Page 1: Service Manual
Service Manual Phaser 480 and Phaser 480X ™ ™ Color Printers Warning The following servicing instructions are for use by qualified service personnel only. To avoid personal injury, do not perform any servicing other than that contained in operating instructions unless you are qualified to do so.
Page 2 Tektronix, Inc., Wilsonville, Oregon. Printed in the United States of America. All rights reserved. Contents of this publication may not be reproduced in any form without permission of Tektronix, Inc. This instrument, in whole or in part, may be protected by one or more U.S. or foreign patents or patent applications.
Page 3: Users Safety Summary
Users safety summary Terms in manual: CAUTION Conditions that can result in damage to the product. WARNING Conditions that can result in personal injury or loss of life. Power source: Do not apply more than 250 volts RMS between the supply conductors or between either supply conductor and ground.
Page 4 Service safety summary For qualiﬁed service personnel only: Refer also to the preceding Users Safety Summary. Do not service alone: Do not perform internal service or adjustment of this product unless another person capable of rendering ﬁrst aid or resuscitation is present. Use care when servicing with power on: Dangerous voltages may exist at several points in this product.
Page 5: Shipping The Printer
Caution To keep your warranty valid, the printer must be shipped in its Tektronix shipping box, taking reasonable care to repack it properly. Failure to do so will result in damage to the printer. Remove the paper tray and repack it for shipping: Insert the two small foam shipping blocks into the paper tray on either side of the metal plate.
Page 6 Use the two tie-wraps to secure the block to the paper clamp bar. Attach them on the right-hand side where there is open space beneath the paper clamp bar. Make sure that they are tightly secured. 8849-71 Phaser 480 Color Printer...
Page 7 Shipping the Printer Place the two rubber cushions, marked L (left) and R (right), onto the metal bar on either side of the platen. Make sure that the rubber cushions are positioned with the posts upright (or leaning slightly forward) and facing outward as shown. Caution The rubber cushions protect the printhead.
Page 8 Shipping the Printer Repack the printer in the Tektronix shipping box. Keep the printer level when moving. 8849-50 Phaser 480 Color Printer...
Page 9: General Information
ﬁeld replaceable units (FRU) list, and assembly/disassembly procedures for selected FRUs. To ensure complete understanding of the product Tektronix recommends participation in Phaser 480 and 480X service training, if available. Figure 1-1. The Phaser 480 Color Printer...
Page 10: The Phaser 480 Color Printer
The Phaser 480X also has a greater RAM memory capacity. Unlike the Phaser 480, the Phaser 480X can use 32 Mbytes SIMMs in the ﬁrst three of its four RAM SIMM connectors, giving the Phaser 480X a potential total RAM memory capacity of 112 Mbytes.
Page 11: Sublimation Dye Printing
Sublimation dye printing Dye sublimation printing is an extension of thermal wax transfer printing. Many of Tektronix’ current and previous printers are based on thermal-wax transfer technology. During the dye sublimation printing process, transfer roll dye, in contact with a sheet of special paper, is vaporized (sublimed) into the surface of the paper by an electronically controlled thermal head.
Page 12: Print Engine Assemblies
® Lower rear cover S- 23 St at lT al k® stic rtjo d Rat ra lle ctio Power cord e Us Rear panel of receptacle image processor board 8849-03 Figure 1-3. Print engine rear view Phaser 480 Color Printer...
Page 13: Figure 1-4. Print With Top Cover Open
General Information Thermal head Right side cover Top cover release Transfer roll 8850-04 Figure 1-4. Print with top cover open Pinch roller Platten Idle roller Timing belt Paper clamp bar 8849-05 Figure 1-5. Print engine interior Service Manual...
Page 14: Figure 1-6. Sensors And Switches Locations
Paper clamp sensor Pick solenoid Left step motor Lower transfer roll sensor Clutch B Clutch gear Clutch feed Exit sensor Paper size sensor Clutch F Paper sensor Right stepper motor 8850-06 Figure 1-6. Sensors and switches locations Phaser 480 Color Printer...
Page 15: Rear Panel
Ethernet® LocalTalk® Status 8849-07 Figure 1-7. The Phaser 480 rear panel About the Ethernet AAUI connector Activating the Ethernet AAUI connector is optional as indicated by “not installed” printed above the connector. Installing the Ethernet card on the image controller board activates the Ethernet connector. The Ethernet card contains the hardware and code to support the EtherTalk, TCP-IP and Novell network protocols.
Page 16: Health Led
A single health LED indicates the status of the printer’s image processor board. Blinking (at a steady rate): The printer is operating normally. The LED blinks irregularly during diagnostics. On or Off : A hard error condition has occurred that would keep the image processor board from operating. Phaser 480 Color Printer...
Page 17: Rear Panel Dip Switches
General Information Rear panel DIP switches The Phaser 480's rear panel DIP switches control the functions of the printer. Combine the switch settings listed in the table below to customize the printer to the users' operating needs. Table 1-2. Normal operation — Phaser 480 rear panel DIP switches Switch Position ( ↑...
Page 18: Front Panel
MEDIA: On blinking indicates that the paper tray is empty. JAM: On indicates a jam has occurred inside the printer. ERROR: On indicates a hardware engine error has occurred. TRANSFER ERROR MEDIA COVER READY POWER ROLL 8850-08 Figure 1-8. The front panel 1-10 Phaser 480 Color Printer...
Page 19: Specifications
General Information Speciﬁcations Table 1-3. Physical dimensions Dimensions Value Height 34 cm. (13.4 ins.) Width: 52 cm (20.5 ins.) Depth: 57 cm (22.5 ins.) Without paper tray Weight: Approximately 41 kgs (90.2 lbs.) Print engine, paper tray and transfer roll weight only Table 1-4.
Page 20 (±3 mm, 0.71 in. 18 mm 0.71 in. 18 mm 18 mm 0.12 in.) Bottom 0.24 in 5.7 mm 0.24 in. 6.0 mm 10.8 mm Left/right 0.14 in. 3.6 mm 0.14 in. 3.4 mm 8.6 mm 1-12 Phaser 480 Color Printer...
Page 21: Table 1-6 Electrical Specifications
General Information Table 1-6. Electrical specifications Characteristic Speciﬁcation Primary line voltages 90 to 132 VAC (115 VAC nominal) 180 to 264 VAC (220 VAC nominal) input voltage range is switch-selectable. Primary voltage 47 to 63 Hz frequency range Power consumption 150 watts at idle.
Page 22: Regulatory Specifications
CISPR 22 (Class B) Radio Frequency Interference Suppression of Radio Frequency Equipment for Industrial, Scientiﬁc, Medical (ISM) and Similar Purposes. IEC: EN55082-1 Limits and methods of measurement of radio interference characteristics of Information Technology Equipment. 1-14 Phaser 480 Color Printer...
Page 23: Installing The Printer And Drivers
