PVM OPeraTiOn
installing the sD Memory Card
Take care to insert the SD card with the correct orientation
– contacts should be visible when inserting the card with
the video display screen facing you.
CauTiOn: Do not remove the SD memory card
during capture operations, data will be lost and the memory
card may be damaged.
Operating Modes
There are three operating modes:
normal Mode
Displays current camera input and date/time. From this mode still pictures and
video are captured.
image review Mode
Displays captured still pictures and video.
Menu Mode
File maintenance, system settings, etc.
The unit powers up in Normal Mode.
From Normal Mode
Enter Image Review Mode by pressing
Enter Menu Mode by pressing OK.
Return to Normal Mode from any other mode by pressing ESC.
14 Phone: 800.536.0790 fax 585.235.6645 gradientlens.com info@gradientlens.com
Luxxor Portable Video Camera User Guide
®
or
Luxxor Portable Video Camera User Guide
®
normal Mode:
Capture a still Photo
In Normal Mode, press the large black
the captured image will remain displayed until the button is released.
Still photo files are saved as .JPG.
Capture a Video Clip
In Normal Mode, press the gray button to start recording. The elapsed
time display will be visible in the lower left of the image to indicate that you
are recording. Press the button again to stop recording and save the clip.
Pressing the button will also stop the recording and save the clip. Video
files are saved as .ASF.
Memory & Battery Charge indicators
In Normal Mode, press ESC to display the memory and battery indicators.
Memory capacity remaining is displayed as a percentage. Low battery power
is indicated by the battery status indicator depicting a less than full charge and
turning yellow.
Phone: 800.536.0790 fax 585.235.6645 gradientlens.com info@gradientlens.com
PVM OPeraTiOn
button. If you hold the button down,
Battery status
Memory remaining
