinder.
Cylinder location of the landing zone.
Number of sectors.
