S5KC Modular Series On-Line Uninterruptible Power Systems (UPS)
The S5KC Modular UPS is scalable from 5 to 20 kVA,
offering many flexible options by adding a few standard
modules. Designed to be fully configured, tested and
shipped in the configuration you need, the S5KC Modular
UPS also has the ability to be easily upgraded in the
field to either higher VA ratings (up to 20 kVA maximum),
longer back-ups time or to add N+x parallel redundancy.
Configurations can be cost-effectively upgraded keeping
your S5KC Modular UPS current without a large
reinvestment in a new system.
The optional N+x redundancy provides a fault-tolerant group
of power modules and controls. The modular design is easy
to upgrade so the UPS can grow with the needs of the
system that is being protected.
Each of the modular components, including 5 kVA power
modules, LCD display, battery modules and system control
modules, can be hot-swapped making it easy to increase
power, extend your back-up time or add redundancy while
still providing power protection to the load.
This fault-tolerant system uses intelligent power and battery
modules which take themselves off-line if there is a problem
without interrupting power to the load. Self-diagnostic
capabilities simplify maintenance and troubleshooting. Each
unit incorporates an internal automatic bypass.
Applications
With multiple standard options in a smaller footprint,
providing more flexibility for capacity and communication
both pre- and post-installation, the S5KC delivers the
power protection needs in applications such as
• Oil and Gas (Pure OEMs)
• Pharmaceutical
• Automotive
• Food & Beverage
Features
• Module level redundancy provides multiple layers of
protection to ensure your machine has the power it
needs to run safely with no single point of failure, critical
loads continue to run on conditioned battery power even
if a system component malfunctions.
• An industry leading 0.9 power factor keeps machines
performing flawlessly when running on battery power.
• Superior overload capabilities deliver conditioned power
during temporary power anomalies without unnecessarily
transferring to and from bypass power.
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: info@clrwtr.com
Uninterruptible Power Supplies
E179213
• Independently controlled maintenance bypass is
designed to provide maximum system availability to
critical equipment by allowing transfer of connected
equipment to an alternate power path. The UPS can
then be turned Off and removed from service with no
interruption of power to connected equipment.
• True on-line double conversion with a large input voltage
range (low line transfer down to 110 Vac) isolates
sensitive equipment from power fluctuations while
minimizing transfers to increase battery life.
• ENERGY STAR® qualified UPS models – UPS products
meeting the EPA's requirements use an average of 35%
less energy than their standard counterparts.
• To enhance the availability and trouble-free operation,
every pre-configured S5KC UPS arrives standard with
one IS-UNITY-DP communications card installed.
Enabling you to take advantage of the remote monitoring
and diagnostic service available with your system during
your initial standard warranty period.
• Start-up services available, contact your local SolaHD
sales representative for details.
Certifications and Compliances
• Listed, UPS Equipment
- UL 1778, Fourth Edition
- CSA C22.2 No. 107.3
• Series S5KCA, S5KCB,S5KCC,S5KCD
- CE (Low Voltage and EMC Directive)
EN62040-1, EN62040-2 EAC - TR CU 004/2011
Safety of Low-Voltage Equipment, TR CU 020/2011
EMC
