BIPAC-645
DSL/Cable Router Plus ISDN Router
With 4-Port 10/100M LAN Switch
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIPAC-645 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Billion BIPAC-645

Summary of Contents for Billion BIPAC-645

  • Page 1 BIPAC-645 DSL/Cable Router Plus ISDN Router With 4-Port 10/100M LAN Switch User’s Manual...

  • Page 2: Table Of Contents

    Table of Contents 1 ............................... 1 HAPTER ........................... 1 NTRODUCTION 1.1 An overview of the Router device ....................... 1 1.2 Package contents..........................1 1.3 This Router Features..........................1 1.4 This Router Device Application ......................2 2 ............................... 3 HAPTER ..........................3 SING THE OUTER 2.1 Cautions for using the Router ......................

  • Page 3: Chapter 1

    In addition, BIPAC-645 supports remote ISDN dial-in and remote access. BIPAC-645 is a small desktop router that sits between your local Ethernet network and a remote network (For example, the Internet or a remote office). It contains an ISDN S/T interface, a 10 Mbps WAN port, four 10/100 Base-T LAN ports, and an auxiliary port for a directly connected management console.

  • Page 4: This Router Device Application

    Supports IP sharing function, allowing multiple users share one internet account. Supports industry standard Point-to-Point Protocol (PPP), Multilink PPP, and PPPoE. Supports Dial-on-Demand and Bandwidth on Demand function. User-friendly management through web-based configurator, telnet management, console port management, and remote upgrades. PAP/CHAP/MS-CHAP, Call Back, IP Packet Filtering, and Caller ID Authentication for firewall security.

  • Page 5: Chapter 2

    Do not place BIPAC-645 under high humidity and high temperature. Do not use the same power source for BIPAC-645 with other equipment. Do not open or repair the case yourself. If BIPAC-645 is too hot, turn off the power immediately and have a qualified serviceman repair it.

  • Page 6: The Rear Ports

    (RJ-45 connector) the Internet or making other WAN connections 2.4 Cabling Now you should be ready to connect your BIPAC-645 on your LAN and WAN or ISDN jacks. Follow these steps to install: • Connect the router from EWAN port to an ADSL/cable modem, or attach the ISDN line to the ISDN connector (S/T interface).
  • Page 7 • The Auxiliary connector is only used to connect a terminal to run the Command Line Interface using the null modem cable. (This is an optional connection.) • There is a DIPswitch located on the rear panel for setting the terminating resistor. You only need to adjust this switch if there are two or more external ISDN equipments attached to the local telephone line.

  • Page 8: Chapter 3

    This section describes the configuration required by LAN-attached PCs that communicate with BIPAC-645, either to configure the BIPAC-645, or for network access. These PCs must have an Ethernet interface installed properly, be connected to the BIPAC-645 either directly or through an external repeater hub, and have TCP/IP installed and configured to obtain an IP address through a DHCP server.
  • Page 9 3. Select Obtain address automatically radio button. 4. Then select Configuration tab. 5. Select the Disable DNS radio button and click OK to finish the configuration.
  • Page 10 Configuring PC in Windows NT4.0 1. Go to Start/Settings/ Control Panel. In the Control Panel double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click OK.

  • Page 11: Configuring Pc In Windows 2000

    Configuring PC in Windows 2000 1. Go to Start/Settings/Control Panel. In the Control Panel double-click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties.

