16x16 DVI Matrix
EXT-DVI-16416
User Manual
1080P
www.gefen.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXT-DVI-16416 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gefen EXT-DVI-16416

Summary of Contents for Gefen EXT-DVI-16416

  • Page 1 ® 16x16 DVI Matrix EXT-DVI-16416 User Manual 1080P www.gefen.com...
  • Page 3 ASKING FOR ASSISTANCE Technical Support: Telephone (818) 772-9100 (800) 545-6900 Fax (818) 772-9120 Technical Support Hours: 8:00 AM to 5:00 PM Monday through Friday, Pacific Time Write To: Gefen, LLC c/o Customer Service 20600 Nordhoff St Chatsworth, CA 91311 www.gefen.com support@gefen.com Notice Gefen, LLC reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. 16x16 DVI Matrix is a trademark of Gefen, LLC © 2011 Gefen, LLC. All Rights Reserved All trademarks are the property of their respective owners. Rev C16...

  • Page 4: Table Of Contents

    CONTENTS Introduction Operation Notes Features Panel Layout Front Panel Back Panel Panel Descriptions IR Remote Control Layout and Description Installing the Battery Setting the IR Channel Connecting the 16x16 DVI Matrix Wiring Diagram 10 Operating the 16x16 DVI Matrix 10 Status Screen 11 Routing Sources 12 Entering Standby mode 13 Exiting Standby mode 14 Routing Sources using the IR Remote Control 15 RS-232 / IP Control 17 RS-232 / Telnet / UDP Commands 17 EDID Management 22 IP / Telnet Configuration 30 Routing 33 Masking 35 Miscellaneous 43 Web Interface 43 View Matrix Status...

  • Page 5: Introduction

    INTRODUCTION Congratulations on your purchase of the 16x16 DVI Matrix. Your complete satisfaction is very important to us. Gefen Gefen delivers innovative computer and electronic solutions that harness integration, extension, distribution and conversion technologies. Gefen’s reliable, plug-and-play products supplement cross-platform computer systems, professional audio/video environments and HDTV systems of all sizes with hard-working solutions that are easy to implement and simple to operate. The Gefen 16x16 DVI Matrix Simplify the process of routing multiple DVI sources giving the ability to route sources without losing quality or resolution. Route 16 sources to 16 digital monitors using the Gefen 16x16 DVI Matrix. The Matrix provides a simple, reliable, and highly effective method of streamlining any installation using multiple sources and outputs. It takes the hassle out of multiple wiring schemes. Four methods are available for controlling the Gefen 16x16 DVI Matrix: Front panel buttons, IR remote, RS-232 interface, or using IP control. How It Works The 16x16 DVI Matrix has sixteen DVI inputs and sixteen DVI outputs. Connect your sixteen computers to the DVI input ports on the Matrix’s input side. Connect the Matrix’s sixteen DVI outputs to the displays. Connect the power supply to the Matrix and connect the power cord to an available wall outlet. The connected displays will show video according to the selection. NOTE: This device only supports DVI-D.

  • Page 6: Operation Notes

    OPERATION NOTES READ THESE NOTES BEFORE INSTALLING OR OPERATING THE 16X16 DVI MATRIX • The 16x16 DVI Matrix does not support HDCP content. • Make sure that a DVI monitor is powered and connected to one of the DVI outputs on the 16x16 DVI Matrix before applying power. By default, the Local EDID is read from the connected monitor and is copied to all 16 DVI inputs once the Matrix has been turned on. If a monitor is not detected by the Matrix at power-on, a default (internal) EDID of 640x480 will be used. This functionality can be disabled using the Secure Local EDID function using RS-232, Telnet, UDP, or the built-in Web interface. • There is no internal scaling in the 16x16 DVI Matrix. Each monitor attached to the Matrix must be able to display the resolutions output by the source device(s). For maximum compatibility it is recommended that only one common resolution be used by each source device. • Advanced EDID features are accessible using RS-232, Telnet, UDP, or the built-in Web interface. • Routing and EDID features can be managed using the built-in IP control features. • This matrix supports Dynamic EDID. See pages 17 and 44 for details.

  • Page 7: Features

    FEATURES Features • Supports resolutions up to 1920 x 1200 • Status LCD (shows routing status) • Advanced EDID management provides rapid integration of sources and displays • Dynamic EDID support • Serial RS-232 interface for remote control via a computer or control automation devices • IP Control (Telnet, UDP, and Web interface) • Output masking command • IR Remote Control • IR Extender • Standby mode • Supports DDWG standards for DVI • Rack-mountable Package Includes (1) 16x16 DVI Matrix (16) 6 ft. DVI cables (M-M) (1) IR Remote Control Unit (1) AC Power Cord (1) Quick-Start Guide...

  • Page 8: Panel Layout

    PANEL LAYOUT Front Panel...

  • Page 9: Back Panel

    PANEL LAYOUT Back Panel...

