PETROL
LAWN MOWER
1650W 460mm
INSTRUCTION MANUAL
SPECIFICATIONS
Power:
1650W (2.2HP)
Motor:
1 Cylinder, 4 Stroke, B&S 450 Series
Fuel:
Petrol (lead free)
No Load Speed:
2900/min
Tank Volume:
1.7L
Cutting Width:
460mm
Cutting Height:
30-80mm
Catcher Capacity:
50 litre
Weight:
29.15kg
ozito.com.au
1
WHAT'S IN THE BOX
Petrol Lawn Mower
Grass Catcher
Spark Plug Wrench
PLM-125
Advertisement
Table of Contents
Related Manuals for Ozito PLM-125
Summary of Contents for Ozito PLM-125
-
Page 1: Lawn Mower
1650W (2.2HP) Motor: 1 Cylinder, 4 Stroke, B&S 450 Series Grass Catcher Fuel: Petrol (lead free) No Load Speed: 2900/min Tank Volume: 1.7L Cutting Width: 460mm Cutting Height: 30-80mm Catcher Capacity: 50 litre Weight: 29.15kg ozito.com.au Spark Plug Wrench PLM-125... - Page 2 KNOW YOUR PRODUCT SETUP & PREPARATION 1. HANDLE ASSEMBLY PETROL LAWN MOWER 1 Front Wheel 9 Cord Clip Fitting the Lower Handle 2 Housing 10 Grass Catcher 1 Align the lower handle with the holes on the support bracket 3 Spark Plug Cover 11 Lower Handle and loosely fasten with the upper phillips head screws and 4 Air Filter...
- Page 3 2. FITTING THE CABLE AND CATCHER 3. PREPARATION Securing the Throttle Cable Cutting Height Adjustment The height adjustment lever provides 9 cutting heights from 30mm to 1 Push the cord clip onto the lower handle so that the cable 80mm. runs neatly up the handles to the start/stop lever.
-
Page 4: Operation
This will help reduce the load. 3 To stop the motor simply release the start/stop lever. IMPORTANT! DO NOT MOW WITH POOR VISIBILITY CONDITIONS, IN THE RAIN OR WHEN GRASS IS WET. PLM-125... -
Page 5: Maintenance
Spare parts can be ordered from the Special Orders Desk at your local Bunnings Warehouse. Ozito Industries will not be responsible for any damage or injuries caused by repair of the tool by an unauthorised person or mishandling or mistreatment of the tool. This tool is designed for domestic home use For further information, or any parts not listed here, visit only. -
Page 6: Additional Safety Instructions For Lawn Mowers
SAFETY INSTRUCTIONS WARNING! b) Use safety equipment. Always wear eye protection. Safety equipment such as a Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate Save all warnings and instructions for future reference. -
Page 7: Warranty
• Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0314...
