Technical Manual
SVA1600

SPECIFICATIONS

ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance:
• Max Amp Power:
• Frequency Range:
• Sensitivity:
• Crossover Frequency:

SYSTEM COMPONENTS:

• Cabinet:
• Grille:
• Low Frequency
Transducer:
DC Resistance:
• High Frequency
Transducer:
DC Resistance:

PACKAGE

Warranty Card 331994-001
Survey Card 331384-001
Owner's Manual 332382-001
Carton
332378-001
8 ohms
200W
50 Hz – 18 kHz (±2 dB)
38 Hz – 18 kHz (–6 dB)
89 dB SPL, 1 Watt @ 1 Meter
1750 Hz
SVA1600 Cabinet (Not For Sale)
332385-001 (2 Pcs)
5 in. (130mm) Cone
Transducer (332206-001)
11.0 ohm ±10%
1 in. (25mm) Cloth Dome
Shielded (331393-001)
5.6 ohm ±10%
End Pad, Top
332364-001
Fibercloth
72298-01
End Pad, Bottom
332379-001
JBL Consumer Products Inc., 250 Crossways Park Dr., Woodbury, New York 11797
SYSTEM COMPONENTS:
• Crossover Network:

AURAL SWEEP TEST SPECIFICATIONS:

A. System Aural Sweep Test:
B. L.F. Aural Sweep Test:
C. H.F. Aural Sweep Test:

PHYSICAL SPECIFICATIONS:

• Enclosure Dimensions:

WEIGHT:

WARRANTY INFORMATION:

• Refer to the Warranty Statement packed with each product.

WIRING DIAGRAM

Driver,
High Freq
331393-001
YEL/BLK
Driver,
Low Freq (2)
332206-001
WHT
WHT/BLK
SCHEMATIC SVA1600
RED
+
L1
2.0 mH
INPUT
C2
LOWER
0.01µF
TERMINALS
BLK
R3
C3
3.9Ω
3.0µF
5W
ORG
+
+2 dB
FLAT
C4
INPUT
0.01µF
R4
UPPER
30Ω
TERMINALS
5W
ORG/BLK
+
DENOTES CONE MOVEMENT WITH POSITIVE VOLTAGE TO RED INPUT TERMINAL.
NOTE: CONE/DIAPHRAGM KIT NOT AVAILABLE, DEFECTIVE SPEAKER SHOULD BE REPLACED.
(cont'd)
332386-001
6.0V Input, 20 Hz to 20 kHz
4.0V Input, 20 Hz to 3 kHz
2.0V Input, 1 kHz to 20 kHz
35.75 x 11.0 x 13.5 in. D
(908mm x 279mm x 343mm D)
60 lbs. (27 kg)
YEL
Network
332386-001
GRN
GRN/BLK
R2
R1
C1
82Ω
82Ω
12µF
10W
10W
WHT/BLK
GRN/BLK
YEL/BLK
L2
1.0 mH
C3
C6
3.0µF
0.01µF
R6
R5
5.1Ω
30Ω
5W
5W
GRN
+
WHT
+
+
L.F.
H.F.
YEL
+
REV A
8-98