Drivers This chapter discusses installing the printer and its drivers as a part of the S0 installation option. Tektronix Service Option S0 consists of three main functions detailed in this and the next two chapters of this manual: Chapter 2 “Installing the Printer and Drivers.” The ﬁrst portion of installation instructions, this chapter, consists of ﬁve basic processes:...
Page 24: Pre-Install Questions For Customers
Some applications require special printing utility ﬁles. _____________________________________________ Will the application(s) and sample ﬁles be available at the time of the installation to send test ﬁles to the printer?________ Will a SCSI font disk be installed on the printer? ___ Phaser 480 Color Printer...
Page 25 _______ Swiss Option A5 (161-0154-00) Customers must provide the particular interface cable or network adapter they need to use with the printer. Customers can purchase the following from the Tektronix Graphics Supplies Order Desk by calling 1-800-835-6100. 10 ft. parallel cable 012-1214-00 Serial, 25 to 25 pin, 3 m (10 ft.) null modem...
Page 26 750 kbyte hard disk space for ﬁles Based on the results of the pre-install interview with the customer, you may wish to access the Tektronix Highly Automated Library (HAL) during business hours, at 1-800-835-6100 (ask to be transferred to HAL) for articles that may help with installing the printer into a customer's network.
Page 27: Unpacking
Installing the Printer and Drivers Unpacking Factory options Option P1: Ethernet SIMM (includes EtherTalk and Novell support) Option P2: TCP/IP protocol support authorization key Option 16: add one 16-Mbyte RAM SIMM Option 32: add two 16 Mbyte RAM SIMMs Option L1/2/3/4: French, Italian, German, or Spanish manual Option A1/2/3/5: International power cord Upgrade kits: Option 4680FP1: Ethernet card, supports EtherTalk and Novell...
Page 28: Printer Inventory
Transfer roll tray Paper tray (B/A3/WB) Sample transfer roll Cleaning kit Phaser 480 User Manual Phaser 480 Drivers and Utilities Printing Reference manual and diskettes Optional Network Utilities for Phaser Color Printers manual and diskettes Getting Started packet Supplies information sheet...
Page 29: Figure 2-1. The Phaser 480 And Its Packaging
P ri n ti R ef er en a se ™ N et U ti li ti fo r a se o lo ri n te rs 8849-02 Figure 2-1. The Phaser 480 and its packaging Service Manual...
Page 30: Setting Up The Printer
Setting up the printer About installing RAM SIMMs The standard conﬁguration for a Phaser 480 includes 32 Mbytes of RAM (80 nsec). Optionally, RAM can be increased to either 48 Mbytes or 64 Mbytes by installing one or both RAM SIMMs in the two RAM expansion SIMM connectors.
Page 31: Setting Rear Panel Switches
Down: No Vivid Blue Adjust. Up: Vivid Blue adjust will change the way blue is printed: it will look blue instead of purple. This feature can also be selected at the Tektronix driver. Switch 9 Down: No Press Adjust. Up: Press Adjust will change the color output to resemble printing press colors.
Page 32: Cabling The Printer
If the network features multiple zones, the network router assigns the printer a zone name. The printer’s conﬁguration page lists the name. The Section 6 topic “Printing the conﬁguration page” on page 6-19 explains printing this page. 2-10 Phaser 480 Color Printer...
Page 33: Connecting The Printer To The Pc
Installing the Printer and Drivers Connecting the printer to the PC Direct connection to the PC Turn off the printer. Turn off the PC. Attach the parallel interface cable to the host computer. Attach the other end to the printer. Alternatively, attach the serial cable to the host computer's serial port.
Page 34: Connecting The Printer To The Workstation
AAUI connector. Turn on the printer. Installing a SCSI hard disk drive on a Phaser 480 (optional) Perform this procedure if the customer has a hard disk drive available for font storage. Otherwise, continue to the next procedure.
Page 35: Figure 2-2. Connecting A Scsi Hard Disk Drive To The Phaser 480
LocalTalk® Status 8850-10 Figure 2-2. Connecting a SCSI hard disk drive to the Phaser 480 Turn on the disk drive ﬁrst, and then the printer. Refer to the Phaser 480 Drivers and Utilities Printing Reference for details on formatting the SCSI disk, controlling sys/start job ﬁles, and using the LaserWriter Utility to load fonts onto the disk drive.
Page 36: Turning On The Printer
In this message, x indicates the number of the SIMM that failed (1 or 2). Since the printer’s base memory is still working, the printer can still be used, but large images may not print, and throughput may suffer. 2-14 Phaser 480 Color Printer...
Page 37 Color settings such as ﬁnepoint enabled and blue adjust. Serial port settings Parallel port settings LocalTalk port settings EtherTalk settings TCP/IP settings Novell settings Table 2-1. Conﬁguration page settings for the Phaser 480 Parameter Description Saved Default Limits or alternate choices NVRAM...
Page 38 Installing the Printer and Drivers Table 2-1. Conﬁguration page settings for the Phaser 480 Parameter Description Saved Default Limits or alternate choices NVRAM Wait Timeout Amount of time the image processor 40 seconds Any value greater than 14 will wait for additional data from a host denoted in seconds.
Page 39 Installing the Printer and Drivers Table 2-1. Conﬁguration page settings for the Phaser 480 Parameter Description Saved Default Limits or alternate choices NVRAM EtherTalk Port Indicates the type of interpreter in use PostScript Level 2 Not installed, Disabled, interpreter at the port...
Page 40 Installing the Printer and Drivers Table 2-1. Conﬁguration page settings for the Phaser 480 Parameter Description Saved Default Limits or alternate choices NVRAM Broadcast The IP Address used to broadcast Default String of 15 or fewer Address messages on the local network. If null,...
Page 41 Installing the Printer and Drivers Table 2-1. Conﬁguration page settings for the Phaser 480 Parameter Description Saved Default Limits or alternate choices NVRAM Syslog Protocol that acts as a remote front Not Authorized, <null string> panel to the printer Log Hosts...
Page 42: Driver And Communication Setup
Chooser along with the LaserWriter 7.0.x driver. The Phaser 480 driver includes special paper sizes and TekColor color correction options. Refer to the Phaser 480 Drivers and Utilities Printing Reference for more details on the Tektronix drivers To install the Tektronix driver with system 6.0.7 or higher or 7.0 or higher...
Page 43: Installing The Tektronix Driver For Windows 3.1
2-22. If you have other Tektronix printer drivers already installed If you still have an earlier version of the Tektronix Windows driver, you can use the INSTALL.EXE program on that diskette to remove the older driver software.
Page 44: Configuring The Tektronix Windows Printer Driver
Drivers and Utilities Printing Reference to delete the ﬁles. When you are ﬁnished removing the old driver ﬁles, restart Windows. Go on to the topic “Installing the Tektronix driver” in this chapter, to install all of your Tektronix printers with the latest driver software.