  • Page 12: Configuring With Gui Program

    3.2.1 Using Different Browsers for BIPAC-645 To configure your BIPAC-645, you can use a popular browser, such as Netscape 4.x and Internet Explorer 5.x. The following describes how to use it to start “Local Router Manager” through IE or Navigator.
  • Page 13 For example, if you select Basic Internet Access only, the interface will only display buttons that you need for basic Internet access. If you subsequently use Local Router Manager to configure BIPAC-645 for other applications, you can return to this screen to “re-customize” your interface by selecting Customize User Interface from the...
  • Page 14 You will find that BIPAC-645 is optimized for Basic Internet Access. You don’t need to understand, to apply for or to assign any IP addresses in your entire network. BIPAC-645 does these things for you automatically. You need to configure each device on your LAN in a uniform way described in Chapter 2.
  • Page 15 What is Basic Internet Access? It means accessing the Internet, surfing the web, accessing a remote FTP server (to send or receive files), and sending and receiving e-mail. These are the tasks that users perform most. When you apply for an account with your Internet Service Provider (ISP), you will be given the username, password, and other necessary information.
  • Page 16 Profile Name: the name that you will use to identify this Internet access profile. EWAN IP Address: the IP address of your EWAN. EWAN IP Netmask: the IP Netmask of your EWAN. ISP Gateway IP Address: the IP Address of your ISP Gateway Primary DNS IP Address: the IP Address of your Primary DNS.
  • Page 17 Idle Timeout (0-3600 seconds): The default value of the idle timeout is 120 seconds. It represents the number of seconds of inactivity over the connection: when this value is reached, BIPAC-645 will disconnect the connection. You can change the idle timeout value to anything between 0 to 3600 seconds.
  • Page 18 Step 2: Select I use Internet Access over ISDN and then click Next. Step 3: Select ISDN in the Configuration Menu and the following screen will appear. Step 4: Select the ISDN switch type that your ISP will tell you. Step 5: Select the number of the directory phone numbers and enter the directory phone numbers in the corresponding blanks.
  • Page 19 After completing basic Internet access configurations via ISDN, now you can set advanced ISDN Configuration if you back to the Local Router Manager screen and select Internet Access with Advanced Configuration. Step 1: After entering the following parameters as the way described in the previous section. Click Advanced.
  • Page 20 3.2.7 IP Configuration for Internet Access Using IP options in the Menu Window, you can assign a public IP address to the BIPAC-645, modify the private IP address, DNS addresses, and enable or disable DHCP.

  • Page 21: The Ip Routing Table

    3.2.8 The IP Routing Table The IP Routing Table contains all the information that the BIPAC-645 needs to route an IP data packet. You can view the IP Routing Table by clicking on the Routing button at the bottom of the Advanced Internet Access Setup screen (described in the previous section).
  • Page 22 3.2.9 IP Address Translation Configuration For security and economic purposes, BIPAC-645 supports Single User Account feature (SUA). Multiple users in the LAN can share a public IP address from ISP and Internet users will view the whole LAN as a big “device”.
  • Page 23 3.2.10 Add or Edit IP Address Translation Step 1: Click Address Translation button in the Advanced Internet Access Setup screen. The following IP Address Translation Configuration screen will appear. Step 2: Click Add for adding a set of IP address translation, or click Edit for editing an existing set of IP address translation after selecting the set of IP address translation that you want to edit.
  • Page 24 3.2.11 Static DHCP Configuration By built-in DHCP feature, the device can automatically assign a private IP address to each PC or workstation in the LAN. But under some situations, you need to set a static private IP address for certain PCs or workstations.

  • Page 25: Chapter 4

    Chapter 4 Remote Configuration The remote site does not have to have a router, and may not be configurable by the local administrator. Make sure the configuration matches the requirements of the remote site. 4.1 Remote Office Access by ISDN To configuring the ISDN interface for Remote Office connectivity, follow these steps: Step 1: Select Access to/from Remote Site in the Local Router Manager screen and click Next: Step 2: If you have already configured your ISDN interface, skip to Step 3.
  • Page 26 Profile Name: a name associated with this profile. Call Direction: if the remote site will be dialing in, select Incoming. If the BIPAC-645 will dial out to the remote site, select Outgoing. Select Both if either side can initiate the connection. The default setting is Both.

  • Page 27: Advanced Options For Remote Office Access Profiles

    4.2 Advanced Options for Remote Office Access Profiles If you press the Advanced button from the above Connection Profile Configuration, the following screen appears. Step 1: Set any of the following parameters: Data Service: choose 64K, 56K, or Auto. Select Auto unless you know the speed required by the other end of the connection requiring either 64K or 56K.

  • Page 28: Deleting Remote Office Access Profile

    Step 3: Click OK after completing the parameters in the following windows. Step 4: Skip to step 6 or click Alternative Numbers if it is required to set more than one choice of remote phone numbers. The screen will appears as follows, Step 5: Select the Number of Alternative Remote Phone Numbers and then enter the remote phone numbers in the corresponding blanks.

  • Page 29: Chapter 5

    Chapter 5 Dial-in User Access Configuration 5.1 Configuring a Dial-in User Profile Step 1: Select Dial-in Access for Off-Site Users in the Local Router Manager screen. Step 2: Select Connection Profiles from the Menu Window. Information about each dial-in user who is allowed to access is stored in a “connection profile.”...

