- Page 1 H-CMDN6000 2 DIN DVD/CD/MP3 RECEIVER WITH BUILT-IN 6.5” TFT DISPLAY Instruction manual DVD/CD/MP3- 2 DIN 6.5” TFT-...
-
Page 2: Table Of Contents
Dear customer! Thank you for purchasing our product. For safety, it is strongly recommended to read this manual carefully before connecting, operating and/or adjusting the product and keep the manual for reference in the future. Table of contents Table of contents ...............................2 Important safeguards ............................4 Accessories................................5 Installation/connection............................6... - Page 3 GPS operations ..............................46 Handling and cleaning discs ..........................47 Troubleshooting guide .............................48 Specification..............................49...
-
Page 4: Important Safeguards
Important safeguards Using the device at temperature below -10º may cause the breakage of the device. Before using, please, heat up the passenger compartment to the recommended temperature! Read carefully through this manual to familiarize yourself with this high-quality car stereo system. Disconnect the vehicle's negative battery terminal while mounting and connecting the unit. -
Page 5: Accessories
Accessories... -
Page 6: Installation/Connection
Installation/connection Installation method 1: DIN Front-mount Installation method 2: Installation using the screw holes at the sides of the unit. Select a position where the screw holes of the mounting bracket supplied with the car and the screw holes of the main unit become aligned (are fitted), and tighten the screws (see at 2 places on each side). - Page 7 Detach the unit Detach the front panel before disassembling the unit. 1. Take out the Outer trim frame. 2. Insert the keys supplied to the unit at both sides of the unit until they click. Pulling the keys makes it possible to remove the unit from the dashboard.
-
Page 8: Electrical Connection
Electrical Connection 1. Output plug 2. Output socket 3. Tuner reception Note: The brown wire is connected with brake signal; for safety, the programs can be seen on the monitor after braking the car, but the menu and RCA outputs are free of it. If you do not want to use this function, connect it with the negative pole. -
Page 9: Unit Controls
Unit controls Front panel 1. SRC/PWR button During waiting mode, briefly press it to turn on the unit; during working status, briefly press it to select radio mode or playback mode, hold and press it to turn the unit on or off. 2. -
Page 10: Inner Panel
Briefly press it to activate the traffic alarm function; press and hold it to select the bands. 10. REL/NAV button Press it to slide down the front panel, then you can insert or eject a disc or a SD card. Press and hold it to activate GPS function. -
Page 11: Remote Control
Remote control AF/EQ button SOURCE button GOTO button BND/TITLE button AMS/MENU button LOC/SUB-T button ST/AUDIO button OSD button PTY/ANGLE button SLOW button 11. ZOOM button 12. PROG button 13. P/N button 14. VOL +/ VOL- buttons 15. MUTE button 16. TA/ LOUD button 17. -
Page 12: Changing The Battery
PAUSE button STOP button 24. RPT button 25. RDM button 26. SEL button Changing the battery 1. Press the catch and at the same time pull out the battery tray (pic. 1). 2. Insert the 1 lithium battery, type CR2025 (3V) battery with the stamped (+) Pic. -
Page 13: General Operations
General operations Reset the Unit Operating the unit for the first time or after replacing the car battery, you must reset the unit. Remove the front panel at first, and then press RESET button on the unit with a pointed object, (such as a ballpoint pen) to set the unit to initial state. - Page 14 Volume Control Press VOL+/VOL- button on the RC or on the unit to increase/decrease the sound level. Turning Loudness On/Off Briefly press TA/LOUD button on the RC to activate loud function. You can press this button to increase the low frequency, which can improve sensitivity for your ears. Keep pressing it again to quit this function. Eject a Disc Press EJECT button on the RC or on the unit to eject or insert a disc.
- Page 15 Insert an SD Card Press REL button after turning the unit on, then insert an SD card into SD slot when the TFT is slanted, and the contents of the card will be played. Clear After inputting something wrong, press CLEAR button to clear it. Mode Selector Repeatedly press SOURCE button on the RC or the SRC/PWR button on the unit to select radio mode, TV mode or playback mode.
