User Manual
User Guide
PORTABLE CAMERA
LUXXOR
PORTABLE
®
vidEO CAMERA
207 Tremont Street, Rochester, New York 14608
800.536.0790
Fax: 585.235.6645
REV. 412
Phone: 800.536.0790 fax 585.235.6645 gradientlens.com info@gradientlens.com
Advertisement
Related Manuals for Gradient Lens Luxxor
Summary of Contents for Gradient Lens Luxxor
-
Page 1: User Guide
User Guide PORTABLE CAMERA LUXXOR PORTABLE ® vidEO CAMERA 207 Tremont Street, Rochester, New York 14608 800.536.0790 Fax: 585.235.6645 REV. 412 Phone: 800.536.0790 fax 585.235.6645 gradientlens.com info@gradientlens.com... - Page 2 ® ® PORTABLE CAMERA Luxxor Portable Video Camera ® The Luxxor Portable Video Camera (LPC) easily connects to anY Hawkeye rigid or Flexible Borescope! when ® connected, the LPC delivers sharp, bright video and warnings: still images. Borescope inspection images can then be viewed “live,”...
- Page 3 The larger the video screen, the poorer the image resolution will appear at a particular viewing distance. The composite video output connector may also be connected to a monitor with an S-Video Input or BNC Input with an appropriate adapter (sold separately). Attach the 6-pin connector to the Luxxor Portable ® VideoCamera.
- Page 4 Portable Video Camera User Guide Luxxor Portable Video Camera User Guide ® ® attach the Camera to Your Borescope Computer ready Option To attach the Luxxor Portable Camera to your Hawkeye Pro series borescope: ® ® warning: The included software drivers MusT be installed BeFOre the VC-usB2 is 1.
- Page 5 There may be a delay after you press the Install button, but before the The VC-USB2 image capture interface connects to the Y-cable of the Luxxor ® Windows Installer window opens. Wait for the InstallShield window to open.
- Page 6 Device in the left-hand column of the window that appears. Make sure that the Video Source box is set to Video Composite as shown below. If not already done, connect the 6-pin circular connector of the Y-cable to the Luxxor Portable Camera. ®...
- Page 7 Turn the PVM’s power on by pressing and holding the power button for 2-5 seconds. fully charged. The Gradient Lens logo will appear. Then the word CAMERA and the battery and note: There is no charging indicator memory status indicators will appear for a few seconds.
- Page 8 PVM OPeraTiOn PVM OPeraTiOn Luxxor Portable Video Camera User Guide Luxxor Portable Video Camera User Guide ® ® normal Mode: installing the sD Memory Card Capture a still Photo Take care to insert the SD card with the correct orientation –...
- Page 9 PVM OPeraTiOn PVM OPeraTiOn Luxxor Portable Video Camera User Guide Luxxor Portable Video Camera User Guide ® ® image review Mode: Menu Mode: View Captured Photos or Video Clips Delete all Push the button to enter Image Review Mode. You can scroll forward or Deletes all saved files, video and still photos.
- Page 10 PVM OPeraTiOn PVM OPeraTiOn Luxxor Portable Video Camera User Guide Luxxor Portable Video Camera User Guide ® ® Menu Mode: Menu Mode: Language auto Power Off If your unit is supplied with a language option this function will allow you to...
- Page 11 PVM OPeraTiOn TrOuBLesHOOTing / sPeCiFiCaTiOns Luxxor Portable Video Camera User Guide Luxxor Portable Video Camera User Guide ® ® Transferring image Files to a PC PVM Troubleshooting Tips The PVM can download saved images through its USB port. Plug in the Mini USB 1.1 nothing on LCD screen: Battery power too low.
- Page 12 Gradient Lens Corporation will either repair or replace components found to be defective or at variance from the manufacturer’s specifications within this time at no cost to the customer.
