S4K5U-5C 6 kVA International On-Line UPS
The new SolaHD S4K5U6K5C Industrial On-Line UPS
Series is designed for international usage and provides
flexible output voltage, an integrated maintenance bypass
switch and internal batteries all in a slim 5U (8.7") enclosure.
The S4K5U-5C features true On-Line (double conversion)
topology providing the ultimate in protection against a wide
range of potential power problems. Flexible output voltages
(220/230/240 Volt) are available through the configuration
program to allow for international use. One of the three L-N
output voltages is selected to match the local voltage. Self
diagnostics simplify maintenance and troubleshooting, and
the UPS can be serviced by the customer. The standard
maintenance bypass switch provides an additional level of
protection.
The S4K5U-5C also features a wide input voltage window to
support the critical load without having to transfer to the
battery. This extends system availability when back-up is
truly needed.
Features
• True double conversion topology
• Higher Power Factor of 0.80
• Flexible L-N output voltage (220/230/240V)
• Configurable as a Tower or Rack Mount model
• High density, 6 kVA in only 5U of rack space
• Easily installed in 18" to 32" deep rack using rack mount
kit # SRS1832
• User replaceable, hot-swappable internal battery module
• Matching 3U Extended Battery Cabinets
• Includes both automatic and manual maintenance
bypass switch
• Automatic frequency detection of either 60 or 50 Hz
• Power Factor Correction
• Self-Diagnostics simplify maintenance and
troubleshooting
• Remote Emergency Power Off (REPO)
• IntellislotTM, USB, and terminal Block Communication
ports
• Compatible with most standby generators
• Two Year Limited Warranty
Clearwater Tech - Phone: 800.894.0412 - Fax: 208.368.0415 - Web: www.clrwtr.com - Email: info@clrwtr.com
Uninterruptible Power Systems
Applications
• Industrial Computers
• Robotics and Process Controls
• Industrial Automation Systems
• Network Servers
• Enterprise Telecommunication Systems
• Printing and Publishing Machinery
• Industrial and Commercial Machinery
• Pharmaceutical and Medical Diagnosis Equipment
Related Products
• Portable MCR Power Conditioners
• Surge Protective Devices
• Active Tracking
Filters
®
3

Advertisement

loading
Need help?

Need help?

Do you have a question about the S4K240BATC and is the answer not in the manual?

Questions and answers

Related Manuals for Sola HD S4K240BATC

Summary of Contents for Sola HD S4K240BATC

  • Page 1 Uninterruptible Power Systems S4K5U-5C 6 kVA International On-Line UPS The new SolaHD S4K5U6K5C Industrial On-Line UPS Series is designed for international usage and provides flexible output voltage, an integrated maintenance bypass switch and internal batteries all in a slim 5U (8.7”) enclosure. The S4K5U-5C features true On-Line (double conversion) topology providing the ultimate in protection against a wide range of potential power problems.
  • Page 2 Uninterruptible Power Systems Table 10: UPS Specifications Parameters Model Number: S4K5U6K5C Rating 6000 VA/4800 W diMeNSioNS, d x W x h, mm [in.] Unit 570 x 430 x 220 [22.4 x 16.9 x 8.7] Shipping 745 x 530 x 516 [29.3 x 20.9 x 20.3] WeighT, kg [lb.] Unit 60 [132.2]...
  • Page 3 Uninterruptible Power Systems Table 11: UPS Specifications Parameters Model Number: S4K5U6K5C AgeNCy Safety IEC62040-1:2008 Version EMI/EMC IEC/EN/AS 62040-2 2 Edition (Cat 2—Table 6) EN61000-4-2, Level 4, Criteria A EN61000-4-3, Level 3, Criteria A Radiated Susceptibility EN61000-4-4, Level 4, Criteria A Electrical Fast Transient EN61000-4-5, Level 3, Criteria A Surge Immunity...

  • Page 4: Battery Parameters

    Uninterruptible Power Systems Table 14: internal Battery Specifications Parameters Model Number: S4K240iNTBATC Used with UPS Model S4K5U6K5C diMeNSioNS, d x W x h, mm [in.] Unit 390 x 113 x 184 [15.4 x 4.4 x 7.2] Shipping 467 x 178 x 262 [18.4 x 7.0 x 10.3] WeighT, kg [lb.] Unit 20.6 [45.1]...
  • Page 5 Uninterruptible Power Systems Table 15: external Battery Cabinet Specifications Parameters Model Number: S4K240BATC Used with UPS Model S4K5U6K5C diMeNSioNS, d x W x h, mm [in.] Unit (with bezel) 570 x 430 x 148 [22.4 x 16.9 x 5.8] 745 x 530 x 407 [29.3 x 20.8 x 16.0] Shipping WeighT, kg [lb.]...
  • Page 6 Uninterruptible Power Systems Table 16: Battery Backup Times output to Connected Load, W Number of Batteries 100% Load, W 1400 1800 2200 2600 3000 3400 3800 4200 4600 4800 Internal battery Internal battery + 1 external battery 4800 cabinet Internal battery + 2 external battery 28.5 22.5 19.5...
  • Page 7 Uninterruptible Power Systems UPS Extended Warranty Offering for the SolaHD 1K, S3K and S4K Series S4KC Industrial – UPS Models The extended warranty program extends the standard Catalog Number Description two-year product warranty by the term of the extension 1-Year Extended Warranty purchased, 1-year or 3 years.
  • Page 8 Uninterruptible Power Systems Field Service Programs for the S4K4UC/6UC Industrial and S5K Series These programs are for Domestic coverage (valid only within S5K Modular Start-Up Programs the continental United States and Canada); additional travel expenses may be billed to customers with site locations Start-Up is included in the cost of the S5K Modular UPS.
  • Page 9 Uninterruptible Power Systems Field Service Programs for the S4K4UC, S4K6UC Industrial and S5K Series - continued S4K4UC and S4K6UC Industrial Start-Up Programs S4K4UC and S4K6UC Industrial Service Programs 1 PM Only (Mon-Fri, 8 am - 5 pm) Catalog Number Description Catalog Number Equipment Domestic Only (Monday - Friday, 8am - 5pm)
