Installation
INSTALLATION
NOTE:
A #2 Phillips screwdriver will be required during this procedure.
Preparation
While performing the steps in this section, work on a soft surface to prevent excessive shock
to the drive being installed. Also refer to the manufacturer's documentation provided with the
drive.
1.
Remove the drive from its protective packaging.
2.
SCSI Drive Termination: The DE200 does not provide onboard termination. External
termination must be provided. Refer to the documentation provided by the drive manu-
facturer for termination information.
3.
ID Select Jumpers: Locate the ID select jumper positions on the drive, and remove
any jumper plugs in this area (the drive carrier board will plug into this section of the
drive).
Ultra320 DE200 User's Guide - Rev. A01
StorCase Technology, Inc.
7