-
Page 16: Main Menu
Main menu Note: This unit can be operated by touching the screen buttons. Thus you can select the menus and change the parameters. When the unit is on, the monitor will display main menu. Press and hold SETUP button on the RC or SEL/MENU on the head unit, or press MENU on the monitor to enter the menu. - Page 17 Press buttons to adjust the desired FAD level, press EXIT to exit this menu. Note: When adjusting the other options perform the same operation. Video Adjust In this menu you can adjust CONTRAST, COLOR, TINT, BRIGHT, PICTURE. Source Adjust You can adjust TV, CDC, GPS and AUX to ON or OFF, press the corresponding button to set.
- Page 18 System Adjust In this menu you can adjust CLOCK SYS (clock system), KEY BEEP, MONI FLEX (monitor flex), REVER POLA (reverse polarity), SUBWOOFER, AMS FULLUP, LOCAL AREA, LOCAL, GOTO FREQ, RT SCROLL, TA VOLUME, REGION, ADJ SCREEN, CLOCK ADJ. Note: Press arrow buttons at the right side of the screen to display the next or previous menu.
- Page 19 AMS Fullup In this menu you can set the modes of AMS. When the setup is ON, the presettable stations are full, new one’s are not allowed. When you select OFF, it will search continually. Local Area You can select EUROPE, USA, to search the stations quickly in your current area. You can select OIRT to receive stations quickly.
- Page 20 Adj Screen Press ADJ SCREEN to display the above menu, there are a square button at the top left corner and a tip: please press the button. Press the square button at place 1, then the button will move to place 2, press it at place 2, it will move to place 3, then place 4, press SAVE at last.
-
Page 21: Digital Tuner Operations
Digital tuner operations Mode selecting Press the SRC/PWR button on the unit or SOURCE button on the RC repeatedly to switch to RADIO mode. User interface (UI) of Radio mode When the unit is switched to Radio mode, the following user interface will be displayed on the display: 1. - Page 22 Band selection Press the BND/TITLE button on the RC or on the touch screen to switch to the bands in the following order: FM1 - FM2 - FM3 - AM1 - AM2 (for two bands); FM1 - FM2 - FM3 - MW - LW (for three bands). Manual/automatic tuning Manual tuning: Press buttons on the RC repeatedly to select a station upward or downward step by...
- Page 23 Scanning/Memorizing Stations Automatically During radio mode, you can press AMS/MENU button on the RC or AMS button on the monitor to scan each stored station for 5 seconds respectively which stored with number buttons (1 – 6). You can press the corresponding Number Buttons, AMS/MENU button on the RC or AMS button on the monitor when your desired station is on.
-
Page 24: Rds Setup
RDS Setup 1. AF. Press it to activate AF function. . Press it to activate TA function. / . Press it to select PTY code. 4. PTY. Press it to activate PTY function. 5. During PTY ON, press this button to search the playing track type. 6. - Page 25 Program Type Briefly press PTY/ANGLE button on the RC or PTY button on the monitor to activate PTY function. When PTY is on, PTY ON appears on the monitor, you can press UP/DOWN to select the program type, and then press PTY CODE to search the special program.
-
Page 26: Disc Operations
Disc operations Discs for playback This unit can play disc types: DVD/DVD±R/DVD±RW/CD/CD-R/CD-RW. Compatible with formats: DVD/SVCD/VCD/MP3/WMA/HDCD/CDDA/MPEG4 (DivX)/Picture- CD/JPEG. The following file types are supported: Audio files: MP3 (*.mp3) WMA (*.wma) Video files: MP4 (*.avi, DIVX3.11/4.0/5.0/6.0 and XVID) MPEG 2(*.vob) MPEG 1(*.dat) Picture file: JPEG (*.jpg) ISO 9660 or ISO 9660 +Joliet format - Max. -
Page 27: Dvd Operations
DVD operations Glossary PBC (Play Back Control) Play Back Control is a menu recorded on the disc with SVCD or VCD2.0 format. For the discs contained PBC, it can playback interactive software with the menu displayed on TV. And if the disc contains still images, it can playback high definition of still image. - Page 28 Playing a DVD Insert a DVD disc into the disc slot, the unit will automatically switch on, if a DVD disc is loaded, press ENTER button to start the playback. To eject a DVD press EJECT button on the unit, on the RC. Touch the screen at any place when DVD mode is on and the monitor will display the menu as follows: Along with buttons of the RC and the unit you can use touch buttons of this menu to perform some of the following operations.
