Specifications - StarTech.com PCI1PM Instruction Manual

Specifications

PCI revision 2.3 (33MHz)
Bus Interface
3.3V/5V compatible
Form Factor
Full/Low Profile
Chipset ID
Sunix UL7512EQ
External Connectors
1 x DB25 female
IEEE 1284-1994
Supported Standards
(ECP/EPP/SPP/BPP)
Maximum Data Transfer Rate
1.8 Mbps
FIFO Buffer
16 Byte
Operating Temperature
0°C ~ 60°C (32°F ~ 140°F)
Storage Temperature
-20°C ~ 85°C (-4°F ~ 185°F)
Humidity
5% ~ 95% RH
Dimensions
121.0mm x 61.0mm x 13.0mm
Weight
75g
Windows XP/Server 2003/Vista/
Compatible Operating
Server 2008 R2/7 (32/64-bit),
Systems
DOS, Linux kernel 2.4.x/2.6.x
11
