Electrical Parts List - Marantz SA1/F1N Service Manual

POS. VERS. PART NO.
NO COLOR (FOR PCS)
301 9965 000 06889 SACD MECHAMISM ASSY
303 9965 000 06890 HOLDER, STEEL MECHANISM 392K271200
309 9965 000 06891 SHOCK ABSORBER
312 9965 000 06892 SHOCK ABSORBER
315 9965 000 06893 TRAY, STEEL TRAY
319 9965 000 06894 DISC, STEEL STABILIZER
320 9965 000 06895 HOLDER, STEEL SHAFT A
321 9965 000 06896 HOLDER, STEEL SHAFT B
323 9965 000 06897 PLATE, STEEL YOKE
324 9965 000 06898 LEVER, STEEL LIFT
325 9965 000 06899 SPRING HOLD
326 9965 000 06900 BELT, DRIVING TIMING
327 9965 000 06901 PULLEY, STEEL
328 9965 000 06902 TOOTHED WHEEL GEAR
329 9965 000 06903 TOOTHED
340 9965 000 06904 GEAR TRAY RACK GEAR
345 9965 000 06905 MAGNET
346 9965 000 06906 DISC, PLASTIC
709 9965 000 06907 SCREW, STEEL
M703 9965 000 06908 LOADING MOTOR ASSY
PWB- 9965 000 06909 PR.CIRCUIT, COMPACT DISC
D1-D3
PART NO.
DESCRIPTION
*ZZ001620R
MOTOR DC <=37.5W
392K130200
FLOAT RUBBER
392K130210
FLOAT RUBBER
392K163200
392K104200
392K106200
392K106210
392K104210
392K354200
392K116200
392K264200
392K262200
392K058200
392K058210
WHEEL TRAY GEAR
392K058220
392K305200
392K107200
HIMELON SHEET
392K010200
*ZZ001630R
MOTOR DC <=37.5W
*ZZ001650R
TRAY SENSOR/SWITCH/
PICKUP IN S

2.7 ELECTRICAL PARTS LIST

POS. VERS.
NO COLOR
(MJI)
CNP 9965 000 06886 CONNECTOR, PLUG 4P
501
CNS 9965 000 06887 CONNECTOR, SOCKET 30P
501
CNS 9965 000 06888 CONNECTOR, SOCKET 11P
502
D0501 9965 000 06882 DIODE, RB521S30
D0502 9965 000 06882 DIODE, RB521S30
D0503 9965 000 06882 DIODE, RB521S30
D0504 9965 000 06882 DIODE, RB521S30
D0505 9965 000 06882 DIODE, DAP202U
D0801 9965 000 06882 DIODE, DAN202K
D0802 9965 000 06882 DIODE, DAP202U
DZ501 9340 548 52115 DIODE, PDZ5.1B REFERENCE *HZ300050R
FL801 9965 000 06884 FILTER, CERAMIC 20MHz
IC501 9965 000 06864 IC TA1244FN I/V CONVERTER *HC106400R
IC502 9965 000 06865 PROCESSOR IX1517GE
IC503 9965 000 06866 IC IX2842AF
IC504 9965 000 06867 IC NJM234V
IC506 9965 000 06868 IC BA6796FP
IC507 9965 000 06869 IC NJM2904M ANA SWITCH
IC601 9965 000 06870 IC AD8052AR ANA AMPLIFIER *HC106480R
IC602 9965 000 06871 PROCESSOR IX1474GE
IC603 9965 000 06872 IC SC514870SJ 4M DRAM
IC606 9965 000 06873 IC IX1473GE
IC801 9965 000 06874 IC IX1478GE
IC802 9965 000 06875 IC IX1535GE
IC803 4822 209 13204 IC PST9129N RESET
IC804 9965 000 06876 IC IX2839AF 1M SRAM
IC805 9965 000 06877 IC IX1539GE FLASH ROM
IC901 9965 000 06878 PROCESSOR CXD2751Q
IC902 9965 000 06879 IC ADC08351
IC903 9965 000 06880 IC IX2840AF
PH051 9965 000 06883 COUPLER, OPTO/PHOTO
PH052 9965 000 06883 COUPLER, OPTO/PHOTO
PH053 9965 000 06883 COUPLER, OPTO/PHOTO
Q0501 4822 130 60729 DIG.TRS, <1W DTC124EK
Q0502 4822 130 60729 DIG.TRS, <1W DTC124EK
Q0503 4822 130 60729 DIG.TRS, <1W DTC124EK
Q0504 9965 000 06881 DIG.TRS, <1W 2SA1955A
Q0505 9965 000 06881 DIG.TRS, <1W 2SA1955A
Q0601 4822 130 60729 DIG.TRS, <1W DTC124EK
Q0602 4822 130 60326 DIG.TRS, <1W DTA144EK
Q0801 4822 130 60729 DIG.TRS, <1W DTC124EK
X0601 9965 000 06885 CRYSTAL 54000MHz
2-37
PART NO.
DESCRIPTION
(FOR PCS)
POWER RECTIFIER
POWER RECTIFIER
POWER RECTIFIER
POWER RECTIFIER
POWER RECTIFIER
POWER RECTIFIER
POWER RECTIFIER
RF SIGNAL
STEPPING MOTOR DRIVER
SPINDLE MOTOR DRIVER
LOADING/FOCUS/TRACKING/
SPIN/SLED DRIVER
SACD DATA
DIGITAL SERVO
SYSTEM MICROCOMPUTER
INPUT/OUTPUT EXPANDER
SACD PLAYBACK SIGNAL
A/D CONVERTER
SDRAM
RP1222
RP1222
RP1222
PART NO.
(MJI)
*YP200040R
*YJ002240R
*YJ002250R
*HZ200150R
*HZ200150R
*HZ200150R
*HZ200150R
HZ20001210
HZ20002210
HZ20001210
*FQ000510R
*HC106410R
*HC106430R
*HC106440R
*HC106450R
*HC106470R
*HC106490R
*HC106500R
*HC106510R
*HC106520R
*HC106530R
*HC106540R
*HC106550R
*HC106560R
*HC106570R
*HC106580R
*HC106590R
*HC200100R
*HC200100R
*HC200100R
*BA001040R
*BA001040R
*BA001040R
*HX100080R
*HX100080R
*BA001040R
*BA001050R
*BA001040R
*JX000710R
