R E M O T E C O N T R O L
POWER BUTTON
REPEAT BUTTON
SETUP BUTTON
SUBTITLE BUTTON
AUDIO BUTTON
***TOP MENU BUTTON
**ARROW BUTTONS
SELECT/ENTER BUTTON
ZOOM BUTTON
SCAN BUTTONS
PAUSE BUTTON
Number buttons
*MENU BUTTON
USE THE MENU BUTTON TO DISPLAY THE
MENU SCREEN INCLUDED ON SELECTED
DVD VIDEO DISCS. TO OPERATE A MENU
SCREEN, FOLLOW THE INSTRUCTIONS IN
"USING A DVD MENU" .
This remote control supports two remote control codes: C1 and C2.
When the unit is shipped from the factory the remote control is set to C1.
To set the remote control to C2, hold down both the STOP button and "2" number button on the remote control for at least five seconds.
(If the batteries in the remote control are replaced while the remote control is set to C2, the setting will revert C1.)
To set the remote control back to C1, hold down both the STOP button and "1" number button on the remote control for at least five
seconds.
Also set the remote control codes of the player to the same setting as the remote control. (This setting is set to C1, when the unit is
shipped from the factory)
POWER
SETUP
AUDIO
TOP MENU
OSD
OSD BUTTON
ZOOM
PLAY BUTTON
CLEAR button
OPEN/CLOSE
REPEAT A-B RANDOM
SUBTITLE ANGLE SURR.
MENU
SELECT
/ENTER
RETURN
MARKER – SEARCH DISC SKIP
SCAN SKIP
PLAY
STOP
PAUSE SLOW
1 2 3
4 5 6
7 8 9
CLEAR PROGRAM
0
**DIRECTIONAL ARROW BUTTONS
(UP, DOWN, LEFT, RIGHT) FOR USE IN
HIGHLIGHTING A SELECTION ON A GUI MENU
SCREEN, TITLE AND MENU SCREEN.
***TOP MENU BUTTON
USE THE TOP MENU BUTTON TO DISPLAY
THE TITLE MENU INCLUDED ON SELECTED
DVD VIDEO DISCS. TO OPERATE A MENU
SCREEN, FOLLOW THE INSTRUCTIONS IN
"USING A TITLE MENU" .
9
OPEN/CLOSE BUTTON
A-B BUTTON
RANDOM BUTTON
ANGLE BUTTON
SURR. BUTTON
*MENU BUTTON
RETURN BUTTON
DISC SKIP BUTTON
MARKER-SEARCH BUTTONS
SKIP BUTTONS
STOP BUTTON
SLOW BUTTONS
PROGRAM BUTTON