  • Page 30: Deleting Dial-In User Profiles

    Step 6: Enter the information: Step 7: Click OK to return to the previous screen and click APPLY to add the connection profile to its database. Otherwise click Multilink if advanced configuration is required for the operation on the ISDN, and its load sharing capabilities.
  • Page 31 Step 1: From the IP Filtering Configuration screen, select the WAN profile of interest from the pull down menu. For example, if your only need is to access the Internet, you should only select the Internet access profile. Step 2: Select send or discarded as desired, which is equivalent to allow and disallow, respectively. Step 3: If you are just starting, click Add to add a new selection rule.

  • Page 32: Chapter 6

    6.1 How to View the Connection Log BIPAC-645 provides a connection log that you can use to track the telephone connections in and out of your BIPAC-645. Connect and disconnect messages can be useful in determining your telephone costs, and trigger messages are useful in determining which applications and tasks trigger a connection.

  • Page 33: How To Reset

    Step 2: Click YES to reset BIPAC-645. 6.4 How to Change the BIPAC-645 Manager Password After you start using the BIPAC-645, you should change the factory default password. Follow the steps to change the password. Step 1: Select Change Password from the System Tools Menu: The following screen displays:...

  • Page 34: What If I Forget The Password

    HyperTerminal) to Router Console port. The default port settings are 19200, N, 8, 1, no flow control. Step 2: Turn off the BIPAC-645, and then turn it on again. In the console window, you’ll see the message “Loading firmware...”.

  • Page 35: Chapter 7

    IP addresses and globally unique public IP addresses," by which the box can "translate" the private IP addresses to public IP address and vice versa. BIPAC-645 supports the feature of NAT. With proper configuration, multiple users can access the Internet using a single account via the NAT device.
  • Page 36 Why do I spend longer time to update firmware in GUI screen? Answer. Because the GUI of BIPAC-645 was written by JAVA program, we would like to suggest user to use Netscape Navigator, and please enable JAVA function under Internet Explorer environment. Please also keep in mind to close other application programs while updating firmware.
  • Page 37 Answer. Due to the consideration of security, you only can set up Profile in GUI Mode, and for the LAN; it only can be revised under the CLI Mode. Solution. Connect the PC to BIPAC-645 with a null modem type cable and enter CLI mode to start IP Filtering by Telnet or Hyper-terminal.
  • Page 38 7. Therefore, it will recover the default password while the router reboot automatically. Why does BIPAC-645 connect with ISP sometimes automatically? Answer. BIPAC-645 will build up connected function once LAN’s PC has any packet need to send. This function calls Dial on Demand.

  • Page 39: Appendix A

    Appendix A Console Commands General Guidelines When the router is powered up, the user can connect a terminal (or the PC running terminal emulation software) to the auxiliary (console) port to perform configuration and management functions. Alternatively, the Command Line Interface may be accessed via a standard telnet application. When properly connected, setting the console speed to a baud rate of 19200 bits per second, eight data bits, no parity, one stop bit, and pressing a carriage return key, the user will see a system sign-on message followed by a password prompt as follows.

  • Page 40: Express Mode" Vs. "Advanced Mode

    • If a keyword is expected when the user types “ ?”, all valid keywords will be displayed, then the command typed so far will be re-displayed, with the cursor sitting at the end (waiting for the user to continue). •...

  • Page 41: Command Categories

    The following notations will be used: lan means the LAN port; <> specifies the arguments of the command, <1-4> means a number between 1 to 4; [ ] indicates a required or optional parameter, or choice of parameters; • Interface Name or ifName represents a profile interface, which can be the LAN port (lan), a PPP profile, a PPPoE profile, an ISDN connection profile, or a modem profile.

  • Page 42: Command List

    Example: Router> command (with parameters) Output … Command List Note that commands may apply either to a specific router model or with a particular Feature Key enabled. Each command below which is affected, is identified by a symbol which is associated with either a router model or a Feature Key as follows: In addition, those commands which involve an interactive user dialog are prefixed with the symbol, “⊕”.

  • Page 43: Diagnostic Commands

    delete dns <primary/secondary> disable dhcp enable dhcp ⊕set dhcp ⊕set range show dhcp show dhcp table show range Diagnostic Commands connect profile <Profile Name> disable trace disconnect profile <Profile Name> enable trace ping <ip_addr> [integer greater than 0][packet length, greater than or equal to 56] set log level <1-10>...
  • Page 44 show filter show filter <1-8> IP Commands add ip route <ip_addr> <Network Mask> <ip_addr> <hop count, 1-15> add ip route <ip_addr> <Network Mask> <Profile Name> <hop count, 1-15> ⊕add pat entry <public port #> ⊕add pat entry default delete ip default route delete ip route <ip_addr>...