Page 45 This option is only available to applications that use this Tektronix driver with Tektronix PostScript Level 2 printers, such as the Phaser 480. When this box is checked, the Compress Bitmaps option is unavailable (grayed out).
Page 46: Updating The Standard Microsoft Windows Postscript Driver
This update procedure provides printer page size information for applications within Windows using the standard driver. However, color adjustments and other PostScript Level 2 features are available only with the Tektronix Windows 3.1 driver and are not supported by the standard driver.
Page 47: Installing The Printer Driver For Os/2 Version 2
LPT2PRIN. Scroll through the printer drivers listed to locate the proper Tektronix printer driver name. If it is listed, select it, otherwise, point the cursor to any other driver listed and click the right mouse button. Click Install from the menu options.
Page 48 Landscape. One of the most likely causes of printer errors is that the document and device defaults do not properly match. Select Options and make sure that it is properly set to Phaser 480. If not, repeat the previous steps. While in this screen, set Job and Wait to 0, if they aren't already.
Page 49: Configuring The Printer's Serial Port For A Pc
Installing the Printer and Drivers Conﬁguring the printer's serial port for a PC Use the PostScript command ﬁle DEVPARAM.PS (also located on the Printers Utilities diskette) to modify the printer’s serial port settings. The following example sets ﬂow control to Xon/Xoff, parity to none, data bits to 8, stop bits to 2 and the baud rate to 9600.
Page 50 Interpreter PostScript string HP7475A Protocol Normal string Binary Use the DOS COPY command to send DEVPARAM.PS to the printer; for example: COPY DEVPARAM.PS COM1: (Substitute the appropriate port for COM1:.) 2-28 Phaser 480 Color Printer...
Page 51: Using Printcap To Configure A Workstation For The Printer's Serial Port
Installing the Printer and Drivers Using printcap to conﬁgure a workstation for the printer's serial port The printcap ﬁle conﬁgures the workstation's lpr queues. The ﬁle is usually found in the workstation's /etc. directory. The printer's rear panel switch settings should all be down.
Page 52 If communication to the serial port uses 7 data bits, the value for xs changes as follows. All other setup parameters remain the same. px:\ :br#9600:rw:\ :fc#00000374:fs#00000003:\ :xc#0:xs#0040040:\ :mx#0:sf:sh:\ :sd=/var/spool/px:\ :if=/var/spool/px/if:\ :lp=/dev/ttya: To print a PostScript ﬁle type: lpr -Ppx ﬁlename 2-30 Phaser 480 Color Printer...
Page 53: Configuring A Novell Server For The Printer
Installing the Printer and Drivers Conﬁguring a Novell server for the printer This is a brief overview of the steps you follow to conﬁgure a Novell ﬁle server and set up print queue to support the printer on a Novell network. The Network Utilities for Phaser Color Printers User Manual gives the step by step procedure you follow to perform this conﬁguration.
Page 54: Configuring Tcp/Ip On A Unix Host
(if the customer site uses lpr). AppSocket, the printer language(s) supported by the printer (if the customer site uses AppSocket). syslog, collect printer information for the network administrator. SNMP, allow the administrator to query and control the printer’s status remotely. 2-32 Phaser 480 Color Printer...
Page 55: Verifying The Printer And Host Connections
Displayed on the right side of the dialog box are a list of printers that the selected driver will print to. Select the newly installed printer Phaser 480 . (If, for example, a Phaser 480 is already on the network with the name Phaser 480, then the newly installed printer will be named Phaser 4801.)
Page 56: Printing The Directory From Macintosh
Close the Chooser by clicking on the small box in the upper-left corner of the dialog box. The Phaser 480 is now your chosen printer. You have now veriﬁed that the printer is on the network and is communicating with the Macintosh.
Page 57: Verifying That An Application Communicates To The Printer
Contact the Customer Support Hotline 1-800-835-6100. Using the Error Handler utility If the Macintosh does not print to the Phaser 480 printer, download the Tek Error Handler. Place the printer's Macintosh Printer Utilities diskette in the disk drive.
Page 58: Pc Verification
Type in a line of text such as “ THIS IS A TEST .” Click the File menu item and select Printer Setup... from the menu list. Select Phaser 480 from the displayed list of available printer drivers. Click OK .
Page 59: Os/2 Connection Verification
Verifying the Printer and Host Connections OS/2 connection veriﬁcation The Print Screen function is controlled from within the OS/2 System folder. Open the System folder, then open the System object. Click on the Print Screen Tab to view the Print Screen settings. Be sure that Enable has been selected.
Page 60: Novell Netware Verification
ﬁles created and sent for printing from other workstations on the network. The Phaser 480, in turn, ﬁnds all ﬁle servers with Phaser 480 queues and extracts the print ﬁles from them. You must determine if a station can send a print ﬁle to the ﬁle server.
Page 61: Using The Error Handler Utility
Verifying the Printer and Host Connections Using the Error Handler utility If a PC has trouble printing directly to the Phaser 480, download the Tek Error Handler utility ﬁle to the printer. The Tek Error Handler (TEKEHAND.PS) is for PostScript Level 1 and 2 printers.
Page 62: Workstation Verification
Workstation veriﬁcation Verifying and printing using the TCP/IP protocols The Phaser 480 accepts ﬁles from networked UNIX and VMS workstations using TCP/IP communications. The printer supports BSD UNIX 4.3, AT&T's UNIX System V with BSD 4.3 lpr extensions, and DEC VMS with Tektronix PhaserSym software.
Page 63 Verifying the Printer and Host Connections To print the Phaser 480 in the VMS environment, you must have the symbiont PhaserSym running on the host. To print to the printer from the host, you must ﬁrst have the printer’s queue established. This is site-dependent and requires the aid of the site’s network administrator.
Page 64: Using The Error Handler Utility
This loads the error handling utility into the printer's memory where it remains until the printer is turned off. Send a print ﬁle to the printer as explained in the previous procedure. If an error occurs, it will print a page listing the error. 3-10 Phaser 480 Color Printer...
Page 65: Key Operator Training
Chapter Key Operator Training This chapter covers the last portion of the Tektronix Service Option S0 installation: training the printer's key operator. The steps you follow here place an emphasis on encouraging the key operator to read and use the printer's user manual and to clean and care for the printer.
Page 66: Printer Controls And Indicators
Show how to reset the printer with DIP Switch 1. Explain that the functions of the Press Adjust and Blue Adjust switches. Show where the functions of the rear panel switches are explained in the user manual. Phaser 480 Color Printer...
Page 67: Loading Media
