AGA ELECTRIC - AIMS
EC & EE COOKER
OWNERS MANUAL
Comprising
Installation & Users
Instructions
REMEMBER: when replacing a part on this appliance, use only spare parts that
you can be assured conform to the safety and performance specification that we
require. Do not use reconditioned or copy parts that have not been clearly
authorised by AGA.
PLEASE READ THESE INSTRUCTIONS BEFORE INSTALLING AND USING THIS APPLIANCE
For use in GB and IE
04/14 EINS 515923
Advertisement
Table of Contents
Related Manuals for AGA EC
Summary of Contents for AGA EC
- Page 1 AGA ELECTRIC - AIMS EC & EE COOKER OWNERS MANUAL Comprising Installation & Users Instructions REMEMBER: when replacing a part on this appliance, use only spare parts that you can be assured conform to the safety and performance specification that we require.
-
Page 2: Table Of Contents
HEALTH & SAFETY THE AGA COOKER OPERATING THE AGA 14 - 15 POWERED OVEN VENTING GUIDE TO AGA COOKING AIMS (AGA INTELLIGENT MANAGEMENT SYSTEM) 17 AIMS CONTROLLER HANDSET 17 - 18 INFORMATION (MAIN MENU) SCREEN SETTINGS DATE/TIME SCREEN AIMS PROGRAMME SCREEN... -
Page 3: Installation Section
RH side for oven doors access. If the AGA is to be installed in a brick recess, then the minimum clearance should be increased by at least 10mm on either side, to allow for the walls not being square and also for the natural dimensional variations found in the castings. -
Page 4: Installation
It should be in accordance also with any relevant requirements of the local authority. In your own interest, and that of safety to comply with the law, all appliances should be installed by an authorised AGA distributor, in accordance with the relevant regulations. -
Page 5: Electrical
EE-LMV MODEL THIS HOLE IF REQUIRED FOR OVEN VENT PIPE IS TO BE CUT ON SITE IN THE LEFT OR RIGHT HAND SIDE PANEL. Fig. 1A mm 1487 889 851 679 1330 756 1125 698 484 816 52 790 873 55 699 662 ELECTRICAL WARNING: THIS APPLIANCE MUST BE EARTHED. -
Page 6: Instructions
Hand this Owners Manual to the User for retention and instruct in the safe operation of the appliance. Also advise the user that, for continued efficient and safe operation of the appliance that servicing is carried out at intervals recommended by the Aga distributor. ELECTRICAL TEST PROCEDURE... -
Page 7: To Test The Aims Control Handset
TO TEST THE AIMS CONTROL HANDSET Fig. 3 DESN 515291 Press the fan button on the handset, the vent fan symbol should show on the handset screen. The oven vent fan should operate and the fan oven neon on the control panel should illuminate. Press the fan button again and the fan should go off. -
Page 8: Oven Vent Pipe Connection Options
Fig. 5 DESN 515284 OVEN VENT PIPE CONNECTION OPTIONS Fig. 6 DESN 513987... -
Page 9: Oven Venting Systems
OVEN VENTING SYSTEMS See Figs. 7, 8, 9 & 10 Pre-site visiting will have determined where and how the layout of the oven vent pipework should be designed and installed. It is then necessary to check that the pipework design and the pipework resistance are within the parameters possible. - Page 10 Fig. 8 Fig. 7 DESN 515608 DESN 513938 Fig. 9 DESN 516111...
