+12 V REGULATOR
(IC841)
POWER AMP (UHF BAND)
(Q402)
POWER AMP (UHF BAND)
(Q401)
D/A CONVERTER
(IC931)
POWER AMP (UHF BAND)
• PA-B UNIT
BIAS CONTROLLER
(IC552)
YGR AMP
(Q171)
PRE-DRIVE AMP
(Q201)
POWER AMP (UHF BAND)
BIAS CONTROLLER
(IC551)
2 - 7
POWER AMP (VHF BAND)
(Q701)
POWER AMP (VHF BAND)
(Q702)
DRIVE AMP
(Q251)