  • Page 10: Panel Descriptions

    PANEL DESCRIPTIONS Control Buttons These buttons are used to navigate the functions of the 16x16 DVI Matrix. For complete details on these controls and how they are used, see pages 10 - 13. Infrared (IR) Receiver This IR receiver will accept commands from the RMT-16416IR remote control. Line-of- sight between this receiver and the remote controls needs to be preserved for proper operation. Power LED Indicator This LED indicator will be active when the included 24V DC power supply is properly connected to the unit. Cancel Button This button is used to return the user to the main status screen once a routing change has been initiated and the user decides to not continue with the change. Main LCD Display This 2 line 16 character display will display status information and is also used to manage the display/source routes. DVI Input Ports 1-16 These inputs are used to connect up to 16 DVI-capable sources. 10/100 Ethernet Control Interface This port is used to connect the 16x16 DVI Matrix to a network for IP control. See page 16 for more information. 24V DC Power Receptacle The port will accept power from the included 24V DC power supply. DVI Output Ports 1-16 These outputs are used to connect up to 16 DVI-capable displays. 10 RS-232 Serial Communications Interface This interface was designed to accept commands from an external control system. This port will allow switching commands as well as EDID management and configuration operations. See page 15 for more information. 11 IR Extender Jack Accepts an optional IR Extender which allows relocation of the IR receiver up to 6 feet away from the Matrix.

  • Page 11: Ir Remote Control

    IR REMOTE CONTROL RMT-16416IR Layout and Description Activity Indicator This LED will be activated momentarily each time a button is pressed. Display and Source Selection Buttons (1 - 16) These buttons are used to select which source is routed to a monitor. NOTE: An Activity Indicator that flashes quickly while holding down any one of the 16 buttons indicates a low battery. Replace the IR Remote Control battery as soon as possible.

  • Page 12: Installing The Battery

    IR REMOTE CONTROL Installing the Battery The Remote Control unit ships with two batteries. One battery is required for operation and the other battery is a spare. Remove the battery cover on the back of the IR Remote Control unit. Insert the included battery into the open battery slot. The positive (+) side of the battery should be facing up. Replace the battery cover. Channel 0 (default): Remote Channel 1: Remote Channel 2: Remote Channel 3: Battery slot DIP switches Setting the IR Channel The IR channel on the IR Remote Control must match the IR channel used by the DVI 16x16 Matrix. For example, if both DIP switches on the IR Remote Control unit are set to IR channel 0 (both DIP switches down), then the 16x16 DVI Matrix must also be set to IR channel 0. See page 37 for information on how to change the IR channel on the DVI 16x16 Matrix. WARNING: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions.

  • Page 13: Connecting The 16X16 Dvi Matrix

    CONNECTING THE 16X16 DVI MATRIX How to Connect the 16x16 DVI Matrix Connect up to 16 DVI source devices to the DVI inputs on the rear panel of the 16x16 DVI Matrix using the supplied DVI cables. Connect up to 16 DVI monitors to the DVI outputs on the rear panel of the 16x16 DVI Matrix with DVI cables. Connect the included AC power cable to the power receptacle on the rear panel of the 16x16 DVI Matrix. Connect the opposite end of the cable into an available electrical outlet. Wiring Diagram for the 16x16 DVI Matrix CAT-5 CABLE DVI CABLE RS-232 CABLE DVI Sources Matrix IP Control EXT-DVI-16416 DVI Displays RS-232 Controller ATTENTION: This product should always be connected to a grounded electrical socket.

  • Page 14: Operating The 16X16 Dvi Matrix

    OPERATING THE 16X16 DVI MATRIX Status Screen The status screen is a 16-character 2-line LCD display. This display shows the current status of the matrix and is also used to perform routing and other functions. When the unit is powered on, the following screen is displayed: EDID LOADING PLEASE WAIT After a few moments, the following is displayed in the status screen: GEFEN 16x16 DVI MATRIX Displaying Additional Information Pressing the ◄ button consecutively, will cycle through other screens such as firmware and boot loader version: MATRIX FIRMWARE 6.1.2 BOOT LOADER GEFEN 16x16 DVI MATRIX...

  • Page 15: Routing Sources

    OPERATING THE 16X16 DVI MATRIX Routing Sources Press the Select button to display the routing screen. > OUTPUT: 01 INPUT: Select button Use the ◄ or ► buttons to select the display that will receive the source signal. Press the Select button to confirm the output selection. Otherwise, press the Cancel button. OUTPUT: 01 > INPUT: Use the ◄ or ► buttons to select the desired source to be routed to the display, which was selected in Step 2. Press the Select button to confirm the output selection. Otherwise, press the Cancel button. Press the Cancel button to return to the Standby screen.

