Craftsman Chipper Shredder — Model No. 247.77605
Ref. No.
Part No.
1.
936-0217
2.
914-0149B
3.
720-0170
4.
681-0094-4044
5.
911-0835
6.
781-0457-0637
7.
926-0211
8.
950-0793
9.
912-3027
10.
712-3004A
11.
936-0119
12.
981-04091
13.
710-3025
14.
710-0157
15.
942-0544B
16.
710-1054
17.
681-04095
18.
912-0411
19.
712-0266A
20.
719-04308
21.
738-04286A
PARTS LIST
Description
Lock Washer, 3/8
Cotter Pin
Wing Knob 5/16-18
Chute Deflector Assembly
Clevis Pin
Shredder Screen
U-Nut 5/16-18
Spacer
Hex Lock Nut, 1/4-20
Hex Lock Nut 5/16-18
Lock Washer 5/16
Inner Impeller Housing Assembly
Hex Cap Screw 5/16-18 x.625
Hex Cap Screw 5/16-24 x .75
Chipper Blade
Hex Cap Screw 5/16-24 x 1.0
Impeller Assembly
Hex Lock Nut 5/16-24
Nut, Jam Lock, 3/8-16
Flail Blade
Shoulder Pin, .5 x 2.625
Ref. No.
Part No.
22.
710-3008
23.
736-0247
24.
942-0571
25.
710-1254
26.
681-0004A-4044
27.
710-0825
28.
781-0515-0637
29.
781-0574-0637
30.
681-0104-4044
31.
932-0306A
32.
936-0117
33.
914-0104
34.
936-0264
35.
710-0376
36.
748-0453
37.
731-1707A
38.
912-0429
39.
731-1710A
40.
681-0123-4044
41.
711-1128
21
Description
Hex Cap Screw 5/16-18 x .75
Flat Washer 3/8 x 1.25
Shredder Blade
Hex Cap Screw 3/8-24 x 2.25
Outer Impeller Housing Assembly
Hex Cap Screw 1/4-20 x 3.75
Front Support Bracket
Shredder Plate
Rear Hopper Bracket Assembly
Compression Spring 1.75
Flat Washer
Cotter Pin
Flat Washer.330 ID x .630 OD
Hex Cap Screw 5/16-18 x 1.0
Spacer, .375 ID x 2.50 LG
Hopper Assembly
Hex Lock Nut 5/16-18
Hopper Collar
Front Hopper Bracket Assembly
Lock Rod
