Gefen Matrix Switcher Keyboard Controller User Manual page 20

Operating the Gefen Matrix Switcher Keyboard Controller
10. Click the
11. The "Changes saved Successfully" message will appear at the bottom of the dialog.
12. Near the bottom of the dialog, under the Setup tab, is a sample keystroke sequence:
In order to switch Input 3 to Output 5, press and release the CTRL key, twice, on the
left side of the keyboard. Then, press 3 and 5 on the keyboard. The numbers can
be entered using the numeric keypad or by using the number keys near the top of the
keyboard.
IMPORTANT: If using the Mac OS platform, go to Preferences
> Accessibility and make sure that "Enable access for assistive
devices" is enabled.
button to confirm the current settings.
page | 14
Basic Operation