  • Page 16: Entering Standby Mode

    OPERATING THE 16X16 DVI MATRIX Entering Standby Mode Entering Standby mode will place the matrix in a low power-consumption state. Simultaneously press and hold the Select and Cancel buttons. GEFEN 16x16 DVI MATRIX Press Select and Cancel Simultaneously The matrix will power-down and go into standby mode. When the matrix is in standby mode, the power indicator on the front-panel will flash bright red until standby mode is disabled.

  • Page 17: Exiting Standby Mode

    OPERATING THE 16X16 DVI MATRIX Exiting Standby Mode Press and hold any button on the front panel until the front-panel LCD comes on. GEFEN 16x16 DVI MATRIX Once the matrix turns on, release the button.

  • Page 18: Routing Sources Using The Ir Remote Control

    OPERATING THE 16X16 DVI MATRIX Routing Sources using the IR Remote Control To route sources using the IR Remote Control, select the output first, then the input. Routing Example: Route Input 12 to Output 3 Select Output 3 by pressing button 3 on the IR Remote Control. Output 3 will be selected in the display. The cursor will appear next to the input, indicating that the next entry on the IR Remote Control will route the selected input. LED indicates a button was pressed Output 3 selected OUTPUT: 03 > INPUT: Select Input 12 by pressing button 12 on the IR Remote Control. The number 12 will appear next to the input. The cursor will automatically advance to the output. > OUTPUT: 03 INPUT: Input 12 selected...
  • Page 19 RS-232 / IP CONTROL RS-232 Interface DE-9 DA-15 RS-232 Controller Matrix TXD TXD DB-25 Only TXD, RXD, and GND are used. DC-37 RS232 Settings Baud rate ........................19200 Data bits ..........................8 Parity bits ........................None Stop bits ..........................1 DD-50 Flow Control ........................None IMPORTANT: When sending RS-232 commands, a carriage return must be included at the end of the command. A space must be included between the command and the parameter.

  • Page 20: Rs-232 / Ip Control

    RS-232 / IP CONTROL IP Configuration The 16x16 DVI Matrix supports IP-based control using Telnet, UDP, or the built-in Web-based GUI. To set up IP control, the network settings for the 16x16 DVI Matrix must be configured via RS-232. The default network settings for the matrix are as follows: IP Address: 192.168.1.72 Subnet: 255.255.255.0 Gateway: 192.168.1.254 HTTP Port: Telnet Port: Connect an RS-232 cable from the PC to the 16x16 DVI Matrix. Also make sure that an Ethernet cable is connected between the matrix and the network. Launch a terminal emulation program (e.g. HyperTerminal) and use the RS-232 settings listed on page 15. NOTE: Depending upon the network, all related IP, Telnet, and UDP settings will need to be assigned. Consult your network administrator to obtain the proper settings. Set the IP address for the matrix using the #sipadd command (see page 28 for details). Set the subnet mask using the #snetmask command (see page 28 for details). Set the gateway (router) IP address using the #sgateway command (see page 27 for details). Set the Telnet listening port using the #set_tcp_term_port command (see page 25 for details). Set the HTTP listening port using the #set_http_port command (see page 24 for details). Power-cycle the matrix to reboot and complete all IP setting changes. Type the IP address that was specified in step 3, in a web browser to access the Web GUI or use the same IP address to Telnet to the matrix.

