SALES NETWORK
SAMSUNG TECHWIN CO., LTD.
•
Optics & Digital Imaging Division 145-3, Sangdaewon 1-Dong,
Jungwon-Gu, Sungnam, Kyungki-Do, Korea 462-703
TEL : 82-31-740-8137~41 FAX: 82-31-740-8145
SAMSUNG OPTO-ELECTRONICS UK LTD (SOUK)
•
Samsung House, 1000 Hillswood Drive Hillswood Business
Park Chertsey Surrey KT16 OPS
TEL : 44-(0)1932-45-5308
FAX: 44-(0)1932-45-5325
www.samsungtechwin.com
www.samsungcctv.com
SAMSUNG OPTO-ELECTRONICS AMERICA, INC. (SOA)
•
Closed Circuit Division 40 Seaview Drive, Secaucus N.J 07094,
U.S.A
TEL : (201) 902-0347 FAX: (201) 902-0429
TIANJIN SAMSUNG OPTO-ELECTRONICS CO., LTD (TSOE)
•
7 Pingchang Rd, Nankai Dist, Tianjin, P.R China
Post Code : 300190
TEL : 86-22-2761-9698 FAX: 86-22-2761-6514
P/No. : Z6806-0474-01A
VAN 04. 2
LENS BUILT IN
WDR COLOR CCD CAMERA
INSTRUCTION MANUAL
SOC-4120AN/P
About this manual
Before installing and using the camera, please read this manual carefully. Be sure to keep it handy for later reference.
SAMSUNG CCD CAMERA
Advertisement
Table of Contents
Related Manuals for Samsung SOC-4120AN
Summary of Contents for Samsung SOC-4120AN
-
Page 1: Instruction Manual
SAMSUNG OPTO-ELECTRONICS UK LTD (SOUK) TIANJIN SAMSUNG OPTO-ELECTRONICS CO., LTD (TSOE) • • Samsung House, 1000 Hillswood Drive Hillswood Business 7 Pingchang Rd, Nankai Dist, Tianjin, P.R China Park Chertsey Surrey KT16 OPS Post Code : 300190 TEL : 44-(0)1932-45-5308... - Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- Page 3 Reduction) CHIP Do not disassemble the camera. CCD having Double Speed 410,000 pixels SOC-4120AN/P has an assistant DSP chip SONY CCD, which provides clean, It may result in fire, electric shock or other hazards. that can remove image noise efficiently noiseless and reliable pictures.
-
Page 4: Table Of Contents
Contents Setting Up The Menu Precautions • CAMERA ID • BACKLIGHT Composition • WHITE BALANCE • MOTION DETECTION Name and Function of Each Part • IRIS LEVEL CONTROL Front • SHUTTER SPEED CONTROL Bottom • SENSE UP Back • GAIN •... -
Page 5: Precautions
Precautions Do not install the camera in Do not install or use the camera in an Do not drop the camera or subject Never keep the camera face to extreme temperature conditions. environment where the humidity is high. them to physical shocks. strong light directly. -
Page 6: Composition
Front Tripod Mounting Bracket Screw Hole Used to fix the Tripod mounting bracket on the 1. WDR Color CCD Camera top of the camera. SOC-4120AN/P 2. Remote Plug Control Cover Used to access focus or zoom handle Zoom Handle To adjust zoom maginification by turning. -
Page 7: Bottom
Name and Function of Each Section Bottom Back Power LED Video Output Jack Tripod Mounting Hole The LED turns on Used to connect an external Used to install the camera on an optional when power is supplied. video monitor in jack. tripod. -
Page 8: Connection
Connection Connecting to Monitor Connecting to Power Connect the VIDEO Out jack to the monitor VIDEO In jack. CCD Camera Monitor • Use AC 24V/300mA or DC 12V/500mA power source for SOC-4120N/P. • As the connecting method varies with the instruments, refer to the manual Resistance of copper wire [at 20C˚... -
Page 9: Operating Your Camera
Operating Your Camera Configuration of The Menu Setting Up The Menu Use the five SETUP MENU buttons on back of the camera. SETUP MENU CAMERA ID (see page 18) • OFF • ON BACKLIGHT (see page 21) UP button • WDR •... -