Key Operator Training Loading media Paper/transparency Demonstrate how to load paper or transparency ﬁlm into a paper tray. Emphasize to the user not to touch the printing surface of the media; handle it by the edges only. Fingerprints can affect print quality. Explain that the user should not bend the media (especially transparency ﬁlm) too sharply.
Page 68: Clearing Paper Jams
Show how you clear an exit jam. Show where this is explained in the user manual. Warranty information Review the warranty information with customers to ensure that they are aware of the printer's warranty and the duration of its coverage. Phaser 480 Color Printer...
Page 69: Supplies Ordering
Customers can call toll-free at 1-800-835-6100 (ask for the Supplies Order Desk) to place a supplies order. Open Monday through Friday, 6:00 am to 5:00 pm (PST). Shipments are made within 24 hours. Outside of the United States Contact your nearest Tektronix dealer. Service Manual...
Page 70: If You Need Help
Electronic bulletin board Tektronix supports an electronic bulletin board that users with a modem can connect to download the latest versions of Tektronix drivers and software. To connect to the BBS phone (503) 685-4504 and use 9600 baud, 8 bits, 1 stop bit, and no parity.
Page 71: Theory Of Operation
Chapter Theory of Operation Overview This chapter provides a high-level description of the sublimation dye printing technology and how the printer employs it. Following that is a high-level discussion of the image processor board and how it receives data from a host computer and transforms it into data for the print engine.
Page 72: Functional Block Diagram
Figure 5-1 is a block diagram of the printer. It illustrates how the printer is divided into two main parts: the print engine and the image processor. The following topics describe these two parts in detail. Phaser 480 Color Printer...
Page 73: Print Engine
Theory of Operation Print engine Sublimation dye transfer — the engine's printing technology To make colored prints, the print engine uses a color printing method called sequential sublimation dye transfer printing . Simply said, the print engine prints by subliming or vaporizing dots of colored dye from a Mylar® ribbon into a sheet of paper.
Page 74: Continuous-Tone Printing
The printer's image processor board must convert the data into the correct format. The following topics describe some of the data formatting that the host or the interface module must perform. Phaser 480 Color Printer...
Page 75: Creating Colors
Theory of Operation The print engine prints an image in a raster format, line by horizontal line, dot by dot. The image to be printed is “described” with the colors yellow, magenta and cyan. First the yellow raster making up the image is printed, then the magenta raster is printed, and ﬁnally, the cyan raster.
Page 76: Engine Control Board Block Description
The head controller generates variable length strobes. During printing, the strobe length is varied, based on the overall thermal head temperature and the volume of dots printed in a line. The voltage level of the pulse is ﬁxed at about 24 VDC. Phaser 480 Color Printer...
Page 77: Thermal Head
Theory of Operation Thermal head The thermal head is the device that sublimes wax dots onto the paper. It contains a row of 3584 solid-state heating elements. The actual number of elements used during a particular print depends on the paper size (A or A4, B or A3) and the image to be printed.
Page 78: The Printing Cycle
ﬁrst color panel, yellow. Transfer roll mark sensors Thermal head Pinch roller Paper feed guide Paper clamp guide Pick roller 8850-14 Figure 5-3. The printing cycle - idle Phaser 480 Color Printer...
Page 79: Paper Clamp Bar Positioning
Theory of Operation Paper clamp bar positioning As the print cycle begins, the timing belts are driven backward to position the paper clamp bar in its clamping position over the clamp actuator roller. Paper clamp bar Platen Timing belts (2) Clamp actuator roller 8850-15 Figure 5-4.
Page 80: Paper Pick
Clamp actuator roller Paper clamp sensor (clamps open) Paper guide Paper leading/trailing edge sensor Feed roller Sheet of paper Clamp paper guide 8850-16 Figure 5-5. The printing cycle - paper picking 5-10 Phaser 480 Color Printer...
Page 81: Paper Clamp
Theory of Operation Paper clamp The paper clamp sensor optically detects when paper has entered the paper clamp bar. With the paper sensed in the clamp, the clamp actuator roller is rotated so that the four spring-loaded clamps close. Paper clamp actuator Paper clamp closes Paper 8850-17...
Page 82: Paper Wrap
Note how the x-axis tensioner lifts up, via cam action, out of the way as the paper clamp bar passes underneath. Platen Axis tensioner 8850-18 Figure 5-7. The printing cycle - paper loading 5-12 Phaser 480 Color Printer...
Page 83: Print Positioning And Printing
Theory of Operation Print positioning and printing With the paper into the paper path, the paper clamp bar, pulling the sheet of paper, is shuttled to a point just in front of the thermal head. This is the print start position. The thermal head, in turn, is lowered to sandwich the transfer roll and paper between the thermal head and the platen.
Page 84: Exit Positioning
Then the paper advances in the paper path to a position that places the trailing edge of the print at the beginning of the exit path. Exit path Trailing edge 8850-20 Figure 5-9. The printing cycle - exit positioning 5-14 Phaser 480 Color Printer...
Page 85: Paper Unclamping
Theory of Operation Paper unclamping The lower exit roller then rotates to drive the print up the exit path. The print is stopped when the paper clamp bar is in its paper pick position. The clamp actuator roller then rotates to open the four clamps of the paper clamp bar. Paper clamp bar Clamp actuator roller 8850-21...
Page 86: Exiting
The rotating upper exit roller catches the print and continues to pull it through the exit path and into the output tray. Upper exit roller Lower exit roller 8850-22 Figure 5-11. The printing cycle - exiting 5-16 Phaser 480 Color Printer...
Page 87: Image Processor
Theory of Operation Image processor Image-rendering technology The image processor board handles PostScript data sent from a host computer and transforms it into a format suitable for the print engine. The hardware/software structure that performs this function is called a graphics pipeline .
Page 88: Figure 5-12. The Image Processor Graphics Pipeline
Control loop Local- LocalTalk Talk handler Serial PostScript Rasterizer Engine Print serializer interpreter driver Parallel engine SCSI Ethernet Ethernet SIMM Fonts in Image processor 8699-18 Figure 5-12. The image processor graphics pipeline 5-18 Phaser 480 Color Printer...
Page 89: Troubleshooting
Chapter Troubleshooting This chapter discusses troubleshooting the printer. Troubleshooting is discussed with two approaches: A step-by-step veriﬁcation procedure that systematically conﬁrms that particular components of the printer are properly functioning until a problem is found. A symptom/cause scheme that lists particular printer failures and error codes and their possible causes.