  • Page 21: Rs-232 / Telnet / Udp Commands

    RS-232 / TELNET / UDP COMMANDS EDID Management Command Description Enables / disables dynamic EDID #dynamic_edid #edidbatolo Read downstream EDID and stores in any Local Input #ediddetolo Sets Local EDID to Default EDID #ediddstoba Read downstream EDID and stores in EDID Bank #ediddstolo Read downstream EDID and stores into a Local EDID #lock_edid Secures Local EDID #prbaedid Read EDID from an EDID bank and sends to serial port Read downstream EDID and sends to serial port #prdsedid #predidst Prints EDID details #prloedid Read Input Local EDID and sends to serial port #dynamic_edid Command The #dynamic_edid command provides the ability to route any downstream EDID to any input. When enabled, the EDID is copied to all inputs from the last selected active output. When disabled, the EDID is copied to all inputs from the first active display detected, start- ing from Output 1. Syntax: #dynamic_edid param1 Parameters: param1 Value [0 - 1]...
  • Page 22 RS-232 / TELNET / UDP COMMANDS #edidbatolo Command The #edidbatolo command reads the downstream EDID and stores it to any local input. Syntax: #edidbatolo param1 param2 [param3...param9] Parameters: param1 EDID bank offset [1 ... 5] param2 Input [1 ... 16] Notes: If param2 = 0, then the EDID in the specified bank is copied to all eight inputs. #ediddetolo Command The #ediddetolo command stores the Default EDID (640x480) in the specified Local EDID inputs. Syntax: #ediddetolo param1 param2 param3...param9 param1 Input [1 ... 16] Notes: If param1 = 0, then all 16 DVI inputs will be set to the Default EDID.
  • Page 23 RS-232 / TELNET / UDP COMMANDS #ediddstoba Command The #ededdstoba command reads the downstream EDID and stores it to a specified EDID bank. Syntax: #ediddstoba param1 param2 Parameters: param1 A downstream monitor [1 ... 16] param2 EDID bank offset [1 ... 3] #ediddstolo Command The #ediddstolo command reads the downstream EDID and stores it to a Local EDID input. Syntax: #ediddstolo param1 param2 [param3...param9] Parameters: param1 A downstream monitor [1 ... 16] param2 Input list [1 ... 16] Notes: If param2 = 0, then the downstream EDID is stored to all 16 DVI inputs. If more than eight inputs need to be specified in order to receive the downstream EDID, the #ediddstolo command must be executed twice.
  • Page 24 RS-232 / TELNET / UDP COMMANDS #lock_edid Command The #lock_edid command secures the Local EDID and disables the automatic loading of the downstream EDID after the matrix is powered on. This feature can also be controlled using the Web Interface (see page 52). Syntax: #lock_edid param1 Parameters: param1 Input [0 ... 1] Value Meaning Disable Enable #prbaedid Command The #prbaedid command reads the EDID file from the specified bank and sends it to the serial port. Syntax: #prbaedid param1 Parameters: param1 EDID bank [1 ... 3] #prdsedid Command The #prdsedid command reads the downstream EDID and sends it to the serial port. Syntax: #prdsedid param1 Parameters: param1 A downstream monitor [1 ... 16]...
  • Page 25 RS-232 / TELNET / UDP COMMANDS #predidst Command The #predidst command reads the downstream EDID. This command displays a table containing details relating to the Local EDID and the monitor name. Syntax: #predidst Parameters: None #prloedid Command The #prloedid command reads the local EDID of a specified input and spools it to the serial port. Syntax: #prloedid param1 Parameters: param1 Input [1 ... 16]...

  • Page 26: Ip / Telnet Configuration

    RS-232 / TELNET / UDP COMMANDS IP / Telnet Configuration Command Description #ipconfig Displays all TCP/IP settings #resetip Resets IP configuration to factory settings #set_http_port Sets the Web server listening port #set_tcp_term_pass Sets the TCP terminal password Sets the Telnet listening port #set_tcp_term_port #set_udp_port Sets the local UDP listening port #set_udp_rip Sets the remote UDP IP address #set_udp_rport Sets the remote UDP port #sgateway Sets the IP gateway address #show_tcp_term_pass Displays the current TCP password for login Sets the IP address of the matrix #sipadd Sets the IP network mask #snetmask #use_tcp_term_pass Enables / disables password prompt for TCP sessions #use_udp_access Enables / disables UDP listening...
  • Page 27 RS-232 / TELNET / UDP COMMANDS #ipconfig Command The #ipconfig command displays all TCP/IP settings on the matrix. Syntax: #ipconfig Parameters: None Example: #ipconfig -------------- TCP/IP settings ------------- MAC add = 00:1C:91:01:01:01 IP add = 192.168.1.72 Net Mask = 255.255.255.0 Gateway = 192.168.1.254 Web Server Port = 80 TCP Terminal Server Port = 23 TCP Terminal password at login is set to ON UDP Server Port = 25665 UDP Remote IP = 110.0.255.255...
  • Page 28 RS-232 / TELNET / UDP COMMANDS #set_http_port Command The #set_http_port command sets the Web server listening port. The default port is 80. Syntax: #set_http_port param1 Parameters: param1 Port [0 ... 65535] Notes: The matrix must be rebooted after executing this command. #set_tcp_term_pass Command The #set_tcp_term_pass command sets the TCP password. The maximum length of the password is 20 characters and is case-sensitive. The default password is Admin. Syntax: #set_tcp_term_pass param1 Parameters: param1 Current password param2 New password param3 New password (confirm) Notes: The matrix must be rebooted after executing this command. Example: #set_tcp_term_pass Admin reindeer reindeer TCP Terminal password updated to: reindeer...
  • Page 29 RS-232 / TELNET / UDP COMMANDS #set_tcp_term_port Command The #set_tcp_term_port command sets the Telnet listening port. The default port value is 23. Syntax: #set_tcp_term_port param1 Parameters: Port [1 ... 65535] param1 Notes: The matrix must be rebooted after executing this command. Example: #set_tcp_term_port 20 New TCP Terminal port set to: 20 #set_udp_port Command The #set_udp_port command sets the local UDP listening port. The default port value is 8. Syntax: #set_udp_port param1 Parameters: param1 Port [1 ... 65535] Notes: The matrix must be rebooted after executing this command.
  • Page 30 RS-232 / TELNET / UDP COMMANDS #set_udp_rip Command The #set_udp_rip command sets the remote UDP IP address. The default port value is 8. Syntax: #set_udp_rip param1 Parameters: IP Address param1 Notes: The matrix must be rebooted after executing this command. Example: #set_udp_rip 192.168.1.20 New remote UDP IP address set to: 192.168.1.20 #set_udp_rport Command The #set_udp_rport command sets the remote UDP port. Syntax: #set_udp_rport param1 Parameters: param1 Port Notes: The matrix must be rebooted after executing this command. Syntax: #set_udp_rport 4096 New remote UDP port set to: 4096...
  • Page 31 RS-232 / TELNET / UDP COMMANDS #sgateway Command The #sgateway sets the IP gateway (router) address. Dot-decimal notation must be used when specifying the IP address. The default gateway is 192.168.1.254. Syntax: #sgateway param1 Parameters: IP gateway param1 Notes: The matrix must be rebooted after executing this command. Example: #sgateway 192.168.1.1 New IP Gateway set to: 192.168.1.1 #show_tcp_term_pass Command The #show_tcp_term_pass command displays the current TCP password for login (if required). Syntax: #show_tcp_term_pass Example: #show_tcp_term_pass TCP Terminal password: reindeer...
  • Page 32 RS-232 / TELNET / UDP COMMANDS #sipadd Command The #sipadd command sets the IP address of the matrix. Dot-decimal notation must be used when specifying the IP address. Syntax: #sipadd param1 Parameters: IP address param1 Notes: The matrix must be rebooted after executing this command. Example: #sipadd 192.168.1.239 New IP set to: 192.168.1.239 #snetmask Command The #snetmask command sets the IP network mask. Dot-decimal notation must be used when specifying the IP network mask. Syntax: #snetmask param1 Parameters: param1 Network mask Notes: The matrix must be rebooted after executing this command. Example: #snetmask 255.255.255.0 New IP Mask set to: 255.255.255.0...
  • Page 33 RS-232 / TELNET / UDP COMMANDS #use_tcp_term_pass Command The #use_tcp_term_pass command enables / disables the password prompt at the beginning of a session. The default setting is disabled. This feature can also be enabled or disabled through the Web GUI (see page 54). Syntax: #use_tcp_term_pass param1 Parameters: param1 State [0 ... 1] Value Meaning Disable password Enable (force) password Example: #use_tcp_term_pass 1 TCP Terminal password at login is set to ON #use_udp_access Command The #use_udp_access command enables / disables UDP listening. Syntax: #use_udp_access param1 Parameters: param1 State...

