DECK MECHANISM PARTS LOCATION
• Top View (With Tray)
• Top View (Without Tray)

• Bottom View

Procedure
Parts
Starting No.
1 Holder Assembly
Clamp
1 2 Plate Calmp
1,2 3 Magnet Clamp
1,2,3 4 Upper Clamp
1,2,3,4 5 Holder Clamp
6 Base Assembly Tray
7 Tray Disc
6 8 Roller Base Tray
6 9 PCB Assembly Tray
6,7 10 Motor Assembly Tray
6,7,10 11 Gear Tray
6,7,10,11 12 Gear Wheel Tray
6,7,8,9,10, 13 Base Tray
11,12
1 14 Frame Assemly
Up/Down
15 PCB Assembly
Junction
1 16 Base Assembly Sled
Damper
1 17 Gear Assembly Feed
1,17 18 Gear Middle
1,17 19 Gear Assembly Rack
1 20 Rubber Damper
1,15,16,17, 21 Frame Up/Down
18,19,20
1,14 22 Base Assembly Main
23 PCB Assembly Main
Mode
6 24 Gear Slider
6,24 25 Gear Exchange
6,24 26 Gear Main
6,24,26 27 Gear Up/Down
6,24,26 28 Gear Wheel Main
6,24,26,28 29 Gear Loading
6,28 30 Motor Assembly Main
1,6,14,23, 31 Base Main
24,25,26,
27,28,29,
30
Note
When reassembling, perform the procedure in
reverse order.
The "Bottom" on Disassembly column of above
Table indicates the part should be disassembled
at the Bottom side.
2-2
Disass Fig-
Fixing Type
embly ure
3 Screws Top 4-1
2 Connectors
1 Hook
Top 4-1
Top 4-1
Top 4-1
Top 4-1
2 Locking Tabs Top 4-2
1 Screw Top 4-2
2 Locking Tabs Bottom 4-2
2 Screws Bottom 4-2
1 Connector
2 Screws Top 4-2
Top 4-2
Top 4-2
Top 4-2
1 Screw Top 4-3
2 Screws Bottom 4-3
5 Connectors
4 Screws Top 4-3
1 Connector
1 Locking Tab Top 4-3
Top 4-3
1 Screw Top 4-3
Top 4-3
Top 4-3
Top 4-4
2 Connectors Bottom 4-4
3 Screws
1 Screw Top 4-4
1 Screw Top 4-4
1 Screw Top 4-4
1 Screw Top 4-4
1 Screw Top 4-4
Top 4-4
2 Screws Top 4-4
1 Locking Tab
Top 4-4
