Pacific hydrostar 6.5 hp pressure washer

Advertisement

6.5 HP Pressure wasHer
set uP, OPerating, and servicing
distributed exclusively by Harbor Freight tools
visit our website at: http://www.harborfreight.com
read this material before using this product.
Failure to do so can result in serious injury.
save tHis ManuaL.
©
Copyright
2008 by Harbor Freight Tools
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
rev 09c, 09e, 11h
Model
instructiOns
3491 Mission Oaks Blvd., Camarillo, CA 93011
®
. All rights reserved. No portion of this manual or any artwork
65078
danger
using an engine indoors can KiLL YOu in
Minutes.
engine exhaust contains carbon monoxide.
this is a poison you cannot see or smell.
never use inside
a home or garage,
even iF doors and
windows are open.
Only use Outside
and far away from
windows, doors, and
vents.
®
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 65078 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pacific hydrostar 65078

  • Page 1 6.5 HP Pressure wasHer Model 65078 set uP, OPerating, and servicing instructiOns danger using an engine indoors can KiLL YOu in Minutes. engine exhaust contains carbon monoxide. this is a poison you cannot see or smell. never use inside Only use Outside...
  • Page 2: Table Of Contents

    PuMP Parts List ......23 PuMP diagraM ......24 cYLinder Head Parts List & diagraM ........25 cranKcase Parts List & diagraM ........26 cranKcase cOver Parts List and diagraM ..... 27 Page 2 For technical questions, please call 1-800-444-3353. SKU 65078...
  • Page 3: Important Safety Information

    Set up and use only on a flat, level, hazardous situation which, if well-ventilated surface. not avoided, could result in minor or moderate injury. SKU 65078 For technical questions, please call 1-800-444-3353. Page 3...
  • Page 4: Operating Precautions

    Tools for your model. Accessories monoxide. This is a poison you that may be suitable for one piece of cannot see or smell. equipment may become hazardous when used on another piece of equipment. Page 4 For technical questions, please call 1-800-444-3353. SKU 65078...
  • Page 5 Use the equipment, accessories, etc., Many accidents are caused by poorly in accordance with these instructions maintained equipment. and in the manner intended for the SKU 65078 For technical questions, please call 1-800-444-3353. Page 5...
  • Page 6: Service Precautions

    Before service, maintenance, or to the hands, arms and shoulders. To cleaning: reduce the risk of vibration-related turn the engine switch to its injury: “OFF” position. Page 6 For technical questions, please call 1-800-444-3353. SKU 65078...
  • Page 7 Harbor Freight Tools for a replacement. save tHese If water is leaking out of the Pressure instructiOns. Washer immediately turn off the unit. Unplug the Pressure Washer, SKU 65078 For technical questions, please call 1-800-444-3353. Page 7...
  • Page 8: Basic Specifications

    Harbor Pull the Collar at the end of the hose Freight Tools at 1-800-444-3353 as soon back and attach the Gun (19) to the as possible. hose. rev 09c Page 8 For technical questions, please call 1-800-444-3353. SKU 65078...
  • Page 9 Pressure Washers. The Pressure Washer will draw one gallon of detergent for every seven gallons of water. Only use the Black (low pressure) Nozzle when spraying detergents. SKU 65078 For technical questions, please call 1-800-444-3353. Page 9...
  • Page 10: Engine Diagram

    Page 10 For technical questions, please call 1-800-444-3353. SKU 65078...
  • Page 11: Operating Instructions

    If the oil level is low, add the Then replace the Fuel Filler Cap. appropriate type of oil until the oil rev 09c; 09d SKU 65078 For technical questions, please call 1-800-444-3353. Page 11...
  • Page 12: Equipment Operation

    “RUN” position. Choose the Nozzle that best meets the needs of the job. Only use the rev 09h Page 12 For technical questions, please call 1-800-444-3353. SKU 65078...
  • Page 13 Nozzles). Spray at a of children’s reach according to the distance of about three to five feet. Storage instructions in this manual. SKU 65078 For technical questions, please call 1-800-444-3353. Page 13...
  • Page 14: Technical Specifications

    ANSI-approved safety vibration, or excess smoking goggles, NIOSH-approved dust occurs, have the problem mask/respirator, and heavy-duty corrected before further use. work gloves. In a well-ventilated Page 14 For technical questions, please call 1-800-444-3353. SKU 65078...
  • Page 15 Gasket-style: Finger-tighten until the dissipate. to prevent Fire, do not gasket contacts the cylinder head, start the engine while the smell of then about 1/2-2/3 turn more. SKU 65078 For technical questions, please call 1-800-444-3353. Page 15...
  • Page 16: Cleaning, Maintenance, And Lubrication Schedule

