Elation Opti Tri 30 User Instructions page 5

Opti Tri 30
DMX Mode:
Operating through a DMX controller gives the user the freedom to create
their own programs tailored to their own individual needs. The Opti Tri 30
has 6 DMX modes: 1 Channel mode, 2 Channel mode, 3 Channel mode,
4 Channel mode, 6 Channel mode, and a 7 Channel mode. See pages
10-12 for each modes' DMX traits.
1. This function will allow you to control each individual fixture's traits
with a standard DMX 512 controller.
2. To run your fixture in DMX mode, plug in the fixture via the XLR con-
nections to any standard DMX controller. Select your desired DMX
mode, and then press the UP or DOWN buttons to adjust the DMX
address.
3. To run the 1 Channel Mode, press the MODE button until "1000"
is displayed. This is the DMX addressing for the 1 Channel Mode.
4. To run the 2 Channel Mode, press the MODE button until "2000"
is displayed. This is the DMX addressing for the 2 Channel Mode.
5. To run the 3 Channel Mode, press the MODE button until "3000"
is displayed. This is the DMX addressing for the 3 Channel Mode.
6. To run the 4 Channel Mode, press the MODE button until "4000"
is displayed. This is the DMX addressing for the 4 Channel Mode.
7. To run the 6 Channel Mode, press the MODE button until "5000"
is displayed. This is the DMX addressing for the 6 Channel Mode.
8. To run the 7 Channel Mode, press the MODE button until "6000"
is displayed. This is the DMX addressing for the 7 Channel Mode.
9. Please see pages 10-12 for DMX values and traits
Elation Professional - www.elationlighting.com - Opti Tri 30 Instruction Manual Page 9
Operating Instructions
Opti Tri 30 1 Channel Mode - DMX Values and Functions
Channel Value
1
0
1 - 7
8 - 15
16 - 23
24 - 31
32 - 39
40 - 47
48 - 55
56 - 63
64 - 71
72 - 79
80 - 87
88 - 95
96 - 103
104 - 111
112 - 119
120 - 127
128 - 135
136 - 143
144 - 151
152 - 159
160 - 167
168 - 175
176 - 183
184 - 191
192 - 199
200 - 207
208 - 215
216 - 223
224 - 231
232 - 239
240 - 247
248 - 255
Elation Professional - www.elationlighting.com - Opti Tri 30 Instruction Manual Page 10
Function
COLOR MACROS
OFF
BASTARD AMBER
MEDIUM AMBER
PALE AMBER GOLD
GALLO GOLD
GOLDEN AMBER
LIGHT RED
MEDIUM RED
MEDIUM PINK
BROADWAY PINK
FOLLIES PINK
LIGHT LAVENDER
SPECIAL LAVENDER
LAVENDER
INDIGO
HEMSLEY BLUE
TIPTON BLUE
LIGHT STEEL BLUE
LIGHT SKY BLUE
SKY BLUE
BRILLIANT BLUE
LIGHT GREEN BLUE
BRIGHT BLUE
PRIMARY BLUE
CONGO BLUE
PALE YELLOW GREEN
MOSS GREEN
PRIMARY GREEN
DOUBLE CTB
FULL CTB
HALF CTB
DARK BLUE
WHITE
