6
Rear Panel (cont'd)
• Enable Termination Power (J4): This jumper is installed at the factory and enables
termination power to/from the SCSI bus.
NOTE:
• Factory-Installed Jumpers (J3): There are two (2) jumpers factory-installed on J3.
One jumper is located on Pins 7 & 8, the other on Pins 9 & 10.
DC Power
Connector
(P1)
J3 Jumpers
(Factory-Installed on
Pins 7 & 8 and Pins 9 & 10
Do Not Remove!)
StorCase Technology, Inc.
Do not remove this jumper!
68-Pin I/O
Connector
(J2)
P1
J4
J3
J4 Jumper
(Factory-Installed
Do Not Remove!)

Figure 5: Receiving Frame (Rear View)

Option Pin
Connector
0456K
9
10
19 20
21 22
Ultra320 DE200 User's Guide - Rev. A01
Introduction
(W1)
Factory-Installed Jumpers
(Do Not Remove!)
