DVG-1100
DVG-1100W
1 Channel MPEG-4
Video Server / Encoder
Version 1.3 2007/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVG-1100 and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech DVG-1100

Summary of Contents for Advantech DVG-1100

  • Page 1 DVG-1100 DVG-1100W 1 Channel MPEG-4 Video Server / Encoder Version 1.3 2007/11...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable.
  • Page 3 DVG-1100 Video Server Manual Revision History Version Change Log Date Author Initial Draft 2007/05/20 Vincent Shih Add I/O Interface 2007/07/20 Vincent Shih Add DVG_Recorder 2007/08/01 Vincent Shih Modify Product Picture 2007/11/20 Vincent Shih Page 3 of 43...

  • Page 4: Safety Instructions

    DVG-1100 Video Server Manual Safety Instructions 1. Read these safety instructions carefully. 2. Keep this user manual for later reference. 3. Disconnect this equipment from AC outlet before cleaning. Do not use liquid or spray detergents for cleaning. 4. For pluggable equipment, the power outlet shall be installed near the equipment and shall be easily accessible.

  • Page 5: Table Of Contents

    DVG-1100 Video Server Manual Table of Content Requirement ........................... 7 Overview............................8 Block Diagram ..........................9 Installation & Settings ........................10 4.1. Power Connection ......................10 4.2. Video Input and video out connector................10 4.3. Install utility software on client PC...................10 4.4. Network Connection ......................11 4.5.
  • Page 6 DVG-1100 Video Server Manual 6.2.8. Special Setting....................35 6.3. REC View ........................36 16 Channel Surveillance Software ....................37 7.1. Introduction........................37 7.2. Installation “VideoServer_Utility.exe”................37 7.3. Main Window ........................38 7.4. Configure storage path of video ..................38 7.5. Configure & Connect to video server ................39 7.6.

  • Page 7: Requirement

    DVG-1100 Video Server Manual 1. Requirement ‧ 1 Channel MPEG-4 Video Server / Encoder × 1 (included) ‧ Power Adaptor (DC 12V/1A) × 1 (not include) ‧ Installation CD & operation manual × 1 (included) ‧ Network cable × 1 (not included) ‧...

  • Page 8: Overview

    DVG-1100 Video Server Manual 2. Overview Outlook Top View Bottom View Page 8 of 43...

  • Page 9: Block Diagram

    DVG-1100 Video Server Manual 3. Block Diagram Application Diagram Page 9 of 43...

  • Page 10: Installation & Settings

    DVG-1100 Video Server Manual 4. Installation & Settings System requirement： OS：Windows 2000 or Windows XP Communication：TCP/IP Interface：10/100M base LAN Web Browser：Microsoft Internet Explorer 4.1. Power Connection Please use DC12V /1A power adapter with Video Server, system need 20~25 seconds finish boot-up process 4.2.

  • Page 11: Network Connection

    4.5. Setting IP of video server by DVG_Finder Open DVG_Finder from start menu under advantech folder. Clicking the [Search] button, DVG_Finder will search all installed Video Server in the same network subnet and list their device name, IP Address and MAC Address in the windows.

  • Page 12: How To Change Ip Address Of Video Server

    DVG-1100 Video Server Manual 4.6. How to change IP address of video server Select one IP address which was searched, and click [UpdateIP] It will show the picture as bellow, you can change IP ADDRESS you need 、Netmask 、 Gateway, and enter login IE User Name、Password, click OK button to change IP.

  • Page 13: How To Change Port Number Of Video Server

    DVG-1100 Video Server Manual 4.8. How to change port number of video server Select one IP address which was searched, and click [UpdatePort]: It will show the picture as bellow, you can change port you need. and enter login IE User Name、Password, click “...

  • Page 14: Internet Connection

    DVG-1100 Video Server Manual 4.10. Internet connection Reference for Intranet and Internet connection methods ： Internet refers to Public IP Address, while Intranet refers to Private IP Address. Private IP Address ranges: • Class A 10.0.0.0 through 10.255.255.255 • Class B 172.16.0.0...
  • Page 15 DVG-1100 Video Server Manual Internet Method ONE：Video Server connects to Internet via router. At this moment, Video Server’s setting is Private IP Address. To properly connect to Internet, the client should go through with router’s forward rules. It is shown in the picture below.

  • Page 16: Web Browser Settings (Download Activex Component)

    DVG-1100 Video Server Manual 4.11. Web Browser Settings (download ActiveX Component) Video Sever will download ActiveX Component from video server automatically when you first time login built-in web server. Internet explorer will show message that request download ActiveX control “IMMP4.cab”. Please click “Install ActiveX control”...