Page 90: Print Engine Troubleshooting
Troubleshooting Print engine troubleshooting This topic is a step-by-step procedure for systematically verifying aspects of the printer's operation. Following this procedure should help determine the cause of a printer's failure. Verifying image processor operation by using the Test Pattern Generator Instructions for using the Test Pattern Generator are provided in Appendix D “Test Pattern Generator.”...
Page 91: Verifying Print Engine Operation By Using Its Self-Test Print
Troubleshooting Verifying print engine operation by using its self-test print If not already off, turn off the printer. Remove the lower rear cover and the engine control board cover to access the engine control board. On the print engine control board, set DIP Switches 1-1 on. Set Switches 1-2, -3, -4, -5, -6, -7 and -8 off .
Page 92: Verifying Power Supply Operation
Troubleshooting Verifying power supply operation Required tools ® #1 POSIDR IV screwdriver Volt-ohm-meter (VOM) Verifying the operation of the power supply involves four steps: Measuring the input voltages Inspecting the power supply fuses Measuring AC supply voltage Turn off the printer and unplug it from its power outlet. With the VOM set to measure AC voltages, measure for power being supplied to the printer.
Page 93: Media Jams And The Paper Path
Troubleshooting Media jams and the paper path Required tools ® #1 POSIDRIV screwdriver Jams fall into the following four categories: Media-based problems Paper-picking errors Paper-clamping errors Paper-ejecting errors Media-based problems Check that the correct type of media is being used. Be sure that the printing side of the paper faces down in the tray.
Page 94: Paper-Clamping Errors
Troubleshooting Check that the pick roller is being rotated. If it is not, go to the topic “Checking the paper-feed and drive train” on page 6-7. Otherwise, go to Step 5. In their starting position, the pick rollers' ﬂat side should face down.
Page 95: Print-Eject Jams
Troubleshooting Print-eject jams Inspect the paper eject sensor. Check to see if the upper eject roller drive belt does not rotate due to a broken drive gear. In such a case, the upper roller will not rotate when the lower roller rotates. Check that the exit roller rotates smoothly.
Page 96: Printing And Print Quality Problems
Troubleshooting Printing and print quality problems Required tools ® #1 POSIDRIV screwdriver Volt-ohm - meter (VOM) Print problems fall into the following ﬁve categories: Streaks or lines in the prints No printing Printing (density) too light or too dark Image is offset or cutoff Wrinkling Misregistration Streaks or lines parallel to the long axis of printing...
Page 97: Not Printing
Troubleshooting Color is uneven The paper may be slipping in the paper clamp bar. Clean all four bar clamps. See the Chapter 7 topic “Cleaning” on page 7-1. Check the paper clamp bar’s clamping pressure by trying to pull a sheet of paper out of the closed clamps.
Page 98: Image Is Offset Or Cut Off
Troubleshooting Ensure that the thermal head fans runs during printing to keep the thermal head from overheating during printing. The fans, mounted at the rear of the top cover, blow outward. If the fans do not run, replace the print engine. If the voltage supplied to the thermal head is correct and the DIP Switch 2 setting is correct, then replace the print engine If printing still does not improve, replace the print engine.
Page 99: Problems And Solutions
Troubleshooting Problems and solutions Print engine error conditions and their causes These are the error conditions displayed in service mode and their possible causes and solutions. Table 6-1. Print engine error conditions and solutions Error Solution End of Paper Ensure that the paper tray is correctly loaded. Check the paper-out sensor and it ﬂag.
Page 100: Power Problems
Troubleshooting Power problems Table 6-2. Print engine power problems and solutions Error Solution All front panel indicators Check to see if the printer is plugged in. Check the line power remain off. fuses inside the power supply. The printer does not Check the power on/off switch.
Page 101: Macintosh Printing Problems
Table 6-4. Macintosh printing problems and solutions Error Solution Image never prints. Make sure that the correct Phaser 480 icon was selected in Printer READY light the Chooser. Try printing the job again. Ensure that the ﬂashes as if receiving printer driver “Phaser 480”...
Page 102: Pc Dos Printing Problems
Send the image ﬁle that was not printing. Any PostScript errors encountered by the printer are recorded on a printout. Call Tektronix Customer Support at 1-800-835-6100 for more assistance (save the print with the error message).
Page 103: Windows Printing Problems
(CMY), blue is often printed as purple. To adjust blue from within Microsoft Windows: Within the Tektronix PostScript Windows driver you have an option, Vivid Blue, that alters blue colors that are appearing purple. To Access this option select:...
Page 104: Workstation Printing Problems
Troubleshooting Workstation printing problems Table 6-7. Workstation printing problems and solutions Error Solution Image never prints. For communication through the serial or parallel port: Ensure Printer READY light that the print ﬁle ends with a “CTRL-D” character. CTRL-D ﬂashes as if receiving indicates the end-of-ﬁle which the printer responds to by data, but no prints are closing host-to-printer communications and then processing...
Page 105: Image Processor
Troubleshooting Image processor Image processor normal indicators There are three indications that the print engine and its image processor are powered-up and operating normally: the front panel POWER and READY indicators are on (steady) and the rear panel STATUS light is blinking. When the printer is receiving or processing data, the front panel READY light blinks.
Page 106: Image Processor Self-Diagnostics
Troubleshooting Image processor self-diagnostics Image processor rear panel switches for self-testing The image processor features four types of self-diagnostic modes. The type of self-diagnostics run depend upon the position of rear panel DIP Switches 2, 3 and 4. The switch combinations are listed here. Switch Self-diagnostic mode ↓...
Page 107: Rear Panel Switches (Diagnostics)
Troubleshooting During the veriﬁcation self-test the test results are transmitted out the serial port. Communication parameters for the serial port are 9600 baud, 8 data bits, no parity and 2 stop bits. The rear panel LED ﬂashes irregularly as the tests are executed (on for one test, off for the next).
Page 108: Resetting Nvram
Troubleshooting Resetting NVRAM Resetting NVRAM returns all the image processor's parameters to their factory defaults except the print count (processed through the image processor) and the Adobe ﬁrmware serial number. To reset the image processor to its factory default values follow this procedure: Power down the printer.
Page 109: Cleaning And Maintenance