    Replace fuel filter (if equipped). revolutions when you feel the piston start the compression stroke (when after every 100 Operation Hours: you start to feel resistance). Replace spark plug. Replace air filter element. Page 16 For technical questions, please call 1-800-444-3353. SKU 65078...
  • Page 17 SKU 65078 For technical questions, please call 1-800-444-3353. Page 17...
  • Page 18: Troubleshooting

    Engine valves or tappets Adjust valve clearance. If that does misadjusted or stuck. not work, clean or replace valves/ tappets. Follow all safety precautions whenever diagnosing or servicing the equipment or engine. Page 18 For technical questions, please call 1-800-444-3353. SKU 65078...
  • Page 19 Check water supply hose for kinks, leaks, or blockage. Not enough water supply. Open water faucet all the way. Follow all safety precautions whenever diagnosing or servicing the equipment or engine. SKU 65078 For technical questions, please call 1-800-444-3353. Page 19...
  • Page 20 ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. Page 20 For technical questions, please call 1-800-444-3353. SKU 65078...
  • Page 21: Parts Lists And Diagrams

    If product has no serial number, record month and year of purchase instead. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 65078 For technical questions, please call 1-800-444-3353. Page 21...
  • Page 22: General Assembly Diagram

    09e Page 22 For technical questions, please call 1-800-444-3353. SKU 65078...
  • Page 23: Pump Parts List

    Inlet Swivel Nut Ball Clip Ring Cone Spring Water Filter When ordering replacement parts from this list, the “A” suffix must be included in order to get the correct part. SKU 65078 For technical questions, please call 1-800-444-3353. Page 23...
  • Page 24: Pump Diagram

    Pump diagram Page 24 For technical questions, please call 1-800-444-3353. SKU 65078...
  • Page 25: Cylinder Head Parts List & Diagram

    When ordering parts for this component use the suffix “B”. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 65078 For technical questions, please call 1-800-444-3353. Page 25...
  • Page 26: Crankcase Parts List & Diagram

    When ordering parts for this component use the suffix “C”. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Page 26 For technical questions, please call 1-800-444-3353. SKU 65078...
  • Page 27: Crankcase Cover Parts List And Diagram

    When ordering parts for this component use the suffix “D”. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 65078 For technical questions, please call 1-800-444-3353. Page 27...
  • Page 28: Crankshaft/Piston Parts List & Diagram

    When ordering parts for this component use the suffix “E”. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Page 28 For technical questions, please call 1-800-444-3353. SKU 65078...
  • Page 29: List & Diagram

    When ordering parts for this component use the suffix “F”. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 65078 For technical questions, please call 1-800-444-3353. Page 29...
  • Page 30: Starter Subassembly Parts List & Diagram

    When ordering parts for this component use the suffix “G”. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Page 30 For technical questions, please call 1-800-444-3353. SKU 65078...
  • Page 31: Diversion Assembly Parts List & Diagram

    When ordering parts for this component use the suffix “H”. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 65078 For technical questions, please call 1-800-444-3353. Page 31...
  • Page 32: Carburetor Parts List & Diagram

    Drain Bolt Gasket Carburetor Packing Fuel Strainer Cup Carburetor Insulation Fuel Strainer Cup Packing Packing Fuel Packing Throttle Valve Lever note: When ordering parts for this component use the suffix “J”. Page 32 For technical questions, please call 1-800-444-3353. SKU 65078...
  • Page 33: Flywheel/Coil Assembly Parts List & Diagram

    When ordering parts for this component use the suffix “K”. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 65078 For technical questions, please call 1-800-444-3353. Page 33...
  • Page 34: Control System Parts List & Diagram

    When ordering parts for this component use the suffix “M”. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Page 34 For technical questions, please call 1-800-444-3353. SKU 65078...
  • Page 35: Air Cleaner Parts List & Diagram

    When ordering parts for this component use the suffix “N”. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 65078 For technical questions, please call 1-800-444-3353. Page 35...
  • Page 36: Muffler Parts List & Diagram

    You are responsible for shipping your engine to a HFT warranty station as soon as a problem exists. Contact the HFT Customer Service department at the number below to make shipping arrangements. The warranty repairs should REV 11h Page 36 For technical questions, please call 1-800-444-3353. SKU 65078...
  • Page 37: Fuel Tank Parts List & Diagram

    The owner is responsible for commissioning a qualified technician/ mechanic to perform all required maintenance, as outlined in the Inspection, Cleaning, and Maintenance section in this manual. SKU 65078 For technical questions, please call 1-800-444-3353. Page 37...