- Page 29 Repeat Playing Press RPT button on the RC to perform replaying function as followings: System Switch During playback mode, Press P/N button on the RC to set the TV standard to PAL or NTSC or AUTO system. Slow motion playback Press button to slow forward or slow backward.
- Page 30 Changing the viewing angle (Multi-angle) With DVDs featuring multi-angle (scenes shot from multiple angles) recordings, you can press PTY/ANGLE button to switch among viewing angles during playback. Notes: mark on a DVD's package indicates that it supports multi-angle scenes. Number 3 in the mark indicates the number of angles from which scenes were shot. The function is invalid if ANGLE button is pressed during fast forward/reverse or pause.
- Page 31 DVD Setup menu Press SETUP button on the RC to enter the setup menu. Use the buttons to choose the setup page: General page, Dolby Digital setup, Preference page, Exit. Press the button to enter the setup page selected. buttons to select the option you want to adjust. Press button to enter the adjustment list.
- Page 32 If the Screen saver is set On and the unit is switched on without a disc playing for 3 minutes, a moving picture appears on the TFT. Dolby digital setup DUAL MONO Choose the mode of the audio output: Stereo: choose this setting, when 5.1-channel sound playing, two channels of signals will be output from the left and right soundtrack;...
- Page 33 Set the desired languages for all the settings. If a setting is supported by disc content, it will work. Otherwise the disc default value works. You also can press the ST/AUDIO button on the RC to select the audio language. Press the LOC/SUB-T button on the RC to select the subtitle language.
- Page 34 Exit Select the Exit page to exit the Setup menu.
-
Page 35: Vcd/Cd Operations
VCD/CD operations Along with buttons of the RC and the unit you can use touch buttons of this menu to perform some of the following operations. Playing a VCD/CD Insert a VCD/CD disc into the disc slot, the unit will automatically switch on, if a disc is loaded, press SOURCE button to start the playback. - Page 36 Number Buttons Press one of number buttons (0-9) to play a track you want. Stop Playback Press STOP button, then press ENTER or PAUSE button on the RC or on the monitor to resume playing. Pause the Playback Press PAUSE button on the RC or on the monitor to switch between play and pause. Fast rewind/forward Press buttons on RC or on the monitor,...
- Page 37 On Screen Display Briefly press OSD button and the display will show: Single elapsed => Single remain => Total elapsed => Total remain => OFF. Press and hold OSD button on the RC to display the current setup. Setting the Playback Time During CD playback, press GOTO button, there will be track : —...
- Page 38 Program Playing During VCD/CD mode, press PROG button, the monitor displays the program menu. Press number buttons to select the track number and then press cursor buttons to move the cursor to START, press ENTER button to start program playing; move the cursor to EXIT and press ENTER button to exit the program playing. Move the cursor to and press ENTER button to go to the last page;...
-
Page 39: Mp4 Disc Operations
MP4 Disc operations Playing tracks Insert an MP4 (AVI, MPEG4) disc into the disc slot, the unit will automatically switch on, if a disc is loaded, press SOURCE button to start the playback. Number buttons You can select any tracks directly using number buttons (0-9). The track you selected will be played automatically. - Page 40 On Screen Display Briefly press OSD button the display shows: Press and hold OSD button on the RC to display the current setup. Setting the Playback Time Press GOTO button, and the monitor will show: —-:-—,enter your desired time of the playback using number buttons.
