[MAIN UNIT]
REF
ORDER
NO.
NO.
J1*
6510027480 S12B-ZR-SM4A-TF (LF) (SN)
J2*
6510027490 S11B-ZR-SM4A-TF (LF) (SN)
J3*
6510020081 52808-2071 (2090)
J5*
6510022472 40FLT-SM2-TB (LF) (SN) (M)
J6*
6510025270 S6B-PH-SM4-TB (LF) (SN)
J7*
6510023861 S9B-ZR-SM4A-TF (LF) (SN)
J8*
6510022472 40FLT-SM2-TB (LF) (SN) (M)
J9*
6510024111 52793-2070 (2090)
J10*
6510027500 S11B-PH-SM4-TB (LF) (SN)
J11*
6510024111 52793-2070 (2090)
J12*
6510027460 52793-3070
J13*
6510019371 B3B-ZR-SM4-TF (LF) (SN)
J1122*
6510019971 52808-1071
J3201*
6510018450 TMP-S01X-B1
J3202*
6510018450 TMP-S01X-B1
J3203*
6510018301 S2B-ZR-SM4A-TF (LF) (SN)
J3204*
6510023801 S4B-ZR-SM4A-TF (LF) (SN)
J3621*
6510018450 TMP-S01X-B1
J3671*
6510018450 TMP-S01X-B1
J3911*
6510018450 TMP-S01X-B1
J6001*
6510025540 AXK724127G
J6002*
6510023861 S9B-ZR-SM4A-TF (LF) (SN)
MP2001 8510019780 3183 A-MAIN CASE
MP2002 8510019790 3183 B-MAIN CASE
MP2003 8930081481 INSULATION SHEET (IA)-1
MP4001* 8510019900 3183 A-MAIN PLATE Y1200
MP5001* 8930083230 3183 C-MAIN PLATE Y1240
MP5005* 8930065741 2590 D-EARTH SPRING-1
[CONNECT UNIT]
REF
ORDER
NO.
NO.
J101*
6510023720 LGY6501-0600C
J102*
6510023720 LGY6501-0600C
J151*
6510018961 B2B-PH-SM4-TB (LF) (SN)
J611*
6510023720 LGY6501-0600C
J751*
6510026540 UBB-4R-D14T-4D (LF) (SN)
J851*
6510027740 HSJ2462-010010
J1001*
6510022472 40FLT-SM2-TB (LF) (SN) (M)
J1002*
6510027040 B12B-PH-SM4-TB (LF) (SN)
J1003*
6510021261 B9B-ZR-SM4-TF (LF) (SN)
J1101*
6450001641 TCS5044-0141177
J1201*
6450001841 TCS7568-4320177
J1301*
6510023900 LGR4619-7000
J1401*
6450001130 JPJ2042-01-110
MP751* 8930083220 3182 JACK SPRING
8930083220 3182 JACK SPRING
8930083220 3182 JACK SPRING
8930083220 3182 JACK SPRING
8930083220 3182 JACK SPRING

[PLL UNIT]

REF
ORDER
NO.
NO.
J1*
6510022472 40FLT-SM2-TB (LF) (SN) (M)
J81*
6510019991 52808-2271 (2291)
J501*
6510028210 SJ050010 (TMP-J01X-V6)
J571*
6510028210 SJ050010 (TMP-J01X-V6)
J601*
6510028210 SJ050010 (TMP-J01X-V6)
J701*
6510028210 SJ050010 (TMP-J01X-V6)
J851*
6510028210 SJ050010 (TMP-J01X-V6)
J852*
6510028210 SJ050010 (TMP-J01X-V6)
J1171*
6510028210 SJ050010 (TMP-J01X-V6)
J1281*
6510028210 SJ050010 (TMP-J01X-V6)
J1301*
6510028210 SJ050010 (TMP-J01X-V6)
J1701*
6510028210 SJ050010 (TMP-J01X-V6)
J1801*
6510028210 SJ050010 (TMP-J01X-V6)
J1901*
6510028210 SJ050010 (TMP-J01X-V6)
W351
7030011280 J1/4ZC
W361
7030011280 J1/4ZC
W1051
7030011280 J1/4ZC
W1061
7030011280 J1/4ZC
EP151* 6910002161 CASE-BM7H-LF
EP354* 6910002161 CASE-BM7H-LF
EP1054* 6910002161 CASE-BM7H-LF
MP291* 8510019980 3183 B-VCO CASE Y1205
MP292
8510019990 3183 B-VCO COVER Y1206
MP293
8810008490 SETSCREWH M2.6X 8 NI
MP351* 8510019110 3073 PLL CASE Y1140
MP352* 8930025070 SPONGE (CW)
MP353* 8930001181 EARTH SPRING-1 (FX-22)
MP411* 8510006810 DC-DC CASE FX859
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection
Screw abbreviations
DESCRIPTION
DESCRIPTION
[EUR]
[EUR-01]
[ITR]
[ESP]
[FRA]
DESCRIPTION
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[PLL UNIT]
REF
ORDER
QTY.
NO.
NO.