Chapter Cleaning and Maintenance Cleaning Tools and supplies required #1 Phillips screwdriver Lint-free cloth 600 grit sandpaper 90% pure isopropyl alcohol Generally, the following three steps are performed by the user. Each time the transfer roll is replaced Wipe the line of heating elements of the thermal head with a lint-free cloth dampened with 90% isopropyl alcohol.
Page 110: Cleaning The Printer
While pressing down on the metal load lever, place the cleaning sheet on top of the paper tray cover. Press the cleaning sheet under the hooks on either side of the tray. Press the ﬂaps on the cleaning sheet into openings on the metal load lever. Phaser 480 Color Printer...
Page 111 Cleaning and Maintenance Press the ﬂaps on the cleaning sheet under the paper tray cover. 9237-05 Apply isopropyl alcohol (at least 20 drops) to the four sponges on the cleaning sheet. Use a back and forth motion for the best coverage.
Page 112 Slide the cover release again and then raise the cover. Note After making the last print, allow the thermal head to cool at least 5 minutes before cleaning because it is very hot. Phaser 480 Color Printer...
Page 113 Cleaning and Maintenance Using a lint-free cloth moistened with isopropyl alcohol, lightly wipe the full length of the thermal head, using a back and forth motion, until dust and ink are removed. Do not exert much pressure on the thermal head. Separator Bar Wipe the edge of the separator bar.
Page 114 Pinch roller — rotate with your hand (use a clean lint-free cloth). b. Platen — rotate by turning the green knob. c. Idler — rotate with your hand (use a clean lint-free cloth). 9237-10 Phaser 480 Color Printer...
Page 115 Cleaning and Maintenance Exit rollers Locate the exit rollers at the front of the Phaser 480X, behind the front panel. Hold the lint-free cloth moistened with isopropyl alcohol against the rubber segments of the roller as you turn the green knob toward the back of the printer.
Page 116 Use the black rubber belt to move the paper clamp bar. Position the paper clamp bar directly over the platen (of the three rollers, the platen is the middle, black roller). 9237-13 Dampen the small end of the cleaning pad with isopropyl alcohol. 9237-14 Phaser 480 Color Printer...
Page 117 Cleaning and Maintenance Place the wide end of the cleaning pad ( foam side down ) on the platen beneath a paper clamp. 9237-15 Gently press the clamp lever down with your ﬁnger to open the clamp. Slide the small end of the pad through the open clamp, wiping side-to-side.
Page 118 Place the transfer roll tray back into the printer; press down gently on the handles so that the endcaps click into place. 12. Close the printer cover Allow approximately 5 minutes for drying time before making prints. 13. Resume printing 7-10 Phaser 480 Color Printer...
Page 119: Lubrication
Cleaning and Maintenance Lubrication Tools and supplies required Light oil White grease order number 006-7436-00 In general, all of the printer's bearings and motors are lifetime factory lubricated. However, over time and under certain extreme operating conditions, oil and grease may dry out causing squeaks and rumbling noises. Look for ﬁne metal particles –...
Page 120: Inspecting
Clutches: Symptoms of a malfunctioning clutch are the printer not picking paper from the tray or random skewing of the print. In such cases disassemble and check inside the suspect clutch for a lack of grease, a broken spring, or worn gear teeth. 7-12 Phaser 480 Color Printer...
Page 121: Fru Disassembly/Assembly
Chapter Disassembly/Assembly This section explains how to remove and replace many of the printer's Field Replaceable Units (FRUs). This section covers procedures for FRUs that are difﬁcult to remove or require special handling or precautions. Refer to Appendix A for a list of the printer's FRUs. Required tools Magnetic tip screwdrivers;...
Page 122: The Printer Covers
Lift up on the top cover panel to disengage the top cover’s hooks from the upper mechanical unit. Reverse these steps to reinstall the top cover. Self-tap screws (M4 x 16) Top cover Hook 8849-24 Figure 8-1 Removing the top cover Phaser 480 Color Printer...
Page 123: Lower Rear Cover
FRU Disassembly/Assembly Lower rear cover Turn off the printer. Remove the power cord. Remove the two screws (M4 x 10, panhead) securing the cover in place. Pull the cover downward to unlatch it from the printer and then backwards to remove. Reverse these steps to reinstall the lower rear cover.
Page 124: Engine Control Board Cover
Rat ra lle ctio e Us Mounting screws (M3 x 7) 8850-27 Figure 8-3 Removing the engine control board cover Reverse these steps to reinstall the engine control board cover. Phaser 480 Color Printer...
Page 125: Right Side Cover
FRU Disassembly/Assembly Right side cover Turn off the printer and remove the power cord. Remove the lower rear cover as explained in the previous procedure “Lower rear cover” on page 8-3. Slide the right rear cover rearward about inch (6 mm). Lift the top edge of the cover so it clears the top cover release and pull the cover to the right to remove.
Page 126: Left Side Cover
Lifting slightly on the upper edge of the left side cover, pull the cover to the left to remove. Reverse these steps to reinstall the right rear cover. Left side cover 8849-29 Figure 8-5 Removing the left side cover Phaser 480 Color Printer...
Page 127: Front Cover
FRU Disassembly/Assembly Front cover Turn off the printer. Remove the power cord. Remove the lower rear cover as explained in the previous procedure “Lower rear cover” on page 8-3. Remove the right side cover as explained in the previous procedure “Right side cover”...
Page 128: Thermal Head
Mounting screws and washers Head springs Head support assembly mounting plate Head support Do not remove assembly these two screws Thermal head mounting plate Claw 8850-52 Disconnect the four wiring harness connected to the thermal head. Phaser 480 Color Printer...
Page 129: Thermal Head Installation
FRU Disassembly/Assembly Thermal head installation Installing the thermal head is basically the reverse of the removal steps. Connect the four wiring harnesses to the thermal head. Position the thermal head into the head support assembly. Ensure the two head springs are properly positioned into their detents in the back of the thermal head.
Page 130: Feed Roller
ﬁt together as shown. Bearing (flat key portion in Ring stopper 6 o'clock position) Feed roller Nylon washer Spring Ring stopper 8850-53 Figure 8-7 Shorting the feed roller’s ring stopper 8-10 Phaser 480 Color Printer...
Page 131: Figure 8-8 Removing The Feed Roller
FRU Disassembly/Assembly Compress the spring pushing the feed roller to the right. Caution Watch for loose parts, such as springs and bearings, in the next step; they fall out easily. While compressing the spring, lift the feed roller up and out of the printer, beginning with the left end of the roller.
Page 132: Paper Guide
Paper guide Turn off the printer. Remove the power cord. Push the top cover release to open the top cover. Remove the left-side, right-side and lower rear covers as explained in the earlier topic “The printer covers” on page 8-2. Remove the feed roller as explained in the earlier topic “Feed roller”...