  • Page 34: Routing

    RS-232 / TELNET / UDP COMMANDS Routing Command Description #callpreset Recalls a routing / mask preset #prpreset Displays the preset table #savepreset Saves the current routing/masking state to a preset Routes the specified inputs to the specified outputs Routes the specified input to all outputs #callpreset Command The #callpreset command recalls a routing preset. Any masked outputs will also be re- called. Syntax: #callpreset param1 Parameters: param1 Preset [1 ... 16] #prpreset Command The #prpreset command displays the preset table. Syntax: #prpreset Parameters: None...
  • Page 35 RS-232 / TELNET / UDP COMMANDS Example: #prpreset PreSet|Out1| 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10| 11| 12| 13| 14| 15| 16 ------|----|---|---|---|---|---|---|---|---|---|---|---|---|---|---|--- |M 0 |M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0 |M 0 |M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0 |M 0 |M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0 |M 0 |M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0|M 0...
  • Page 36 RS-232 / TELNET / UDP COMMANDS r Command The r command routes the specified input to the specified outputs. Syntax: r param1 param2[...param17] Parameters: param1 Input [1 ... 16] param2 Outputs [1 ... 16] Notes: If param2 = 0, then the specified input is routed to all outputs. Examples: r 7 3 4 5 6 10 12 Input 7 is routed to outputs: 3 4 5 6 10 12 r 2 0 All outputs are routed to Input 2 s Command...

  • Page 37: Masking

    RS-232 / TELNET / UDP COMMANDS Masking Command Description Masks the selected (video) output(s) #maskout #unmaskout Unmasks the selected output(s) #maskout Command The #maskout command allows blanking of the specified outputs. Syntax: #maskout param1 param2 Parameters: param1 Output [1 ... 16] State [0 ... 1] param2 Value Meaning Unmask Mask Notes: If param1 = 0, then all outputs will be masked. The current masking state will be lost if power is interrupted or if the masking state is not saved (see #savepreset on page 31).
  • Page 38 RS-232 / TELNET / UDP COMMANDS #unmaskout Command The #unmaskout command unmasks the specified outputs. Syntax: #unmaskout param1...param8 Parameters: param1 Output [1 ... 16] Notes: If param1 = 0, then all outputs will be unmasked. Examples: #unmaskout 3 8 10 Activate outputs: 3 8 10 #unmaskout 0 Activate all outputs...