  • Page 17: Uninstall Activex Component

    DVG-1100 Video Server Manual 4.12. Uninstall ActiveX Component User can uninstall Web ActiveX component manually. Open “C:\WINDOWS\Downloaded Program Files folder. Right click on [IMMP4Control Control] select “Remove” to uninstall OCX. Or from Internet explorer menu [Tools] General Setting View Files 4.13.

  • Page 18: Connect To Video Server By Browser

    DVG-1100 Video Server Manual 5. Connect to Video server by browser After searching IP address step, you can double click [Name] on DVG_Finder window to open IE windows. Or you can open Internet explorer manually and enter IP address to connect Video Server.
  • Page 19 DVG-1100 Video Server Manual The Homepage of Video Server in Internet Explorer interface as show in picture: Function introduce as bellow: (1) Play remote video、Stop play video、REC_AV,REC_AVI Record AV or AVI format video clip (2) Snapshot->Take a single picture of video (3) View Size (4) PTZ Control : you can control the way、zoom and focal length...

  • Page 20: Ie Setup Function Interpretation

    DVG-1100 Video Server Manual 6. IE Setup function interpretation 6.1. Basic Configuration 6.1.1. Status Click Setup button into Basic configuration function, Status shows System Information、Firmware current version、MAC Address、Camera information、Total live view users、Wireless status、OCX information : System Information： <1> Firmware Current Version：It shows firmware version you are using and the version date.
  • Page 21 DVG-1100 Video Server Manual Camera Information： <1> Camera Type：It shows the connected camera’s video signal type. (NTSC or PAL) <2> Total live-view users：It shows the number of concurrently connected users session, which excludes those who only operate on the screen without played video image.

  • Page 22: Video & Audio Settings

    DVG-1100 Video Server Manual 6.1.2. Video & Audio Settings Video Stream： <1> CBR：Constant Bit Rate, Configure video stream bit rate as 128kbps，256kbps，384 kbps，512 kbps，1M kbps，1.5M kbps，2M kbps，3M kbps. Default: Disable <2> Resolution：Change the resolution of steaming video, there are D1、Field、CIF、QCIF four kinds of resolution for your choose.

  • Page 23: Networking

    DVG-1100 Video Server Manual “rec+ take snapshot time +.AV” ). <2> REC Duration time：Setup REC duration time. (0-infinity) seconds. Default 0 means REC continually. Note：The AV file maximum capacity is 1G, when bigger than 1G, system will save to the other one file automatically.

  • Page 24: Wireless Settings

    DVG-1100 Video Server Manual 6.1.4. Wireless Settings Basic Configuration： <1> Operation Mode：Two modes, Infra ( Infrastructure Mode ) and Ad-Hoc Mode. If you are just operating with AP, please select Infra mode, if it is a point-to-point transmission, please select Ad-Hoc mode. Default: Infra.
  • Page 25 DVG-1100 Video Server Manual automatically according to the network condition. On :Turn on the protection. Off :Turn off the protection. <9> TX Preamble：Define length in the mode. There are three kinds of select mode： CRC block Ad Hoc Auto、Long and Short, select "Auto" to indicate the wireless network card will distinguish automatically.

  • Page 26: Pppoe

    DVG-1100 Video Server Manual 6.1.5. PPPoE Configuration： <1> Enable PPPoE：Enables or disables this function. <2> User Name：Enter the account provided by ISP. <3> Password：Enter the password provided by ISP. <4> MTU：Maximum Transmission Unit. <5> Email Notification when IP is changed：Enables or disables this function.

  • Page 27: Date & Time

    DVG-1100 Video Server Manual Dynamic DNS： To use DDNS service, be sure to go to the web site of DynDNS (www.dyndns.org) and PeanutHull, and register for a dynamic domain name, which can be used to access it over Internet. Free of charge. Or you can’t use the service.

  • Page 28: Log

    DVG-1100 Video Server Manual 6.1.8. Log Log Information：Shows log system time、connection history、IP status information. PS. Log information will be erased after system reboot. 6.2. Advance Configuration 6.2.1. MAINTENANCE Maintain Server： <1> Restart：To restart video server, all setting won’t change. <2> Restore：Reset all parameters, except IP parameters, to the original factory settings.

  • Page 29: Administrator

    DVG-1100 Video Server Manual 6.2.2. ADMINISTRATOR User List：Add/Remove user account. Add New User： User Name：Enter A-Z or a-z, only use English and number to make up user name, and user name has to less than 14 characters. Password：Key in password.