Page 133: Pick Roller
FRU Disassembly/Assembly Pick roller Turn off the printer. Remove the power cord. Push the top cover release to open the top cover. Remove the left-side, right-side and lower rear covers as explained in the earlier topic “The printer covers” on page 8-2. Remove the feed roller as explained in the earlier topic “Feed roller”...
Page 134: Figure 8-11 Removing The Pick Roller
(showing a rotation). In this position, the paper pick clutch’s latch should be engaged to the catch in the end of the pick roller. 8-14 Phaser 480 Color Printer...
Page 135: Engine Control Board
FRU Disassembly/Assembly Engine control board Turn off the printer. Remove the lower rear cover as detailed in the previous procedure “Lower rear cover” on page 8-3. Remove the two screws (M3 x 7, panhead) which secure the engine control board cover in place. Disconnect the six wiring harnesses connected to the engine control board.
Page 136: Power Supply
Figure 8-13 Removing the power supply Reverse these steps to reinstall the power supply. Check the voltage output of the power supply as explained in the Chapter 9 topic “Power supply output” on page 9-2. 8-16 Phaser 480 Color Printer...
Page 137: Image Processor Board
FRU Disassembly/Assembly Image processor board Caution Before removing the image processor board, inspect the bottom of the printer. If the bottom pan is not ﬂat, but rather “caved in” it may have been bent during shipping or while being moved. Screws in the bottom pan could then scratch and damage the image processor board as it is being removed.
Page 138: Ram Simm
When properly inserted, a tab on each end of the connector slips into a hole on each end of the SIMM. Also, a pawl on each end of the connector latches around each end of the SIMM to lock it in place. 8-18 Phaser 480 Color Printer...
Page 139: Figure 8-15 Installing Ram Simm
FRU Disassembly/Assembly Do not insert a RAM SIMM in the Ethernet card connector J30. It could be damaged upon power-up. 8850-32 Figure 8-15 Installing RAM SIMM Reinsert the image processor board into the printer. Turn on the printer and print a start page. It lists the installed memory. Service Manual 8-19...
Page 140: Ethernet Card
8850-33 Figure 8-16 Installing the Ethernet card Reinstall the image processor board in the printer. Turn on the printer and print a start page. It lists the installed Ethernet option. 8-20 Phaser 480 Color Printer...
Page 141: Enabling Tcp/Ip With The Downloadable Authorization Code
FRU Disassembly/Assembly Enabling TCP/IP with the downloadable authorization code When the Ethernet card is installed, the EtherTalk and Novell protocols are immediately active. The Ethernet card’s TCP/IP protocol must be activated by a downloadable authorization code, sometimes referred to as its software key. The authorization code is printed on a certiﬁcate included with the printer (if the option was factory installed) or with the ﬁeld upgrade kit.
Page 143: Checks And Adjustments
Chapter Checks and Adjustments This chapter contains the procedures to calibrate the printer after you replace key Field Replaceable Units. It also contains procedures to let you evaluate the printer's functionality. Finally, this chapter lists a series of steps you can follow to inspect and clean the printer you are servicing.
Page 144: Power Supply Output
® D ia S ta rt jo 8849-34 B au r a ll ri a at e b le C ol Figure 9-1. Preparing the power supply for +24V adjustment Phaser 480 Color Printer...
Page 145: Figure 9-2 Connecting The Voltmeter
Checks and Adjustments Connect the positive lead of the voltmeter to pin 5 of J11 (+24 V). Connect the negative lead to pin 6 of J11 (GND). +24 V adjustment trimmer Connector J11 Pin No.5 (+24 V) ( a ) Pin No 6 (GND) t I n s t a...
Page 146: Figure 9-3 Adjusting +24V
(2 4. -0 11 8850-36 Figure 9-3. Adjusting +24V After you make the adjustment, remove the voltmeter and turn off the printer. Flip DIP Switch 1-7 and 1-8 down . Reconnect CN4 and CN5. Reinstall the covers. Phaser 480 Color Printer...
Page 147: Adjusting The +5 Vdc Output
Checks and Adjustments Adjusting the +5 VDC output Turn off the printer. Remove the top cover and the upper and lower rear covers as detailed in the Section 8 procedure “The printer covers” on page 8-2. Remove the engine control board cover which is held in place by two screws (M3 x 7, panhead).
Page 148: Adjusting For Color Misregistration
Remove the engine control board cover which is held in place by two screws (M3 x 7, panhead). Print a registration test print as explained in the Chapter 6 topic “Verifying print engine operation by using its self-test print” on page 6-3. Phaser 480 Color Printer...
Page 149: Figure 9-5 Inspecting The Test Print For Misregistration
Checks and Adjustments Examine the crosshairs in the corners of the print for misregistration. Look for vertical bars of cyan out of alignment (shifted left or right, short axis of paper) with the yellow bar. The distance cyan is misaligned to yellow is referred to as X1. The distance cyan is misaligned to the right of yellow is referred to as X2.
Page 150: Adjustment For X1 Or X2 Misalignment
Figure 9-7. For X1 misalignment insert the gap gauge into the gap to the left of the ﬁxing plate and the cross member it is attached to. Gap gauge Assembly middle base F2 fixing plate 8850-40 Figure 9-7. Inserting the gap gauge Phaser 480 Color Printer...
Page 151: Figure 9-8 Adjusting For X2 Misregistration
Checks and Adjustments Yellow Cyan To reduce X misregistration, add to the thickness of the gap gauge 8850-42 Figure 9-8. Adjusting for X2 misregistration Holding the ﬁxing plate against the gap gauge, tighten the set screw. Remove the gap gauge. Print out another test print and examine it for misregistration.
Page 152: Vertical Misregistration
Y2, shorten the yellow printing. In the case of the test print, the horizontal lines are about 0.2 mm thick. Upside of a sheet of paper Cyan Yellow Cyan 8850-43 Figure 9-10. Vertical misregistration 9-10 Phaser 480 Color Printer...
Page 153: Figure 9-11 Vertical Registration Adjustment
Checks and Adjustments Adjust the setting of DIP Switch 2 on the engine control board to lengthen or shorten the yellow printing on paper as indicated in the table below. To adjust vertical misregistration on transparency ﬁlm, lengthen or shorten the yellow printing as indicated in Table 9-1, “DIP Switch 2 — Adjusting vertical misregistration on paper,”...
Page 154 Checks and Adjustments Table 9-2. DIP Switch 2 — Adjusting vertical misregistration on transparency ﬁlm Dip Switch 1 Length of yellow color Shorten Lengthen 9-12 Phaser 480 Color Printer...
Page 155 Appendix Field Replaceable Units List This appendix provides a list of ﬁeld replaceable units for the Phaser 480 and Phaser 480X color printers. Changes to Tektronix instruments are made to accommodate improved components as they become available. It is important when ordering parts to include the following information: Component's part number.