  • Page 45: Port Commands

    show icmp statistics show ip show ip <interface name> show ip routing table show ip statistics show pat show tcp statistics show udp statistics Port Commands clear port statistics [port name] disable port <port name> enable port <port name> ⊕set port <port name> show port show port <port name>...

  • Page 46: Security Command

    show profile show profile <Profile Name> show profile statistics show profile statistics <Profile Name> Security Command set ip private <ip_Addr><netMask> SNMP Commands clear trap manager <1-5> disable trap enable trap set community string read <string up to 30 characters, inclusive> set trap manager <1-5>...

  • Page 47: System Commands

    show tcp statistics show udp statistics show <Interface Name> statistics System Commands change password clear config disable remote-mgt enable remote-mgt disconnect telnet session <1-5> download config <file_name> from <ip_addr> download firmware help logout reset system save config set console baud <baudrate> set console timeout <timeout value, 1- 60>...
  • Page 48 set system name <string up to 30 characters, inclusive> set time <hh:mm:ss> set timezone <-12:00 - +12:00> show config show connection log show interface list show internet access time show system show system log show telnet session show time upload config <string up to 60 characters, inclusive> to <ip_addr>...

  • Page 49: Command Detail

    Command Detail Bridging Commands Although routing is preferred over bridging for transmitting data across wide area connections, occasionally bridging is required. For example, when the data packets to be transmitted are neither IP nor IPX (such as NetBEUI, SNA or AppleTalk), or when the other end of the WAN connection only supports bridging.

  • Page 50: Show Learning

    show learning Description: This command displays MAC addresses learned from all bridging-enabled interfaces. Example: Router> show learning lan: MAC Address ------------------------------------------------ 12-22-33-3D-D5-00 00-60-54-16-67-01 00-96-33-58-BD-DE Total MAC addresses: 3 newyork: MAC Address ------------------------------------------------ 00-40-33-3D-D5-DB 00-60-20-16-00-01 00-40-33-58-07-DE Total MAC addresses: 3 show learning <Interface Name> Description: This command displays MAC addresses learned from a specified interface.

  • Page 51: Dhcp Commands

    disable compression <Profile Name> Description: This command disables compression over the specified interface. enable compression <Profile Name> Description: This command enables compression over the specified interface. show compression statistics <Profile Name> Description: This command displays compression related statistics for the specified interface. DHCP Commands The Dynamic Host Control Protocol (DHCP) is a client/server protocol that defines an efficient and...

  • Page 52: Disable Dhcp

    Once configured, the DHCP server will assign private addresses from within the defined private address range with the highest available address being assigned first. This address range may be modified using the “set range” command. Statically assigned addresses must be within this range as well. Up to 20 static DHCP assignments may be configured and saved.

  • Page 53: Show Dhcp

    is 192.168.168.230, unless re-configured with the “set ip private…” command (or its HTTP equivalent). The term of the lease is 10 hours. The factory default is enabled. ⊕ ⊕ ⊕ ⊕ set dhcp Description: This command configures the global parameters to be supplied to all requesting DHCP clients.

  • Page 54: Show Dhcp Table

    Router> show dhcp Admin Status: Enable Default Lease: 10 hours Network address: 192.168.168.0 Netmask: 255.255.255.0 Default gateway: 192.168.168.230 Primary DNS: 199.191.129.139 Secondary DNS: 199.191.144.75 Primary WINS: 63.221.98.5 Secondary WINS:63.221.98.7 Node Type h-node IP-Address Mac-Addr Lease-Expires Entry Type ----------------------------------------------------------------- 192.168.168.134 00400535db4f 06-15-99 14:24:5 Static 192.168.168.254 222222222222...
  • Page 55 enable trace Description: This command enables the debug trace messages. When enabled, all log messages entered into the system log will appear in the console session from which this command is issued. ping ipAddr [<n_times> < n_size>] Description: This command allows the user to ping an IP device (send a diagnostic message to be echoed by the receiving device).
  • Page 56 Example 1: Add the following Single Workstation dialing into a router using the CLI Express Mode (you can toggle between Express Mode and Advanced Mode by using the Ctrl-E key combination) Router> add user u1 Add new user profile "u1" ... user name (Unspecified): user1 user password (Unspecified): *** password confirm (***): ***...
  • Page 57 show user [profile name] Description: Displays the current local profile database. Example 1: Without the user name parameter the output appears as follows. Router> show user profile name: u2 user name: user2 dial in from: Workstation enable IP: IP RIP: Disable profile name: u1 user name:...
  • Page 58 Source IP Address Any value (wildcard) Individual IP Address (xxx.xxx.xxx.xxx) Range of consecutive IP Addresses (xxx.xxx.xxx.xxx-yyy.yyy.yyy.yyy) A Network of IP Addresses (and its associated subnet mask). (xxx.xxx.xxx.xxx/mmm.mmm.mmm.mmm) Destination IP Address Any value (wildcard) Individual IP Address (xxx.xxx.xxx.xxx) Range of consecutive IP Addresses (xxx.xxx.xxx.xxx-yyy.yyy.yyy.yyy) A Network of IP Addresses (and its associated subnet mask).

