- Page 1 Uninterruptible Power Systems S3K Series Instruction Manual...
- Page 2 ©2009 EGS Electrical Group, LLC. All rights reserved. Specifications are subject to change without notice. ®SolaHD name and logo are registered trademarks of EGS Electrical Group, LLC. All names referred to are trademarks or registered trademarks of their respective owners. Visit our Web site at www.solahd.com S3K Series Instruction Manual • ii...
-
Page 3: Table Of Contents
6.0 Alarms ....................... 10 7.0 Software & Interface ................11–12 8.0 Maintenance & Storage ................12 9.0 Troubleshooting ..................13 10.0 Specifications ..................14–15 11.0 Registration & Warranty ................15 Visit our Web site at www.solahd.com S3K Series Instruction Manual • iii... -
Page 4: Important Safety Instructions
1.0 Important Safety InStructIonS Thank you for selecting the S3K Series Uninterruptible Power System (UPS). This manual contains important safety instructions that should be followed during the installation and operation of your UPS. Please read all safety, installation and operating instructions before attempting to install or operate the UPS. Please adhere to all warnings on the unit and in this manual during installation and operation. -
Page 5: Product Description
UPS is correcting a high utility voltage condition. The loads will continue to receive normal power. ON-lINE Indicator (green lED): The LED illuminates when the line input voltage is normal. Visit our Web site at www.solahd.com S3K Series Instruction Manual • 5... -
Page 6: Rear Panel
REMOTE pORT (computer Interface): Provides both RS-232 and relay signals to support Windows applications and other OS compatible solutions. SNMp pORT cOVER (S3k1600 Models Only): Remove the cover to insert the .NETpower card (P/N: SNMPCARDPC). Visit our Web site at www.solahd.com S3K Series Instruction Manual • 6... -
Page 7: Pre-Installation
The UPS charges its battery whenever it is connected to utility power, even when the unit is off. For best results, charge the battery for 8 hours before initial use. 4.2.3 turn on the uPS Press the ON/TEST button. Visit our Web site at www.solahd.com S3K Series Instruction Manual • 7... - Page 8 Use network cables (supplied by user) to connect the UPS to the computer network port. Please refer to the .NETpower card CD-ROM for configuration settings and further instructions. Visit our Web site at www.solahd.com S3K Series Instruction Manual • 8...
-
Page 9: Operation
LEDs are lit, the load is drawing between 50% and 67% of the UPS’s capacity. If the UPS is overloaded, the overload LED illuminates and the alarm sounds. Visit our Web site at www.solahd.com S3K Series Instruction Manual • 9... -
Page 10: Alarms
When the UPS output exceeds 100% of nominal for 20 seconds or 125% for 2 seconds, an audible alarm will sound and the front panel OVERLOAD LED will illuminate. The UPS will shut down automatically to protect its internal circuitry. Visit our Web site at www.solahd.com S3K Series Instruction Manual • 10... -
Page 11: Software & Interface
• Broadcasting a warning when power fails; • Closing any open file before the batteries are exhausted; • Turning off the UPS. Please refer to 7.4.1 on page 12 for Remote Port PIN Configurations. Visit our Web site at www.solahd.com S3K Series Instruction Manual • 11... -
Page 12: Maintenance & Storage
• During extended storage in environments where the ambient temperature is -15°C to +30°C (+5°F to +86°F), charge the UPS’s batteries every 6 months; +30°C to +45°C (+86°F to +113°F), charge the UPS’s batteries every 3 months. Visit our Web site at www.solahd.com S3K Series Instruction Manual • 12... -
Page 13: Troubleshooting
Damage present on battery Replace the battery packs packs immediately for further assistance, please contact SolahD Technical Support at: U.S.: (800) 377-4384 • International: (847) 268-6651 • E-mail: tech@solahd.com Visit our Web site at www.solahd.com S3K Series Instruction Manual • 13... -
Page 14: Specifications
Hot swappable, sealed, maintenance-free, lead acid Typical Recharge Time 4 hours (to 90% of full capacity) protection Automatic self-test & discharge protection. Replace battery indicator. Backup Time 10–30 min. (depending on the load) Visit our Web site at www.solahd.com S3K Series Instruction Manual • 14... -
Page 15: Registration & Warranty
To register your product for updates and information on service and support, visit our Web site at: http://www.solahd.com/support/registration.htm 11.2 Warranty information Please see the enclosed “Terms & Conditions of Sale”. Visit our Web site at www.solahd.com S3K Series Instruction Manual • 15... - Page 16 Technical Support U.S.: (800) 377-4384 International: (847) 268-6651 E-mail: tech@solahd.com Web site: www.solahd.com Part Number: A272-076 Rev 3 August 24, 2009...