-
Page 11: Aims Handset
AIMS HANDSET Consumer Protection AIMS HANDSET Handset can be wall mounted as described below. Remove backplate from the rear of the Handset by sliding down with hand and away from the Handset (fig 10). Select the site for the handset and use the backplate to mark the position of fixing holes. Drill 6mm dia. -
Page 12: User Guide
Children should be supervised to ensure that they do not play with the appliance. IMPORTANT NOTICE: PLEASE READ THE ACCOMPANYING WARRANTY. Any alteration that is not approved by AGA could invalidate the approval of the appliance, operation of the warranty and could also affect your statutory rights. -
Page 13: The Aga Cooker
1 Half size roasting tin with grill rack 2 Oven grid shelves 1 Plain shelf 1 Toaster 1 AGA book 1 Wire brush A full description of cooking with the AGA is given in the AGA book. Fig. 13 DESN 513946... -
Page 14: Operating The Aga
Controls:- located behind the top left hand door Fig. 14 DESN 515283 Switch on the AGA’s electricity supply. Turn the right hand control knob from the OFF setting to the Normal manual control setting.The cooker will heat up until it reaches its Normal operating temperature which is set by the temperature control knob. (Turn clockwise to increase temperature). - Page 15 When first switched on, the AGA will emit an odour for a short while. This is simply due to protective oil burning off the hotplates. Wipe the inside of the lids whilst the AGA is heating up to avoid a film of this oil being deposited on the inside of the lids.
-
Page 16: Powered Oven Venting
REMEMBER: SWITCH THE FAN OFF WHEN YOU HAVE FINISHED COOKING. GUIDE TO AGA COOKING As the AGA Cooker is heated differently from an ordinary cooker, exact conversions are not possible. Look in the AGA Book for a similar recipe. Below is a quick guide to oven usage. -
Page 17: Aims (Aga Intelligent Management System)
AIMS CONTROL HANDSET What is AIMS? The AIMS program is flexible. In short, it means the AGA can sleep when you sleep and only operate at normal when you need it. The technology is simple to use and can result in significant fuel savings. - Page 18 The AIMS one or two programmable events. The two events programme will enable the AGA to be at ‘Normal’ in the morning, (i.e. to cook breakfast) drop to a lower temperature during the day, and return to ‘Normal’ in the evening (i.e. to cook dinner) and drop to ‘Slumber’ later in the evening and throughout the night.
-
Page 19: Information (Main Menu) Screen
(Normal, Low or Slumber). If an arrow is automatically (AIMS) or manually showing this indicates the cooker is (according to switch position on main AGA heating up from Low or Slumber to Normal. control panel) Black band - correct amount of... -
Page 20: Aims Programme Screen
AIMS PROGRAMME SCREEN Use the button to activate this screen and to move through the different actions and set an AIMS programme. To go back a step at any time press 1. Set the frequency of the programme Once or Twice daily using + and - buttons. 2. - Page 21 AIMS calibration resulting in failed heat-up times. AIMS POINTS TO REMEMBER 1. An AGA contains a large thermal mass of cast iron, consequently the appliance will retain its heat and there will be a long period of time before there is any noticeable drop in temperature.
-
Page 22: Holiday Screen
THE HOLIDAY SCREEN Press the button to activate this screen and to move through the different operations and set a holiday programme. 1. Set a start date and time using the + or - buttons. Pressing the button after each field has been entered to move you to the next field. -
Page 23: Aims - Frequently Asked Questions
The Base Station memory of the time of day will not be affected, but if the power cut coincides with the powering up of the AGA this will be affected - an absence of electricity means the AGA cannot power up to the mode required until the electricity is restored. -
Page 24: Aims Handset Care
Complete the following procedure to check the handset is communicating with the base unit and to select a language option. 1. Press and hold the oven vent fan button on the control panel in the Aga until the blue neon vent fan indicator flashes, then release button. -
Page 25: Fitting Of Oven Shelves
FITTING OF OVEN SHELVES When using the oven shelves for the first time follow Figs. 24a - 24d. Fig. 24a Fig. 24b DESN 512403 DESN 512404 REMOVAL OF OVEN SHELVES Fig. 24c Fig. 24d DESN 512405 DESN 512406... -
Page 26: Caring And Cleaning For The Aga
Top Plate and Front Plate The easiest way to clean the AGA top plate and front plate is to mop up spills as they happen. Baked-on food is more difficult to clean but can usually be removed with AGA vitreous enamel cleaner or mild cream cleaners using a cloth, or, if necessary, a nylon scouring pad. - Page 28 For further advice or information contact your local AGA Specialist With AGA Rangemaster's policy of continuous product improvement, the Company reserves the right to change specifications and make modifications to the appliance described and illustrated at any time. Manufactured by...