  • Page 59: Show Filter

    Example: Router> set filter default enter interface (Unspecified): isp enter default action (forward, forward/discard) : forward show filter Description: This command displays the entire configured rule set. Example: Router> show filter Interface Name : abc Default action is forward, and current exception rules are : Filter 1: Filter Name: Rule1...

  • Page 60: Delete Ip Default Route

    ⊕ ⊕ ⊕ ⊕ add pat entry <public port #> ⊕ ⊕ ⊕ ⊕ add pat entry default Description: Each IP packet received from the Internet interface is examined. If the destination address is the public address of the interface, the Network Address Translation Table is searched for a match. If the address is found, the destination address is replaced with the associated private address and port number.

  • Page 61: Delete Pat Entry Default

    delete pat entry <public port #> Description: This command deletes the specified port mapping from the Network Address Translation Table. delete pat entry default Description: This command deletes the default port mapping from the Network Address Translation Table. disable spoofing <Interface Name> <iprip> enable spoofing <Interface Name>...
  • Page 62 Example: Router> set ip lan 204.71.220.153 255.255.255.0 set ip private <ip_addr> <netMask> Description: This command is used to modify the “private” IP address on the router’s LAN interface. The IP network corresponding to the “set ip private” command becomes the private network. Private addresses are not legal for use on the Internet and therefore, devices in this network are no longer accessible from public devices on the Internet side.

  • Page 63: Show Arp Table

    set ip <Profile Name> set ip <Profile Name> < local-ipAddr> <netMask> <remote-ipAddr> Description: This command enables IP routing over the connection specified by Profile Name. Additionally, a WAN connection that supports IP routing, may, either be assigned zero or two IP addresses.

  • Page 64: Show Ip Routing Table

    Source Quench: Redirect: Echo Request: Echo Reply: Timestamp Request: Timestamp Reply: Address Mask Request: Address Mask Reply: Calls to icmp error: Messages Reflected: show ip Description: This command displays all interfaces on which IP routing has been enabled. Example: Router> show ip Admin.

  • Page 65: Static Route

    is directly attached to the router (i.e., the destination is on the same LAN the router is connected to), or the destination is reachable through an unnumbered serial interface. The meanings of the flags are: Host Static Route Gateway Cloned Entry Example: Router>...

  • Page 66: Show Pat

    Fragments Dropped after Timeout Fragments Dropped (Duplicates/No Space show pat Description: This command displays the static configuration entries in the Network Address Translation Table. Example: Router> show pat Public Port Private IP Private Port Number Address Number -------------------------------------------------------- Default 192.168.168.121 192.168.168.120 192.168.168.120 Router>...

  • Page 67: Show Port

    clear port statistics [port name] Description: This command clears port statistics. If a port is not specified, the statistics counters on all ports are cleared. disable port <port name> enable port <port name> Description: These two commands is used to disable or enable a port. ⊕...
  • Page 68 Router> show port Port Name : isdn Port Type : ISDN Admin Status: Enabled Op State: Down Directory#1: 5551111 Directory#2: 5552222 Sub-addr Req: No Switch Type: Europe (ETSI) Advice of Charge Unit price: Unspecified Currency: Unspecified Port Name : ewan Port Type : EWAN Admin State : Enabled...
  • Page 69 Total Error: B1-Channel Total Octets: 2316 Total Packets: Total Error: B2-Channel Total Octets: Total Packets: Total Error: Example 2: Router> show port statistics ewan interface: e1 ---------------------------------------------------------------- Received Transmitted ---------------------------------------------------------------- Total packets Total octets 217120 Multicast packets Error on interface CSMA collisions Packets dropped Packets with unsupported protocol 0...
  • Page 70 Existing profiles are edited also using the “add profile” command. In this case, the defaults shown are the existing configured values. This router only support one profile over EWAN interface. When an ewan profile is configured, the following new added profile(s) will select ISDN automatically. User can modify the ewan profile by using “add profile”...
  • Page 71 enter remote network IP address (Unspecified): 192.168.167.0 enter remote network IP netmask (Unspecified): 255.255.255.0 Router> Example 3 – Internet Access through EWAN port: Router> add profile wilson The system is currently in Advanced Mode, press Ctrl-E to switch to Express Mode. Add new connection profile “wilson”...