-
Page 41: Mp3/Sd Operations
MP3/SD operations Along with buttons of the RC and the unit you can use touch buttons of this menu to perform some of the following operations. Playing an MP3/SD Insert an MP3 disc into the disc slot, the unit will automatically switch on, if an MP3 disc is loaded, press SOURCE to start the playback. - Page 42 Selecting the MP3/SD Track Press GOTO button and the monitor will show: ---. Then press Number Buttons to enter the Mp3 track number and press then ENTER button to play; secondly press GOTO button, and the monitor will shows: --:--, now enter the desired number to play the current track at this point.
-
Page 43: Mp3 Overview
MP3 overview MP3 is short for MPEG Audio Layer 3 and refers to an audio compression technology standard. This product allows playback of MP3 files on DVD-R/-RW, DVD+R/+RW, CD-ROM, CD-R/-RW discs. The unit can read MP3 files written in the format compliant with ISO 9660. However it does not support the MP3 data written by the method of packet write. -
Page 44: Aux/Tv Operations (Optional)
AUX/TV operations (optional) Press SRC button to switch to AUX mode. Along with buttons of the RC and the unit you can use touch buttons of this menu to perform some of the following operations. TV touch screen menu Press SRC button to switch to the TV mode. 1. - Page 45 You can adjust the following items: SOUND: M/N, B/G, D/K. BAND: V-l, V-H, UHF MODE: SECAM/NTSC/PAL 7. Mode selector 8. Preset stations. To show all of stations in item 1. 9. Frequency. To show the TV frequency. TV Station Selection Press number buttons or buttons on the RC to select the TV stations, press 1 to 9 number buttons to select the stations directly;...
-
Page 46: Gps Operations
GPS operations Press and hold the REL/NAV button on the unit to activate the GPS function. For details of operating the in-built GPS navigation system see the Navigation System User’s Manual (in Russian only) included in the accessories package. -
Page 47: Handling And Cleaning Discs
Handling and cleaning discs Dirty, scratched or warped discs may cause skip ping or noise. Handle the disc only by the edges. To keep clean do not touch its surface. Discs should be stored in their cases after use to avoid scratches. Do not expose discs to direct sunlight, high humidity, high temperature or dust. -
Page 48: Troubleshooting Guide
Troubleshooting guide Cause Solution Symptom The car ignition is not on. power supply is properly No power. connected to the car accessory switch the ignition key to “ACC”. The fuse is blown. Replace the fuse. Disc cannot be loaded. Presence of disc inside the player. Remove the disc in the player then put a new upward. -
Page 49: Specification
Specification DVD/CD/MP3 RECEIVER General Power supply: 12 V DC Maximum power output: 50 W x 4 channels Compatible disk types: DVD/DVD±R/DVD±RW/CD/CD-R/CD-RW Compatible formats: DVD/SVCD/VCD/MP3/WMA/HDCD/CDDA/MPEG4(DivX)/Picture-CD/JPEG Dimensions/weight: D x W x H: 172 x 178 x 100 mm / 3.5 kg ESP function: 40 sec. - Page 50 TEMP 25 ° Satellite Acquisition Sensitivity -149dBm Cold Start Time <60S (Open sky) Warm Start Time <35S (Open sky) Hot Start <10S (Open sky) 1st Positioning Time <100s (Open sky) Signal Format NMEA0183 format output signal Language of map Russian MAP Display 2D and 3D Display Voice...
- Page 51 ..............................51 ..........................53 ............................54 ..........................55 ........................57 ...........................58 .............................58 ..........................59 ) ....................60 ............................62 ............................63 ..............................66 ............................71 RDS ............................74 ............................76 DVD.............................77 VCD/CD ........................86 ........................91 ........................93 AUX/ )......................96 GPS.............................98...
- Page 52 ............................99 .....................101 ........................103...
- Page 53 -10º...
- Page 54 . 2. 5 - 4 20 – 5...
- Page 58 SRC/PWR SEL/MENU MUTE VOLUME+/ VOLUME- SEL. RESET. AF/EQ TA/BAND REL/NAV...