Page 10: Camera Id
Operating Your Camera 3. Press SET button. SETUP CAMERA ID Change the status using Select the function using the UP or DOWN button. BACKLIGHT the LEFT or RIGHT button. CANERA ID WHITE BAL. W-ATW MOTION DET. IRIS LEVEL SHUTTER SENSE UP CLR RESET END GAIN AGC-L... -
Page 11: Backlight
Operating Your Camera 5. Select the position at which the CAMERA ID will be located on the screen. BACKLIGHT Move the cursor to 'POS' and press SET button. SV-II DSP chip built-in provides intelligent light level control to overcome the severe Backlight conditions. -
Page 12: White Balance
Operating Your Camera 4. When completed, press the SET button. S-ATW(Special Auto Tracking White balance): When color temperature is 1800~6000K, specially in sodium lamp, select this mode. (EX. sodium lamp, inside the Notes tunnel) • If you select WDR mode, the following phenomenon may appear by lighting AWC(Auto White balance Control): The white balance is automatically adjusted condition. - Page 13 Operating Your Camera 2. Set ‘MOTION DET.’ to the desired mode using LEFT or RIGHT button. SETUP CAMERA ID BACKLIGHT WHITE BAL. W-ATW MOTION DET. IRIS LEVEL Maximum Minimum SHUTTER · When completed, press SET button. MD1: Your camera detects the object’s motion by outline or difference of a MD2: Your camera detects object’s motion by the variation of brightness, so color tone, so this mode is very useful for the daytime or observing this mode is very useful for night or observing large moving object.
-
Page 14: Iris Level Control
Operating Your Camera Notes SETUP CAMERA ID Tips on Using the Motion Detection Feature BACKLIGHT WHITE BAL. W-ATW • As you increase or decrease MD LEVEL, the areas’ sensitivity is increased or MOTION DET. decreased for object. IRIS LEVEL • After selecting zone and sensitivity, perform a test operation to make sure it SHUTTER works properly. -
Page 15: Sense Up
Operating Your Camera Notes MANUAL SET MANUAL SET VALUE : 1/60 VALUE : 1/50 • If you press the set button on ‘AUTO’ mode. You can adjust brightness by increasing PRESS SET TO RETURN PRESS SET TO RETURN or decreasing the shutter speed. (EX. x2,.., x32, x64, .., x128) •... -
Page 16: Ssnr
Operating Your Camera SSNR(Samsung Super Noise Reduction) SPECIAL To reduce the noise on the screen. 1. Press the SET button to display the setup menu and move the arrow indicator to ‘SSNR’ using the UP or DOWN button. 2. Set ‘SSNR’ to desired mode using the LEFT or RIGHT mode. -
Page 17: Using Remote Jack / Md Output
Operating Your Camera Using Remote Jack / MD Output If you connect a remote plug to the REMOTE jack on the rear of the camera Notes as shown below, you can access the menu setup mode from a remote place. •... -
Page 18: Troubleshooting
Troubleshooting If you have trouble operating your camera, refer to the following table. If the Problem Solution guidelines do not enable you to solve the problem, contact an authorized technician. The color of the picture • Check that you have properly set the ‘WHITE BAL.’ is not matched. -
Page 19: Declaration Of Conformity
Application of Council Directive(s) 89 / 336 / EEC SOC-4120AN SOC-4120AP Item Manufacturer's Name SAMSUNG TECHWIN CO., LTD Power Source DC 12V / AC 24V compatible Manufacturer's Address SAMSUNG TECHWIN CO., LTD Power Consumption 280mA (DC) / 3.8 W (AC) - Page 20 MEMO MEMO...