  • Page 72: Show Profile

    show profile This command displays a summary of all configured static profiles. Example: Router> show profile Profile Admin Remote Call Name Type State Number Originator ---------------------------------------------------------------- wilson EWAN Enabled daniel ISDN Enabled 5553333 Local only julia ISDN Enabled 5556666 Local only show profile <Profile Name>...
  • Page 73 wilson Down 0 show profile statistics <Profile Name> Example: Router> show profile statistics wilson wilson Received Transmitted --------------------------------------------------------------- Total octets: Total packets: Total errors: Security Command set ip private <ip_addr> <netMask> Description: This command is used to modify the “private” IP address on the router’s LAN interface. Please refer to IP command category for details.

  • Page 74: Show Snmp Statistics

    set trap manager <1-5> <ipAddr> Description: This command sets the IP address of the nth trap manager (n=1-5). Example: Router> set trap manager 1 203.23.12.71 show snmp statistics Example: Router> show snmp statistics Received Transmitted ------------------------------------------------------------------- Total Packets Request Variables SET Variables GET Requests GETNEXT Requests...
  • Page 75 clear port statistics [port name] Description: Refer to this command under Port Commands. clear profile statistics [Profile Name] Description: Refer to this command under Profile Commands. show compression statistics <Profile Name> Description: Refer to this command under Compression Commands. show icmp statistics Description: Refer to this command under IP Commands.

  • Page 76: Clear Config

    Interface or the HTTP. A password is a character string that starts with a letter and contains at least 6 and up to a total of 15 alphanumeric characters. The password is case sensitive. The default factory setting is “password”. If you forget the password, the only way to recover is clear the entire configuration and return the unit to its original state as shipped from the factory.

  • Page 77: Download Firmware

    Router> download config router.cfg from 205.51.23.12 download firmware Description: This command causes the product firmware to be downloaded to the system from a directly attached PC running the terminal emulation software (one with file download capability). Note that this command cannot be used from a telnet session. This is an alternative to downloading the software using the HTTP browser.
  • Page 78 If so, the entire configuration will be automatically saved to the flash memory. However, this command can also be used to execute the save operation immediately after some configuration changes, e.g., when the user intends to power down the system. set console baud <baudrate>...
  • Page 79 Router> set internet access time enter Day-of-the-week (all, (a)ll/(d)ay-range): d enter dd1-dd2 (Unspecified): mon-sat enter Time-of-day (all, (a)ll/(t)ime-range): t enter hh1:mm1-hh2:mm2 (Unspecified): 07:00-18:00 If the system loses its time setting, allow Internet Access ? (Yes, Yes/No): set log level <1-10> Description: This command changes the system log level, causing different events to be logged into the system log table.

  • Page 80: Show Config

    set time <hh:mm:ss> Description: This command sets the time of the day (24-hour clock). Note that the time will normally be set automatically when an HTTP browser first connects to the router. Example: Router> set time 20:33:00 set timezone <-12 - +12> Description: This command specifies the time zone for the location as an offset from Greenwich Mean Time (GMT).

  • Page 81: Show Internet Access Time

    Router> show interface list Oper. Comp. IfName Type State MTU Status Status Status ------------------------------------------------------------------- LOOPBACK 1536 Enable Disable ETHERNET 1500 Enable Enable n/a show internet access time Description: The current setting of the Internet time restriction is displayed. See set internet access time for details. Example: Router>...

  • Page 82: Show Telnet Session

    debugging purposes. This command shows the next 22 entries of the system log. For example, if there are 60 entries in the log, the first “show system log” command will show log entries 1 through 23, the next command will show entries 24 through 46, and the next command will show entries 47 through 60, followed by 1 through 9.