  • Page 39: Miscellaneous

    RS-232 / TELNET / UDP COMMANDS Miscellaneous Command Description Activates the boot loader for firmware updates #activebolo #fadefault Resets the matrix to factory default routing #help Displays all available commands #lock_fo Toggles the +5V lock power state #set_input_name Specifies a name for an input #set_ir Sets the IR channel of the matrix #set_output_name Specifies a name for an output Displays the board temperatures #show_temp #show_user_name Displays the TCP user name #show_ver_data Displays the current hardware #show_voltage Displays the board voltages Toggles / displays +5V input Displays the current routing status in tabular form #fadefault Command The #fadefault command disables the EDID lock state, sets the default routing state (1-1, 2-2, 3-3, etc.) and resets the input and output names to the default names (e.g. Output 1, Input 1). Syntax: #fadefault Parameters: None...
  • Page 40 RS-232 / TELNET / UDP COMMANDS #help Command The #help command displays help on the specified command. If param1 is not specified, then the full list of commands is displayed. Syntax: #help [param1] Parameters: param1 Command name Example: #help #callpreset Cmd #callpreset: Recall a routing and mask state preset Syntax: #callpreset param1 Param1 = 1-16 (preset) e.g: #callpreset 2 #lock_fo Command The #lock_fo enables/disables the power lock state. Enabling this feature will store the +5V status for each input prior to shutting down the matrix. This preserves the +5V state when the unit is restarted.
  • Page 41 RS-232 / TELNET / UDP COMMANDS #set_input_name Command The #set_input_name command provides a name to the selected input. For example, “Input 1” could be renamed as “Computer 1”. The maximum string length for param2 is 15 characters. Special characters and spaces are not permitted. If required, use the underscore character (“_”) to separate characters. Syntax: #set_input_name param1 param2 Parameters: Input [1 ... 16] param1 param2 Name Example: #set_input_name 5 computer1 computer1 is assigned to input 5 #set_ir Command The #set_ir set the IR channel for the matrix. The associated DIP switch settings for the IR remote control unit are returned. See page 8 for details on setting the IR channel for the IR remote control. Syntax: #set_ir param1 Parameters: Channel [0 ... 3]...
  • Page 42 RS-232 / TELNET / UDP COMMANDS #set_output_name Command The #set_output_name command provides a name to the selected output. For example, “Output 1” could be renamed as “HDDisplay”. The maximum string length for param2 is 15 characters. Special characters and spaces are not permitted. If required, use the underscore character (“_”) to separate characters. Syntax: #set_output_name param1 param2 Parameters: Output [1 ... 16] param1 param2 Name Example: #set_output_name 3 display_3 display_3 is assigned to output 3 #show_temp Command The #show_temp command displays the board temperatures to the screen. Syntax: #show_temp Parameters: None Example: #show_temp Temperature near cross point top side is 50 Temperature near cross point bottom side is 44 C degree...
  • Page 43 RS-232 / TELNET / UDP COMMANDS #show_user_name Command The #show_user_name command displays the current TCP terminal user name. Syntax: #show_user_name Parameters: None Example: #show_user_name TCP Terminal login: Administrator #show_ver_data Command The #show_ver_data command displays the hardware and firmware version ot the screen. Syntax: #show_ver_data Parameters: None Example: #show_ver_data Hardware version 2 Firmware Release version 6.1.2 Release date: Jan 21 2013 Release time: 16:38:56 Boot loader version 1.5...
  • Page 44 RS-232 / TELNET / UDP COMMANDS #show_voltage Command The #show_voltage command displays board voltages to the screen. Syntax: #show_voltage Parameters: None Example: #show_voltage Analog voltage 3.3 , measured 3262 mV Analog voltage 1.8 , measured 1781 mV Analog voltage 1.2 , measured 1180 mV...
  • Page 45 RS-232 / TELNET / UDP COMMANDS f Command The f command enables / disables the +5V on the specified input. Do not precede this command with the “#” symbol. WARNING: Use caution when applying power to inputs. If the source device supplies +5V on the input, then enabling the +5V may cause damage to the source and/or the 16x16 DVI Matrix. Syntax: f param1 param2 Parameters: param1 Input [1 ... 16] param2 State [0 ... 1] Value Meaning Disable Enable Notes: If param1 = 0, then all inputs will be affected. Examples: f 15 1 Enable F0 15 f 0 1 Enable All FO...
  • Page 46 LOW | ACTIVE Output_11| Input_1| LOW | ACTIVE Output_12| Input_1| LOW | ACTIVE Output_13| Input_1| LOW | ACTIVE Output_14| Input_1| LOW | ACTIVE Output_15| Input_1| LOW | ACTIVE Output_16| Input_1| LOW | ACTIVE ----------------|----------------|-------|-------- GEFEN PRO Dynamic EDID mode RMT_IR - SW1=0,SW2=0...

