- Page 1 InSTrUcTIonS FOR USE TV 2.0...
-
Page 2: Thank You
Thank you Thank you for choosing our product as your means to better hearing. To support your efforts, we have put great care and attention into making sure that your new TV adapter has the highest quality and is easy to use. The complete system description is documented online at www.oticonusa.com/ connectline... - Page 3 Indications for Use The TV adapter is intended to be used together with the Oticon Streamer or Oticon Streamer Pro and Oticon wireless hearing instruments. This enables the hearing instrument user to listen to the TV, by wirelessly sending the TV...
-
Page 4: Important Notice
ImporTanT noTIce Please familiarise yourself with the entire content of this booklet before using your TV adapter. It contains instructions and important information about the use and handling of your TV adapter. -
Page 5: Table Of Contents
contents Package content TV adapter overview Warnings Installation Placing the TV adapter Connecting the TV adapter to a power outlet Connecting the TV adapter to the TV Connecting using TOSLINK Connecting using RCA Connecting using mini jack adapter Connecting using SCART Pairing the Streamer to the TV adapter Turn on the TV sound Turn off the TV sound... -
Page 7: Package Content
package content The TV adaptor box consists of the following elements: TV adapter Power supply TOSLINK RCA cable InstructIons for use tV 2.0 SCART adapter Mini jack adapter This guide (Installation guide and Instructions for use) -
Page 8: Tv Adapter Overview
TV adapter overview Mode Power indicator TV indicator Power on, no connection to the Streamer In pairing mode Streaming - no audio input detected RCA inserted and streaming TOSLINK inserted and streaming (digital) TOSLINK inserted and streaming (invalid signal)* Fault condition ** No light Blinking Steady... - Page 9 Front Power indicator TV indicator Back SelectMe Power supply TOSLINK out TOSLINK in RCA left and right * For more information please refer to: www.oticonusa.com/connectline...
-
Page 10: Warnings
Warnings You should familiarize yourself fully with the following general warnings and the entire contents of this booklet before using your TV adapter. Products to be connected to external equipment • The safety of the use of the TV with RCA input cable is determined by external signal source. - Page 11 Warnings • The TV adapter is not a toy and therefore should be kept out of the reach of children and anyone else who might swallow parts or otherwise cause injury to themselves. Special attention should be paid to the smaller components in order to prevent children from swallowing them and choking.
-
Page 13: Installation
Installation Activating the TV adapter for the first time Before you can use the Streamer and your hearing aids with your TV, the TV adapter must be connected to a power outlet, connected to the TV and paired with your Streamer. This is a step-by-step guide on how to install the TV adapter. -
Page 14: Placing The Tv Adapter
placing the TV adapter There are two options of placing the TV adapter: 1. Close to the TV - placed horizontally (A). 2. Behind or close to the TV hanging on the wall (vertically) (screws not included) (B). -
Page 16: Connecting The Tv Adapter To A Power Outlet
connecting the TV adapter to a power outlet Start by connecting the TV adapter to a power outlet. Use the power supply from box 1 1. Plug the power cord into the “power” connector on the TV adapter (A). 2. Plug the power supply into the mains wall socket (B). 3. - Page 17 Box 1...
-
Page 18: Connecting The Tv Adapter To The Tv
SCART audio output (L+R) Mini jack audio output (typically headphone output) *Dolby Digital and the double-D symbol are registered trademarks of Dolby Laboratories. Please refer to the detailed specification of ConnectLine TV 2.0. (www.oticonusa.com/connectline) and your TV manual/specifications to ensure compatibility. - Page 19 TOSLink (p. 20) RCA (p. 22) Mini jack (p. 26) SCART (p. 24) * For more information please refer to: www.oticonusa.com/connectline...
-
Page 20: Connecting Using Toslink
connecting using ToSLInK 1. Use the TOSLINK cable from box no. 3 (A). 2. Remove the plastic cap from the TOSLINK cable. (B) 3. Connect the TOSLINK cable to the TOSLINK output on your TV/home theatre system (C). 4. Connect the TOSLINK cable to the pink TOSLINK input (D) on the TV adapter. 5. - Page 21 Box 3 Box 2...
