ECOMOW
ELECTRIC MOWER
1400W 380mm
INSTRUCTION MANUAL
SPECIFICATIONS
Power:
1400W
Input:
220-240V~50/60Hz
No Load Speed:
3,700/min
Cutting Diameter:
380mm
Cutting Heights:
20mm, 30mm, 40mm,
50mm, 60mm & 70mm
Catcher Capacity:
35 litre
Weight:
14.3kg
ozito.com.au
WHAT'S IN THE BOX
Electric Lawn Mower
3 Piece Grass Catcher
Handle Securing Set &
Cable Clips
ELM-140
Advertisement
Table of Contents
Related Manuals for Ozito ELM-140
Summary of Contents for Ozito ELM-140
- Page 1 INSTRUCTION MANUAL 3 Piece Grass Catcher SPECIFICATIONS Power: 1400W Input: 220-240V~50/60Hz No Load Speed: 3,700/min Cutting Diameter: 380mm Cutting Heights: 20mm, 30mm, 40mm, 50mm, 60mm & 70mm Catcher Capacity: 35 litre Handle Securing Set & Weight: 14.3kg Cable Clips ozito.com.au ELM-140...
- Page 2 KNOW YOUR PRODUCT SETUP & PREPARATION 1. ASSEMBLY ECOMOW ELECTRIC MOWER 1 Motor cover 8 Height adjustment lever Fitting the Lower Handle to Mower Body 2 Lifting handle 9 Quick adjustment knob 3 Lower handle 10 Rear wheel 4 Cord clips 11 Grass catcher flap WARNING!: ENSURE THE TOOL IS DISCONNECTED...
- Page 3 OPERATION 2. PREPARATION Securing the Power Cord to the Handles Using the Cord Retainer The cord retainer prevents the extension cord from being disconnected 1. Secure the power cord from the during use. switch housing to the mower using 1. Make a loop with the extension HOOK the two cord clips (supplied).
- Page 4 3. HOW TO MOW The tool is recommended for use with a residual current device with a • Always use an approved extension lead suitable for power input of rated residual current of 30mA or less. this tool. • Heavy duty power leads recommended. Switching On/Off •...
- Page 5 Do not over tighten. Belt SPELM1400-4832 Ozito Industries will not be responsible for any damage or injuries caused by repair of the tool by an unauthorised person or mishandling or mistreatment of the tool. This tool is designed for Domestic Home Use only.
- Page 6 Model No. ELM-1400 Tool: SPARE PARTS Model No. The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No. Blade SPELM1400-29 Blade Bolt...
- Page 7 6. Do not pull lead around sharp objects. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New 7. Always switch off at the mains before disconnecting any plug, cord or extension lead.
- Page 8 • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0813...