  • Page 47: Web Interface

    WEB INTERFACE View Matrix Status Matrix Status Displays the current routing status of each input and output on the matrix. Auto Refresh Refresh Check this box to enable Auto Refresh. Click to refresh the Matrix The Auto Refresh function automatically Status screen refreshes the interface every 10 seconds.
  • Page 48 WEB INTERFACE Dynamic EDID Mode Routes any downstream EDID to any input. See #dynamic_edid on page 17 for details on this feature. Options: On, Off. Click the Update Dynamic EDID State button after selecting either On or Off. Switch Outputs Used to route the specified input to the selected output(s). To route a source, place a check mark next to each Output. Next, click the radio button next to the desired Input. Press the Switch button to apply the routing change.
  • Page 49 WEB INTERFACE Presets Provides saving and recalling Pull-down list of routing states. Recall Preset Click the down-arrow on the pull-down list to select the routing state (1-16) to recall. Click the Recall Preset button to recall the preset. Save Preset Click the down-arrow on the pull-down list to select the preset location (1-16). Click the Save Preset button to save the preset.
  • Page 50 WEB INTERFACE Rename I/O Provides custom naming Pull-down list of each input and output on the matrix. Input Select the DVI input to rename from the pull-down list. Type the name of the input in the Input Name field. Click the Save Input Name button to save changes. See page 37 for naming restrictions. Output Select the DVI output to rename from the pull-down list. Type the name of the output in the Output Name field. Click the Save Output Name button to save changes. See page 38 for naming restrictions.

  • Page 51: Manage Edid

    WEB INTERFACE Manage EDID EDID Status Displays the current EDID status for each input on the matrix and indicates the current Lock State (page 20). Refresh Click to refresh the Matrix Status screen Auto Refresh Check this box to enable Auto Refresh. Auto Refresh will automatically update the screen every 10 seconds.
  • Page 52 WEB INTERFACE Set Input to Default EDID Set Input to Default EDID Press this button from the Manage EDID screen to access this menu system. Set Default EDID Place a check mark next to the input(s) that should be set to the default EDID. Click the Set Default EDID button to apply the default EDID to the selected inputs.
  • Page 53 WEB INTERFACE Upload EDID Upload EDID Press this button from the Manage EDID screen to access this menu system. Load EDID file Place a check mark next to the input(s) that will receive the EDID data from the file. The EDID file must be in .bin format. Click the Browse button to locate the EDID on the computer. Click the Load EDID file button to upload the EDID file to the matrix.
  • Page 54 WEB INTERFACE Download EDID Download EDID Press this button from the Manage EDID screen to access this menu system. Download EDID File to PC Select the radio button next to the output, containing the EDID to be downloaded. Click the Download EDID File to PC button to confirm the change. The downloaded EDID file will be in .bin format.
  • Page 55 WEB INTERFACE Copy EDID Copy EDID Press this button from the Manage EDID screen to access this menu system. Select Source to Copy from / Select Input(s) to Copy to Click the radio button next to the input or output containing the EDID to copy. Note that only a single input or output can be selected at a time. Place a check mark next to the input(s) where the EDID will be copied. Click the Set EDID button to confirm the operation.
  • Page 56 WEB INTERFACE EDID Lock State EDID Lock State Press this button from the Manage EDID screen to access this menu system. Update EDID Lock State Secures the Local EDID and disables the automatic loading of the downstream EDID after the Matrix is powered on. Select the radio button next to the Off or On option then click the Update EDID Lock State button to apply the change. The EDID Lock State has no effect when the Dynamic EDID function is activated.

  • Page 57: Masking

    WEB INTERFACE Masking Matrix Mask Status / Change Displays the current masking status for each output. Mask Click the Mask button to mask the selected output. If the output is already masked then the button will read “Active” (enabled). Click the (“Active”) button again to toggle the masking state to “Mask” (disabled).

  • Page 58: Ip Configuration

    WEB INTERFACE IP Configuration IP Settings Assigns IP address, subnet, gateway, HTTP listening port, and Telnet port. Note that the MAC address can not be changed. Click the Save button to apply changes. The matrix must be rebooted for the changes to take effect. Telnet Login Settings Sets / forces the password for Telnet sessions to the matrix. Click the Save button to apply changes.
  • Page 59 WEB INTERFACE UDP Connection Settings Sets UDP remote IP and remote port. Also enables or disables UDP access to the matrix. Click the Save button to apply changes. Reset Click the Reset button to restore the factory-default IP settings.

  • Page 60: Backup / Restore

    WEB INTERFACE Backup / Restore The Backup / Restore feature for the 16x16 DVI Matrix is not currently implemented and will be available in a future release of the firmware.

  • Page 61: Power Management

    WEB INTERFACE Power Management Power Status Enabling this feature will store the +5V status for that input prior to shutting down the matrix. This preserves the +5V state when the unit is restarted. Power State Refresh The current Click to refresh power state is the Power listed under Status screen the column titled “5 Volt”. Click these buttons to toggle the input power state. Auto Refresh Check this box to Save Changes automatically Click to save the update the power lock status. screen every 10 seconds.
  • Page 62 WEB INTERFACE Power Lock State In the case of an accidental power loss to the matrix, the +5V state for each input can be preserved. Set the specified Power Status buttons (see previous page) and click the radio button next to ON. Click the Update Power Lock State button to apply changes. By default, this option is set to Off.