- Page 59 GPS. / / / / / / / ; ANGLE+/ANGLE- EJECT. REL.
- Page 60 AF/EQ SOURCE GOTO BND/TITLE AMS/MENU LOC/SUB-T ST/AUDIO PTY/ANGLE SLOW ZOOM PROG VOL +/ VOL- MUTE TA/LOUD EJECT 0-9 NUMBER CLEAR ENTER / / / / FAST REWIND/ FAST FORWARD / PREVIOUS/NEXT SETUP...
- Page 61 PAUSE STOP...
- Page 62 (CR 2025 3V), – 6...
- Page 63 RESET RESET SOURCE SRC/PWR : BALAN => FADE => BASS => TREBL => VOLUME. VOL+/VOL- AF/EQ. AF/EQ : POP –...
- Page 64 CLAS – ROCK – EQ OFF. – OFF. VOL+/VOL- (LOUD) TA/LOUD LOUD. EJECT ANGLE+/- MUTE MUTE.
- Page 65 CLEAR SOURCE SRC/PWR...
- Page 66 SETUP SEL/MENU MENU : AUDIO, VIDEO, SOURCE, SYSTEM, EXIT. AUDIO ( AUDIO VOLUME ), BALANCE ( ), FAD, BASS ( TREBLE (...
- Page 67 FAD, EXIT, VIDEO ( CONTRAST ( ), COLOR ( ), TINT ( BRIGHT ( PICTURE ( 3. SOURCE ( TV, CDC, GPS ON ( OFF (...
- Page 68 4. SYSTEM ( CLOCK SYS, KEY BEEP, MONI FLEX, REVER POLA, SUBWOOFER, AMS FULLUP, LOCAL AREA, LOCAL, GOTO FREQ, RT SCROLL, TA VOLUME, REGION, ADJ SCREEN CLOCK ADJ. CLOCK SYS ( CLOCK SYSTEM KEY BEEP ( ON ( OFF ( - ON, MONI FLEX - MANUAL (...
- Page 69 REVER POLA ( +12 V, BATTERY 0 V, GROUND SUBWOOFER ( OFF; - ON. AMS ( AMS) AMS. ON ( OFF ( LOCAL AREA ( EUROPE, USA OIRT LOCAL ( ON ( OFF ( GOTO FREQ ( ON ( GOTO...
- Page 70 RT Scroll ( : SLOW ( ), NORMAL ( FAST ( TA Volume ( : LOW ( ), NORMAL ( HIGH ( Region ( ON ( ADJ SCREEN ( ADJ SCREEN : please press the button (« »). SAVE. CLOCK ADJ ( CLOCK ADJ...
- Page 71 SRC/PWR SOURCE 4. SEEK+/SEEK-. 5. VOL+/VOL-. 6. BAND. 7. AMS. 8. MENU. 9. SRC.
- Page 72 10. 6 11. RDS. RDS SETUP. BND/TITLE : FM1 - FM2 - FM3 - AM1 - AM2 ( FM1 - FM2 - FM3 - MW - LW ( DX/LOC LOC/SUB-T LOC;...
- Page 73 MO/ST ST/AUDIO MONO. AMS/MENU (1 – 6). AMS/MENU AMS/MENU (1 – 6). DISP GOTO, FREQ.
-
Page 74: Rds
AF – – – PTY. PTY – PTY. RDS. PS – RDS. SEEK+/SEEK- - PREV – 10. EQ – 11. LOUD – LOUD. AF/EQ Traffic Alarm TA/LOUD Traffic alarm. AF, «TA»... - Page 75 «TA» ., DVD, AUX), RDS. PTY/ANGLE PTY. PTY, PTY ON; UP/DOWN PTY CODE PTY SEARCH. PTY OFF, TA/LOUD...