  • Page 30: Change Password

    DVG-1100 Video Server Manual Note： 「admin」 account can't delete. Anonymous User Setting：Yes or No. Enable anonymous viewer login. (No user name or password required.) Default: No. Maximum number of simultaneous viewers limit：Enter maximum number of simultaneous viewers. (Maximum value: 20).

  • Page 31: Ftp

    DVG-1100 Video Server Manual To set up mail server, please use the mail server provided by your ISP. SMTP (E-mail) Settings： Mail server：Set up the major mail server. From E-Mail address：Set up the Sender’s E-mail account. Authentication、User Name、Password：If the mail severs require authentication, please check Yes here, and enter User name and Password in the field provided.

  • Page 32: Ptz

    DVG-1100 Video Server Manual 6.2.6. PTZ Select PTZ Protocol：Pelco-P or Pelco-D. Default：Pelco-P. Select PTZ Baudrate：Select PTZ Baudrate (bit/s). There are 9600bit/s, 4800bit/s, 2400bit/s, 1200bit/s. Default: 9600bit/s. Set PTZ Address：Type your PTZ Device address ID. RS-485 device ID. Default: 0 Set pan direction：Set up moves perpendicular direction. Default：Down.

  • Page 33: Alarm Event

    DVG-1100 Video Server Manual 6.2.7. ALARM EVENT Embedded Motion Detection Setting Set Motion Detect Region： Set up motion detection region. Click “Begin “, choose range 0~15 and click “Edit Region “, and then you can drag-drop a square region on video. If want to cancel the region, please click “Remove Region “.
  • Page 34 DVG-1100 Video Server Manual I/O Port Pin Define: Page 34 of 43...

  • Page 35: Special Setting

    DVG-1100 Video Server Manual 6.2.8. Special Setting Video Advance Setting： Compression：Set video compression Compression Bit rate 170~850 kbps 120~500 kbps 110~360 kbps 110~330 kbps 110~270 kbps P/I Ratio(P frmae ; I frame)：Can change the ratio of the P frame and I frame (When I frame ratio more higher, the streaming video quantity more clear but opposite data will also become more bigger).

  • Page 36: Rec View

    DVG-1100 Video Server Manual 6.3. REC View PLAYBACK： This function cans playback video files which were recorded previously. Click “Browse” button can select files to play. (*.av). Click "Play" button to start playback the recorded video. Click “Stop “button to Stop.

  • Page 37: Channel Surveillance Software

    7. 16 Channel Surveillance Software 7.1. Introduction PowerView-NVR/DVG_Recorder series is multi channel recording software for DVG-1100 video server. Any PC running with PowerView-NVR/DVG_Recorder will turn into professional DVR platform which can connect up to 16 channel video server and recording real-time audio/video stream into hard driver.

  • Page 38: Main Window

    DVG-1100 Video Server Manual 7.3. Main Window Video window Main menu Disk driver status Right-Click menu Video ch. switch Window layout Switch/Rotate window Quit program Message window 7.4. Configure storage path of video Page 38 of 43...

  • Page 39: Configure & Connect To Video Server

    DVG-1100 Video Server Manual Click [Setup] at main menu and system setup window will show up. Under Server page, user can configure four storage path where to save audio/video from video server. 7.5. Configure & Connect to video server Step 1: Right-click on video window and then pop-up menu will show up.

  • Page 40: Record Audio/Video

    DVG-1100 Video Server Manual Step 3: Configure setting for each video window. There are 16 tabs [View1 ~ View16]. a. Remote Server Name/ID: IP address of remote video server b. Port Number: 80 [default] c. User Name: admin d. Password: xxxxx e.

  • Page 41: Playback Video

    DVG-1100 Video Server Manual 7.7. Playback video Step 1: Click [Play] at main menu, Video player window will show up. Step 2: Right side of the window show the 16 video windows. Click one of the windows will show the recorded clip list at left side of the window.

  • Page 42: Modify、Repair Or Remove

    DVG-1100 Video Server Manual 7.8. Modify、Repair or Remove Run “VideoServer_Utility.exe” from CD-ROM. System will show following window once you have installed videoserver_utility. 7.9. Save exist configuration file before upgrade utility User can save exist configuration file of DVG_Recorder before proceed remove or upgrade utility.

  • Page 43: Specification

    DVG-1100 Video Server Manual 8. Specification Page 43 of 43...