Page 156: Table A-1 Fru Parts List
A-1 20 118-9257-00 PAPER PICK ROLLER A-1 21 118-9256-00 PAPER FEED ROLLER A-1 22 118-9225-00 PAPER GUIDE, GRAY PLASTIC A-1 23 118-9232-00 PAPER GUIDE HOLDERS, WHITE PLASTIC A-1 24 118-9226-00 PLATEN ROLLER A-1 25 118-9231-00 PAPER CLAMP Phaser 480 Color Printer...
Page 157: Figure A-1 The Printer Frus
Field Replaceable Units List . 99- T NO 8850-45A Figure A-1. The printer FRUs Service Manual...
Page 158: Table A-2 Supplies And Accessories
070-8849-30 USER MANUAL (GERMAN) 070-8849-40 USER MANUAL (SPANISH) 070-8850-01 SERVICE MANUAL 070-8851-00 PRINTER TOOLS REFERENCE MANUAL/SW 070-8901-00 NETWORK UTILITIES MANUAL/SW 063-1652-01 PHASER 480 DRIVERS AND UTILITES SOFTWARE 065-0546-00 SHIPPING CARTON KIT 650-3358-00 INTERNAL SHIPPING BLOCKS KIT 067-1433-99 TEST PATTERN GENERATOR...
Page 159: Test Pattern
Appendix Test Pattern Top of Bottom of print print Figure B-1. Inspection/check test pattern This appendix illustrates the test pattern produced by the print engine. It also illustrates horizontal and vertical misconvergence. Horizontal misconverg- ence is misconvergence parallel to the printhead. Vertical misconvergence is misconvergence in the direction the paper travels through the paper path.
Page 160 Index conﬁguring a Novell server for the printer 2-31 conﬁguring TCP/IP 2-32 adjusting for color misregistration 9-6 connecting the printer to the Macintosh 2-10 adjusting the +5 VDC output 9-5 connecting the printer to the PC 2-11 adjusting the printhead voltage 9-2 connecting the printer to the workstation 2-11 antistatic mat 8-1 continuous-tone printing 5-4...
Page 161 2-29 HAL information system 4-6 OS/2 connection veriﬁcation 3-5 health LED 1-8 OS/2 Version 2, Tektronix driver 2-25 Highly Automated Library (HAL) 2-4 OS/2 Version 2.0, loading drivers 2-25 horizontal misregistration, adjusting for 9-6 paper clamp bar 7-8...
Page 162 printer theory of operation 5-1 RAM SIMM troubleshooting 6-1 installing 8-18 printer assemblies, internal and external 1-4 rear panel 1-7 printer clearances 1-11 description 1-7 printer covers, removing 8-2 switches 7-4 printer inventory 2-6 rear panel switches printer page description ﬁle 3-3 default settings 2-9 printhead regulatory standards 1-14...
Page 163 Standard Windows PostScript driver white portion of print is colored 6-8 updating 2-24 Windows 3.1 driver veriﬁcation 3-4 start-up ﬁle 1-9 Windows 3.1, Tektronix driver 2-21 startup page 2-14 Windows printer driver streaks or lines in print 6-8 conﬁguring 2-22...
Page 164: Wiring Diagrams
Appendix Wiring Diagrams Figure C-1 illustrates a wiring diagram of the printer. Cover open sensor Thermal head unit (Left) (Right) Step motor L Step motor R 24 V(b) 24 V(a) Pick solenoid 24 V(a) Clutch F Power supply Driver Clutch 24 V(b) card gear-49...
Page 165: Figure C-2 Wiring Routing Diagram
Wiring Diagrams Figure C-2 illustrates a wiring routing diagram of the printer. 8850-47 Figure C-2 Wiring routing diagram Phaser 480 Color Printer...
Page 166: Table Of Contents
Connecting the printer to the workstation 2-12 Direct connection to the workstation 2-12 Networked connection to the workstation 2-12 Installing a SCSI hard disk drive on a Phaser 480 (optional) 2-12 Turning on the printer 2-14 The startup page 2-14...
Page 167 Driver and communication setup 2-20 Loading the Macintosh driver 2-20 Installing the Tektronix driver for Windows 3.1 2-21 If you have other Tektronix printer drivers already installed 2-21 Configuring the Tektronix Windows printer driver 2-22 Updating the standard Microsoft Windows PostScript driver 2-24...
Page 168 Theory of Operation Overview 5-1 Functional block diagram 5-2 Print engine 5-3 Sublimation dye transfer — the engine's printing technology 5-3 The print process 5-3 Continuous-tone printing 5-4 Image data 5-4 Creating colors 5-5 Engine control board block description 5-6 CPU 5-6 Interface buffers 5-6 Thermal Head controller 5-6...
Page 169 Image processor hard and soft error indicators 6-17 Verifying the image processor's operation 6-17 Image processor self-diagnostics 6-18 Image processor rear panel switches for self-testing 6-18 Printing the configuration page 6-19 Rear panel switches (diagnostics) 6-19 Resetting NVRAM 6-20 viii Phaser 480 Color Printer...
Page 170 Cleaning and Maintenance Cleaning 7-1 Cleaning the printer 7-2 Lubrication 7-11 Inspecting 7-12 FRU Disassembly/Assembly Required tools 8-1 The printer covers 8-2 Top cover 8-2 Lower rear cover 8-3 Engine control board cover 8-4 Right side cover 8-5 Left side cover 8-6 Front cover 8-7 Thermal head 8-8 Thermal head installation 8-9...
Page 171 Field Replaceable Units List Test Pattern Wiring Diagram Test Pattern Generator Shipping the Printer Index Phaser 480 Color Printer...
Page 172 The front panel 1-10 Figure 2-1. The Phaser 480 and its packaging 2-7 Figure 2-2. Connecting a SCSI hard disk drive to the Phaser 480 2-13 Figure 5-1. Functional block diagram 5-2 Figure 5-2. The dye sublimation print process 5-4 Figure 5-3.
Page 173 Figure A-1 The printer FRUs A-3 Figure C-1 Interconnect wiring diagram C-1 Figure B-1 Inspection/check test pattern B-1 Figure C-2 Wiring routing diagram C-2 Figure D-1 Plugging the Test Pattern Generator into the printer's parallel port D-2 Phaser 480 Color Printer...
Page 174 Tables Table 1-1 Phaser 480X capabilities with increases in RAM 1-2 Table 1-2 Normal operation — Phaser 480 rear panel DIP switches 1-9 Table 1-3 Physical dimensions 1-11 Table 1-4 Printer clearances 1-11 Table 1-5 Functional specifications 1-12 Table 1-6...
Page 176: Test Pattern Generator
The Test Pattern Generator contains PostScript commands to start test patterns for a number of Tektronix color printers. It allows you to test a printer as if it was receiving a ﬁle from a host computer. In most cases, the test patterns are generated by the printer's image processor and then printed by the print engine.
Page 177: Figure D-1 Plugging The Test Pattern Generator Into The Printer's Parallel Port
To use the Test Pattern Generator, follow this procedure: Select a test pattern using the Test Pattern Generator's ﬁve DIP switches. Table D-1 lists the available test patterns for the Phaser 480. Plug the Test Pattern Generator into the printer's parallel port. You do not have to turn the printer off;...
Page 178 Additionally, the Test Pattern Generator lets you set up a printer for printing from a 4511A Network Interface. To do so, just select the appropriate DIP switch setting. Table D-1. Test Pattern Generator DIP Switch settings Phaser 480 Pattern or function 7 vertical color bars...

This manual is also suitable for:

Phaser 480x

Tektronix Phaser 480 Service Manual

1 General Information

2 Installing the Printer and Drivers

Verifying the Printer and Host Connections

Key Operator Training

5 Theory of Operation

Troubleshooting

7 Cleaning and Maintenance

8 FRU Disassembly/Assembly

9 Checks and Adjustments

Quick Links

Service Manual

Color Printers

Troubleshooting

Related Manuals for Tektronix Phaser 480

Summary of Contents for Tektronix Phaser 480
