ECOMOW
ELECTRIC MOWER
1000W 320mm
INSTRUCTION MANUAL
SPECIFICATIONS
Power:
1000W
No Load Speed:
3,200/min
Cutting Diameter:
320mm
Cutting Heights:
30mm, 50mm & 70mm
Catcher Capacity:
30 litre
Weight:
7.0kg
ozito.com.au
WHAT'S IN THE BOX
Electric Lawn Mower
Grass Catcher
Handle Knobs, Handle
Securing Set & Cable
Clips
ELM-1000
Advertisement
Table of Contents
Related Manuals for Ozito ELM-1000
Summary of Contents for Ozito ELM-1000
-
Page 1: Specifications
ELECTRIC MOWER 1000W 320mm INSTRUCTION MANUAL Grass Catcher SPECIFICATIONS Power: 1000W No Load Speed: 3,200/min Cutting Diameter: 320mm Cutting Heights: 30mm, 50mm & 70mm Catcher Capacity: 30 litre Handle Knobs, Handle Weight: 7.0kg Securing Set & Cable Clips ozito.com.au ELM-1000... -
Page 2: Product View And Parts
KNOW YOUR PRODUCT SETUP & PREPARATION 1. ASSEMBLY ECOMOW ELECTRIC MOWER 1 Motor cover 8 Handle Knobs 2 Lifting handle 9 Rear wheel Fitting the Lower Handles to the Mower Body 3 Lower handle 10 Grass catcher flap 4 Cord clips 11 Handle securing set 5 Lock-off button 12 Grass catcher WARNING!:... -
Page 3: Preparation
OPERATION 2. PREPARATION Using the Cord Retainer Securing the Power Cord to the Handles The cord retainer prevents 1. Secure the power cord running the extension cord from being from the switch housing to the disconnected during use. body of the mower by using the two cord clips (supplied). -
Page 4: How To Mow
First disconnect the mower from the power supply and inspect blade for any obstructions. A wait of up to 2 minutes in cooling time, or longer depending on ambient temperature and the operation being performed, before switching On the mower and resuming normal operation. Do Not Overload the Mower Mowing long thick grass may cause the motor speed to drop; you will hear a change in the motor sound. If the motor speed drops you may overload your lawn mower, which may cause damage. When mowing in long thick grass first cut with the cutting height set in the highest position, this will help reduce the load. ELM-1000... -
Page 5: Maintenance
SPELM1000-06 a clockwise direction. Do not over tighten. Belt SPELM1000-30 Ozito Industries will not be responsible for any damage or injuries caused by repair of the tool by an unauthorised person or mishandling Blade & Bolt SPELM1000-33 or mistreatment of the tool. This tool is designed for Domestic Home Use... -
Page 6: Spare Parts Diagram
Model No. ELM-1000 Tool: SPARE PARTS Model No. 42 43 44 45 46 47 48 49 50 24 25 27 29 6-10 6-11 The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No. -
Page 7: Electrical Safety
The electric motor has been designed for 230V and 240V only. Always check that the power supply never in circles. corresponds to the voltage on the rating plate. 6. Do not pull lead around sharp objects. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New 7. Always switch off at the mains before disconnecting any plug, cord or extension lead. Zealand. 8. Never carry the product by the cord. -
Page 8: Warranty
• Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0713...