  • Page 63: Firmware Update

    FIRMWARE UPDATE Firmware Update Procedure The following items are required to update firmware: • RS-232 Terminal (e.g. Windows-based PC running HyperTerminal). • RS-232 cable (do not use a null-modem cable) • Firmware file: DVI16x16_e_x_x_x.bin To begin the update procedure the matrix Boot Loader must be activated. To activate the Boot Loader, follow the procedure below: Power-on the matrix. Connect an RS-232 cable to the PC and open the terminal program using the following settings: Baud rate: 19200 Stop bits: Data bits: Flow control: None Type the command: #activebolo 0 Once the Boot Loader is activated the following message should appear: Press [1] on the computer keyboard to begin downloading program to the temporary memory DVI16x16 Boot Loading ================== Main Menu =========================== Download new program -------- 1 Cancel ---------------------- 2 ======================================================== Press [1] on the computer keyboard to begin downloading program to the temporary...

  • Page 64: Warning Messages

    WARNING MESSAGES Fan Failure The 16x16 DVI Matrix uses an internal fan to maintain a stable operating temperature in various environments. In the case that the fan fails to start, an alert will appear on the LCM: FAN FAILURE! If the 16x16 Matrix is connected to a PC using a terminal program, the following message will appear on the display: Fan failure !!! This message will continue to be displayed at regular intervals until the fan is functioning. Although the DVI 16x16 Matrix is still functional, it is recommended that Gefen Technical Support be notified of the issue. See Asking for Assistance at the beginning of this manual. System Failure In the case of a critical malfunction, the following warning message will be displayed on the LCM: SYSTEM FAILURE! If the 16x16 Matrix is connected to a PC using a terminal program, the following message will appear on the display: System failure !!! The Matrix should be powered-down immediately and contact Gefen Technical Support. See Asking for Assistance at the beginning of this manual.
  • Page 65 WARNING MESSAGES Critical Malfunctions Temperature Failure If the measured system temperature exceeds 85° C, the following message will be displayed on the LCM: SYSTEM FAILURE! Power Failure If the power reading exceeds the tolerance rating (greater than 120% or less than 80%), the following message will be displayed on the LCM: SYSTEM FAILURE! In both cases, the Matrix will stop working and should be powered-down immediately and contact Gefen Technical Support under the Asking for Assistance section, at the beginning of this manual.

  • Page 66: Specifications

    SPECIFICATIONS Maximum Pixel Clock ....................165 MHz Input Video Signal ....................1.2 Volts p-p Video Input Connectors..........(16) DVI-I 29-pin, female (digital only) Video output Connectors..........(16) DVI-I 29-pin, female (digital only) IR Extender....................3.5 mm mini-stereo RS-232 Interface..................DB-9 serial, female Ethernet (IP control) port................RJ-45 (100BaseT) Power Supply..............100 ~ 240 V AC (x2 for redundancy) Power Consumption ..................60 Watts (max.) Operating Temperature..............+32 to +104 ˚F (0 to +45 ˚C) Storage Temperature..............-4 to +140 ˚F (-20 to +60 ˚C) Relative Humidity..............20% ~ 90% (no condensation) Dimensions (W x H x D) ........17.25’’ x 3.5” x 12” (438mm x 89mm x 305mm) Rack-mountable ..............2U rack space, rack ears included Shipping Weight .................... 30 lbs. (13.6 kg)

  • Page 67: Warranty

    This warranty is in lieu of all other warranties expressed or implied, including without limitation, any implied warranty or merchantability or fitness for any particular purpose, all of which are expressly disclaimed. Proof of sale may be required in order to claim warranty. Customers outside the US are responsible for shipping charges to and from Gefen. Copper cables are limited to a 30 day warranty and cables must be in their original condition. The information in this manual has been carefully checked and is believed to be accurate. However, Gefen assumes no responsibility for any inaccuracies that may be contained in this manual. In no event will Gefen be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. The technical information contained herein regarding the features and specifications is subject to change without notice. For the latest warranty coverage information, refer to the Warranty and Return Policy under the Support section of the Gefen Web site at www.gefen.com. PRODUCT REGISTRATION Please register your product online by visiting the Register Product page under the Support section of the Gefen Web site.

  • Page 68: Licensing

    LICENSING lwIP is licenced under the BSD licence: Copyright (c) 2001-2004 Swedish Institute of Computer Science. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution. The name of the author may not be used to endorse or promote products derived from this software without specific prior written permission. THIS SOFTWARE IS PROVIDED BY THE AUTHOR ``AS IS’’ AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
  • Page 72 Rev C16 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefen.com support@gefen.com This product uses UL or CE listed power supplies.