MP661* 8510019800 3183 FILTER CASE Y1191
1
MP671* 8930065741 2590 D-EARTH SPRING-1
1
MP701* 8510013140 2241 DC-A CASE
1
MP702* 8510005351 637 VCO SHIELD PLATE-1
1
MP703* 8930078840 SHIELD SPONGE (CM)
1
MP1051* 8510019110 3073 PLL CASE Y1140
1
MP1054* 8930050240 1632 PLL SPLING Y472
1
MP1060* 8930058170 SHIELD SPONGE (O)
1
MP1101* 8510012310 2157 DBM CASE
1
MP1171* 8930063970 SHIELD SPONGE (AM)
1
MP1172* 8510019880 3183 PLL CASE Y1197
1
MP1201* 8510018870 2355 C-SHIELD CASE Y1088
1
MP1202* 8930050240 1632 PLL SPLING Y472
1
MP1231* 8510018870 2355 C-SHIELD CASE Y1088
1
MP1232* 8930057931 SHIELD SPONGE (M)-1
1
MP1501* 8510013140 2241 DC-A CASE
1
MP1502* 8510005351 637 VCO SHIELD PLATE-1
1
MP1503* 8930063970 SHIELD SPONGE (AM)
1
MP1504* 8930078840 SHIELD SPONGE (CM)
1
MP1881* 8930065741 2590 D-EARTH SPRING-1
1
MP2001* 8510013140 2241 DC-A CASE
1
MP2002* 8510005351 637 VCO SHIELD PLATE-1
1
MP2003* 8930078840 SHIELD SPONGE (CM)
MP2004* 8930058510 INSULATION SHEET HC
1
MP2005* 8930058510 INSULATION SHEET HC
1
MP2006* 8930076750 RUBBER SHEET (CC)
1
MP2007* 8930043300 RUBBER SHEET (AG)
1
MP2008* 8930053940 RUBBER SHEET (AV)
1
1
[RF-A UNIT]
REF
ORDER
NO.
NO.
QTY.
J301*
6510020081 52808-2071 (2090)
J451*
6510019991 52808-2271 (2291)
1
J501*
6510028210 SJ050010 (TMP-J01X-V6)
1
J701*
6510028210 SJ050010 (TMP-J01X-V6)
1
J741*
6510028210 SJ050010 (TMP-J01X-V6)
1
J801*
6510028210 SJ050010 (TMP-J01X-V6)
1
J931*
6510027650 AXN480C330P
1
J951*
6510027660 AXN380C038P
1
J1011*
6510028210 SJ050010 (TMP-J01X-V6)
1
J1141*
6510028210 SJ050010 (TMP-J01X-V6)
1
J1301*
6510014961 B2B-ZR-SM4-TF (LF) (SN)
1
1
EP911* 6910002161 CASE-BM7H-LF
1
EP913* 6910002161 CASE-BM7H-LF
1
MP651* 8510012400 2177 D/A CASE Y454
1
MP701* 8930024170 EARTH SPRING (G) Y072
1
MP702* 8930081180 3183 RF-A SPRING Y1199
1
MP911* 8930065741 2590 D-EARTH SPRING-1
1
MP1071* 6910001130 10MSHIELD CASE (P10L-A)
1
MP1101* 8510012400 2177 D/A CASE Y454
MP1121* 8510015900 2590 M-2LO CASE Y697
MP1201* 8510012400 2177 D/A CASE Y454
MP1701* 8510010760 1876 DDS CASE
MP1702* 8510010770 1876 DDS COVER
QTY.
[RF-B UNIT]
1
1
REF
ORDER
1
NO.
NO.
1
1
J1*
6510020001 52808-3071 (3090)
1
J52*
6510019981 52808-1671 (1690)
1
J101*
6510014961 B2B-ZR-SM4-TF (LF) (SN)
1
J201*
6510028210 SJ050010 (TMP-J01X-V6)
1
J381*
6510028210 SJ050010 (TMP-J01X-V6)
1
J501*
6510019371 B3B-ZR-SM4-TF (LF) (SN)
1
J601*
6510028210 SJ050010 (TMP-J01X-V6)
1
J1351*
6510028210 SJ050010 (TMP-J01X-V6)
1
J1491*
6510028210 SJ050010 (TMP-J01X-V6)
1
J1751*
6510028210 SJ050010 (TMP-J01X-V6)
J2351*
6510028210 SJ050010 (TMP-J01X-V6)
1
J2491*
6510028210 SJ050010 (TMP-J01X-V6)
1
1
EP731
6910002161 CASE-BM7H-LF
1
EP732
6910002161 CASE-BM7H-LF
EP1051 6910002161 CASE-BM7H-LF
1
1
MP211* 8510015900 2590 M-2LO CASE Y697
1
MP212* 8930057931 SHIELD SPONGE (M)-1
MP213* 8930070580 SHIELD SPONGE (BA)
1
MP214* 8510002280 VCO SHIELD (A) FX 15
1
8510002280 VCO SHIELD (A) FX 15
2
8510002280 VCO SHIELD (A) FX 15
1
8510002280 VCO SHIELD (A) FX 15
1
8510002280 VCO SHIELD (A) FX 15
1
MP251
8510012400 2177 D/A CASE Y454
1
6 - 2
DESCRIPTION
QTY.
DESCRIPTION
QTY.
DESCRIPTION
QTY.
[USA]
[TPE]
[KOR]
[CHN]
[EXP]
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