- Page 76 DVD/DVD±R/DVD±RW/CD/CD-R/CD-RW. DVD/SVCD/VCD/MP3/WMA/HDCD/CDDA/MPEG4(DivX)/Picture- CD/JPEG. : MP3 (*.mp3) WMA (*.wma) : MP4 (*.avi, DIVX3.11/4.0/5.0/6.0 and XVID) MPEG 2(*.vob) MPEG 1(*.dat) : JPEG (*.jpg) ISO 9660 ISO 9660 + Joliet - – 448. – 99. - 99 44,1 : 32 - 320 : *.ACC, *.DLF, *.M3U, *.PLS, MP3 PRO, DRM.
-
Page 77: Dvd
SVCD DVD- « ». DVD- SVCD, VCD... - Page 78 ENTER EJECT STOP. ENTER PAUSE...
- Page 79 (0-9) PAL, NTSC AUTO. ZOOM...
- Page 80 => => => => GOTO, ENTER GOTO. Multi-angle) multi-angle ( ANGLE multi-angle. ANGLE Multi-audio) AUDIO AUDIO 1 => AUDIO 2 => AUDIO 3.
- Page 81 multi-audio. Multi-subtitle) SUB-T : Subtitles 1 — Subtitles 2 — Subtitles OFF multi-subtitle. MENU AMS/MENU, ENTER BAND/TITLE, ENTER...
- Page 82 SETUP DOLBY, ENTER SETUP 4:3 PS: 4:3 LB: –...
- Page 83 SUBTITLE DOLBY 5,1- FULL OFF (...
- Page 84 PAL: NTSC: ST/AUDIO – LOC/SUB-T...
- Page 85 « », 8888), ENTER. « ». 8888 ( (8888) ENTER,...
-
Page 86: Vcd/Cd
VCD/CD VCD/CD SOURCE VCD/CD EJECT. - Page 87 (0-9) STOP. ENTER PAUSE PAUSE PAL, NTSC AUTO.
- Page 88 ZOOM => => => => DISP GOTO; « »: —-:—- . « »,...
- Page 89 ENTER GOTO. ST/AUDIO VCD, BND/TITLE, SEL/MENU, SEL/TITLE. PBC 2.0 VCD/CD PROG; ENTER ENTER. ENTER;...
- Page 90 ENTER. STOP PROG CD-R CD-RW, 44,1 ISO 9660, CD-R MP3 CD-R CD-RW CD-R CD-RW CD-R CD-RW 1. ID3TAG.
-
Page 91: Mp4
MP4 (AVI, MPEG4) SOURCE (0-9). MP4 (AVI, MPEG4) STOP PAUSE. MP4 (AVI, MPEG4) PAUSE MP4 (AVI, MPEG4) - Page 92 – – GOTO; —-:—- . ENTER GOTO, -—:—-:—-, ENTER. ZOOM...
- Page 93 SOURCE STOP, EJECT. (0-9)
- Page 94 STOP, GOTO; —-:—- . ENTER GOTO, --:--. CLEAR PAUSE DISP...
- Page 95 MPEG 3 DVD-R/-RW, DVD+R/+RW, CD- ROM, CD-R/-RW. 9660. “.mp3”. “.mp3”, “ MP3” “ ”, PC “ ” “ ” 448. VBR, . VBR:...
-
Page 96: Aux/ ( )
AUX/ AUX. 1 – 10 10 – 30 -- , 2. CH-/CH+ . 3. VOL+/VOL- . 4. STEP. 5. ANT. 6. SETUP. - Page 97 SOUND ( ): M/N, B/G, D/K. BAND ( ): V-l, V-H, UHF MODE ( ): SECAM/NTSC/PAL GOTO, AMS/MENU...
-
Page 98: Gps
REL/NAV GPS. - Page 101 ». RESET.
- Page 103 DVD/CD/MP3 DVD/DVD±R/DVD±RW/CD/CD-R/CD-RW DVD/SVCD/VCD/MP3/WMA/HDCD/CDDA/MPEG4(DivX)/ Picture-CD/JPEG 172 178 100 /3,5 CD, 120 480 234 16:9 300:1 PAL/NTSC/AUTO – 74 /87,5 – 108 522 – 1620 SECAM/NTSC/PAL 48,25 – 863,25...