-
Page 22: Connecting Using Rca
connecting using rca 1. Use the RCA cable from box no. 2 (A). 2. Connect the RCA cable to the RCA output on your TV (B) or home theatre system. (Typically marked “L – R AUDIO OUT” and found on the TV back or bottom panel.) 3. - Page 23 Box 2...
-
Page 24: Connecting Using Mini Jack Adapter
connecting using mini jack adapter 1. Use the mini jack adapter from box no. 2 (A). 2. Connect the RCA cable to the mini jack adapter (B1). 3. Connect the mini jack to the TV, this is typically the headphone output (B2). 4. - Page 25 Box 2 TV cord...
-
Page 26: Connecting Using Scart
connecting using ScarT 1. Use the SCART adapter from box no. 2 (A). 2. Connect the RCA cable to the red and white terminals on the SCART adapter (B). 3. Connect the SCART adapter to the SCART output on your TV (C). 4. - Page 27 Box 2...
-
Page 28: Pairing The Streamer To The Tv Adapter
pairing the Streamer to the TV adapter Before using your Streamer for TV listening, it must be paired to the TV adapter. For pairing: 1. Make sure the TV adapter is powered on, i.e. the power indicator is steady green. Press and hold the on/off button on the Streamer Pro (B) for 5-6 seconds (A) until the blue light starts blinking. - Page 29 Pairing Streamer 1.4...
- Page 30 Pairing Streamer Pro Streamer Pro Description top status front adapter Streamer and TV adapter on Streamer in pairing mode Pairing complete Streaming - no audio input detected RCA inserted and streaming TOSLINK inserted and streaming (digital) Steady Blinking...
-
Page 32: Volume Control
Volume control Use the volume button on the Streamer to adjust the TV volume level in the hearing instruments. Adjust the volume by pressing up or down briefly. Repeat the brief press for further adjustments. MUTE While watching TV it is possible to switch off the microphones in your hearing instruments, so that only the sound from the TV is heard. - Page 33 Volume up Mute Volume down Streamer Pro Streamer Pro...
-
Page 34: Turn On The Tv Sound
Start TV listening Make sure to wear the Streamer around your neck using the neck loop, and make sure the Streamer is powered on. Turn on the TV sound Briefl y press the TV button on the front of the Streamer. The Streamer connects to the TV adapter. - Page 35 Pairing Streamer Pro Streamer Pro Description top status front adapter Streamer and TV adapter on Streaming - no audio input detected RCA inserted and streaming TOSLINK inserted and streaming (digital)
-
Page 36: Selectme, Using More Than One Tv Adapter
Selectme, using more than one TV adapter With Streamer Pro 1.1 and later you can use multiple TV adapters. E.g. one in the living room and one in the bedroom. To switch between TV adapters: 1. Make sure you are not connected to any TV adapter i.e. the Streamer should be turned on, but not active. -
Page 38: Technical Information
Technical information The TV Adaptor contains a 2.4 GHz Transmitter. The emission power from the TV adapter is max. dBμV/m @ meters and is well below international emission limits for Human Exposure. This instrument contains a module with: FCC ID: XXXXXXXX XXXXXXXX The device complies with Part 15 of the FCC rules and RSS-210 of Industry Canada. - Page 39 This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. To comply with FCC RF exposure requirements, the device and the antenna for this device must be installed to ensure a minimum separation distance of 20 cm or more from a person’s body.
- Page 40 If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Relocate the receiving antenna.
- Page 41 Hereby, Oticon A/S declares that this TV adapter is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Declaration of conformity is available at: Oticon A/S Kongebakken 9 DK-2765 Smørum Denmark www.oticon.com xxxx Waste from electronic...
- Page 44 people First People First is our promise to empower people to communicate freely, interact naturally and participate actively 0000123570000001...
