• PLL UNIT
DDS-A
(IC702)
DDS-B
(IC1502)
SERIAL-PARALLEL
CONVERTER
(IC1402)
SERIAL-PARALLEL
CONVERTER
(IC103)
SERIAL-PARALLEL
CONVERTER
(IC104)
SERIAL-PARALLEL
CONVERTER
(IC1401)
1ST TX/RX LO FILTER
(FI401)
ANALOG SW
(IC1454)
PROGRAMMABLE CLOCK GENERATOR
(IC662)
2 - 5
32 MHz REFERENCE
FREQUENCY
OSCILLATOR
(X151)
PLL IC
(IC201)
LEVEL CONVERTOR
(IC1054)
LEVEL CONVERTOR
(IC1053)
DDS B
(IC1051)
ANALOG SW
(IC1455)
