5.
Tear off Keypad Light Insulator, then remove four screws of Keypad Board and tear off
3M Tape then unscrew two screws of Speaker Holders to remove speaker.
Speaker Rubber Left
Speaker
Keypad Board
Speaker Holder
Tape 3M J350 17*60mm
Speaker Rubber Right
Keypad Light Insulator
19
