Marantz SA-1 User Manual

Marantz SA-1 User Manual

Super audio cd player
Hide thumbs Also See for SA-1:
Table of Contents

Advertisement

Quick Links

See also: Service Manual
MODEL SA-1 TECHNICAL SPECIFICATIONS
Audio Characteristics
Channels
Frequency range
Frequency characteristics
Dynamic range
THD (1kHz)
wow & flutter
Analog output
output level (unbalanced)
output level (balanced)
Digital output
output level (cinch JACK)
output level (optical)
Optical Readout System
Laser
Wave length
Sampling frequency
Power Supply
U version ...................................................................................................................... AC 120V 60Hz
Power Consumption ....................................................................................................................... 33W
Cabinet, etc.
Dimensions (Width × Height × Depth) .................................................................. 458 × 133 × 365mm
Net weight .................................................................................................................................. 17.7kg
Operating temperatures ................................................................................................ +5ºC ~ +35ºC
Operating humidity ........................................................................................... 5 ~ 90% (without dew)
Accessories
• Remote control unit ......................................................................................................................... 1
Dimensions (Width × Height × Depth) ............................................................... 44 × 17.5 × 239mm
Net weight (without Batteries) ................................................................................................... 175g
• AAA (R03) Batteries ........................................................................................................................ 2
• Stereo audio cable with cinch pins ................................................................................................ 1
• AC Power Cord ............................................................................................................................... 1
• User's Guide ................................................................................................................................... 1
Specifications subject to change without prior notice.
Super Audio CD
2channels
2Hz — 100kHz
2Hz — 50kHz (-3dB)
109dB
0.0012%
Precision of quartz
2.2V
4.4V
—
—
AlGaAs
650nm
2.8224MHz
27
CD
2channels
2Hz — 20kHz
2Hz — 20kHz
98dB
0.0015%
Precision of quartz
2.4V
4.8V
0.5Vp-p (75Ω)
-19dBm
AlGaAs
780nm
44.1kHz

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SA-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Marantz SA-1

Summary of Contents for Marantz SA-1

  • Page 1 MODEL SA-1 TECHNICAL SPECIFICATIONS Audio Characteristics Channels Frequency range Frequency characteristics Dynamic range THD (1kHz) wow & flutter Analog output output level (unbalanced) output level (balanced) Digital output output level (cinch JACK) output level (optical) Optical Readout System Laser Wave length...

  • Page 2: Front View

    POWER REAR VIEW CONNECTION COLD(-) HOT(+) GROUND DIGITAL OUTPUTS OPTICAL COAXIAL REP 1 TRACK PLAY PROGRAM TOTAL SACD SUPER AUDIO CD PLAYER SA-1 UNBALANCED CONNECTION COLD(-) BALANCED HOT(+) ANALOG OUTPUTS GROUND FILTER STANDARD CUSTO M PLAY STOP PAUSE SACD/CD DISPLAY...

  • Page 3: Product Features

    INTRODUCTION Thank you for selecting the Marantz SA-1 Super Audio CD Player for your A / V system. This Compact Disc Player incorporates a number of features designed to enhance the listening of your favorite audio sources. Please read these operating instructions carefully. We recommend that you read the entire user guide before you attempt to connect or operate the player.

  • Page 4: About Super Audio

    The glossy side shining like a rainbow is the front side of the disc, and the side on which the label is printed is the back. Unlike conventional turntables for playing analog discs, the SA-1 Super Audio CD Player reads the information recorded on the disc from underneath without contacting it using a beam of laser light.
  • Page 5 CONNECTIONS NOTE For protection of the components and the speak- ers, be sure to turn off the power before making connections. Unbalanced connectioncords Rear Panel Optical fiber cable (commercially available) Pre-main amplifier, etc. (included) UNBALANCED CONNECTION COLD(-) HOT(+) BALANCED GROUND ANALOG OUTPUTS DIGITAL OUTPUTS OPTICAL...

  • Page 6: Controls, Connections And Indicators

    CONTROLS, CONNECTIONS AND INDICATORS Please read the following instructions referring to the illustration on page Some of the operations described in this user’s guide can only be operated from the remote control unit. In the description of controls, the names of the buttons which are available on both the main unit and the remote control unit are enclosed in , and the names of the buttons which are available only on the remote control unit are enclosed in...

  • Page 7: Using The Remote Control Unit

    Remove the battery cover. Remote control unit (RC-1SA) Rear side Insert the batteries with correct +/– orientation. Two AAA-size (R03) batteries Close the battery cover until it clicks shut. SA-1...
  • Page 8 REMOTE CONTROL UNIT RC-1SA When the power to the SACD player is ON and a disc is loaded on the disc tray, the remote control unit (RC-1SA) can be used to operate the player’s various functions. SACD/CD DISPLAY TIME PROG PLAY MODE CANCEL 10/0...
  • Page 9 TRACK PLAY PROGRAM TOTAL OPEN/CLOSE SACD SUPER AUDIO CD PLAYER SA-1 To stop playback: Press the STOP button. To remove the disc: Open the disc tray by pressing the disc, then close the tray by lightly pressing its front edge. Always keep the disc tray closed even when the CD player is not being used.

  • Page 10: Repeat Play

    SEARCHING/SKIPPING Direct search (specifying a desired track num- ber) Specify the track number using numeric buttons ( 1 - 9 , 10/0 , >10 ). ¡With tracks 1 to 10, specify directly which track is to be played, and immediately the track is searched and its play is commenced. →...

  • Page 11: Program Play

    Then press the CANCEL button to delete the tracks in sequence starting with the one programmed last. Q&A • How many tracks is it possible to program? Up to 20 tracks can be included in the program. With delete programming, up to 20 tracks can be omitted from the program.

  • Page 12: About Balanced Jacks

    2. European system (Pin 2 = HOT, Pin 3 = COLD) COLD The SA-1 uses the USA system of 1. When a preamp or main amplifier adopting the European system is connected using a cable with XLR balanced connectors, the repro- duced signal may be inverted of phase.

  • Page 13: Troubleshooting

    In the event of difficulty, consult your dealer or write directly to the nearest location to you that is listed on the Marantz Authorized Service Station list. Please quote the model and serial number of the equipment and give a full description of what you think is abnormal about the equipment’s...
