The ICA-HM351 follows the ONVIF v1.01 and v1.02 standard SDK for users to integrate with the third party software. The ICA-HM351 can also work with PLANET Cam Viewer 3 Lite / Pro Management software and Network Video Recorder products for video surveillance application and provides monitoring, recording and event management functions to secure your property and life.
1.3 Package Contents User can find the following items in the package: ICA-HM351 x 1 Power Adapter x 2 Wall Mounting Kit x 1 User’s Manual CD x 1 Quick Installation Guide x 1 NOTE: 1. If any of the above items are missing, please contact your dealer immediately.
2. Basic Setup This chapter provides details of installing and configuring the internet camera 2.1 System Requirements Intel Dual Core 2.0GHz or higher (above Recommended) (above Recommended ) 128MB Video RAM or above 1024 x 768 24bits Display Resolution Operating System Windows XP / Vista / Win7 DirectX 9.0c above...
2.2 Physical Description 2.2.1 Identification of ICA-HM351 cable Interface Description The input power is DC 12V, 1A. DC Power (Power Jack, IR and IP Note:ONLY use package power adapter supplied with the Camera) internet. Otherwise, the product may be damaged.
Page 10
Note:ONLY use one power source, either from DC or from 802.3af Power over Ethernet. Audio Output Connect a loud speaker to the IP Camera. This is for voice alerting and two-way audio. (Green, Line Out) Microphone Input Connect a microphone to the IP Camera. (Pink, Audio In) The Network Camera also provides composite video output.
2.3 Hardware Installation 2.3.1 Physical Installation 1. Fix IR camera to desired location with wall mount fixture 2. Plug-in Ethernet Cable into RJ-45 connector Connect an Ethernet cable to the LAN socket located on the Network Camera’s back panel and attach it to the network. If there has an IEEE 802.3af PoE switch in your network, you can connect the NOTE: camera LAN cable to this PoE switch to obtain power.
NOTE: “Run” and type “D:\Utility\IPWizard II\setup.exe”, assume D is your CD-ROM drive. 3. The “Welcome to the InstallShield Wizard for PLANET IPWizard II” prompt will display on the screen and click “Next” to continue. 4. Please click “Next” to install with original settings, or you may click “Change…” button to...
Page 13
5. Please click “Install” to start the installation. 6. Please click “Finish” to complete the installation and launch program immediately.
IPWizard II to discover Camera’s IP address and set up related parameter in a Camera. Search When launch the PLANET IPWizard II, a searching window will pop up. PLANET IPWizard II is starting to search Network Cameras on the LAN. The existed devices will be listed as below.
View If PLANET IPWizard II finds network devices, View button will be available. Please select the device you want to view and click the View button. Then you could see the video from camera directly. Furthermore you could double click the left button of mouse to link to the network device by browser.
After keying in new username and password, click “Submit” button to perform your setting accordingly. Click “<<” button will go back to previous page. Using UPnP of Windows XP, Vista or Win7 2.6.1 Windows XP UPnP™ is short for Universal Plug and Play, which is a networking architecture that provides compatibility among networking equipment, software, and peripherals.
Page 17
continue The “Add or Remove Programs” will display on the screen and click Add/Remove Widows Components to continue. The following screen will appear, select “Networking Services” and click “Details” to continue The “Networking Services” will display on the screen, select “Universal Plug and Play” and click...
Page 18
“OK” to continue. Please click “Next” to continue The program will start installing the UPnP automatically. You will see the below pop-up screen,...
Page 19
please wait while Setup configures the components. Please click “Finish” to complete the UPnP installation Double-click “My Network Places” on the desktop, the “My Network Places” will display on the screen and double-click the UPnP icon with Internet camera to view your device in an internet browser.
2.6.2 Windows Vista UPnP™ is short for Universal Plug and Play, which is a networking architecture that provides compatibility among networking equipment, software, and peripherals. This device is an UPnP enabled device. If the operating system, Windows Vista, of your PC is UPnP enabled, the device will be very easy to configure.
2.6.3 Windows 7 Go to Start > Control Panel > Network and Internet > Network and Sharing Center, if network discovery is off; click the arrow button to expand the section. Click Turn on network discovery, and then click Apply. If you are prompted for an administrator password or confirmation, type the password or provide confirmation.
Install the Device behind a NAT Router Once installed, the device is accessible on your LAN. To access the device from the Internet you must configure your broadband router to allow incoming data traffic to the device. If the device is installed on the LAN with a router, then it may get a dynamic IP address from the DHCP server.
Setup ActiveX to use the Internet Camera The Internet camera web pages communicate with the Internet camera using an ActiveX control. The ActiveX control must be downloaded from the Internet camera and installed on your PC. Your Internet Explorer security settings must allow for the web page to work correctly. To use the Internet camera, user must setup his IE browser as follows: 2.8.1 Internet Explorer 6 for Windows XP From your IE browse...
2.8.2 Internet Explorer 7 for Windows XP From your IE browse ”Tools” ”Internet Options…” ”Security” ”Custom Level…”, please setup your “Settings” as follow. Set the first 3 items • Allow previously unused ActiveX control to run… • Allows Script lets •...
Page 26
2.8.3 Internet Explorer 7 for Windows Vista and Win7 From your IE browse ”Tools” ”Internet Options…” ”Security” ”Internet” ”Custom Level…”, please setup your “Settings” as follow. • Enable “Automatic prompting for ActiveX controls” • Prompt “Initialize and script active controls not marked….” From your IE browse ”Tools”...
“ The login window of Internet camera will appear, Default login username/password is: admin/ <no password> If the User name and Password have been changed with PLANET IPWizard II, NOTE: please enter the new User name and Password here.
Page 28
Web browser may display the “Security Warming” window, select “Yes” to install and run the ActiveX control into your PC. After the ActiveX control was installed and run, the first image will be displayed. If you log in the camera as an ordinary user, setting function will be not available. If NOTE: you log in the camera as the administrator, you can perform all the settings provided within the device.
3.3 Live View Start-up screen will be as follow no matter an ordinary users or an administrator. Video Profile ActiveX Control Streaming Protocol Monitor Image Section Language Setting Menu Client Menu PTZ Control 2-Way Audio Full Screen Monitor Image Section The image shot by the camera is shown here.
Page 30
for user logged into camera as administrator. Item Action Configure Network settings such as Wireless, Network DHCP, DDNS, 3GPP, PPPoE and UPnP. Camera Adjust camera parameters. Configure system information, date & time, System maintenance, and view system log file. Configure bit rate and frame rate of video Video profiles.
Hide PTZ Control Camera Direction Camera Speed Preset Tour Go Tour Auto Pan Hide PTZ Control Click the icon will hide the PTZ control function. Camera Direction Control camera up/down/left/right and home position. Camera Speed Choose the speed of Pan and Tilt. Preset Add/Update the preset positions or go to one of these positions.
3.4 ActiveX Control The plug-in ActiveX control supports a lot of functions by clicking the left mouse button. Note that this feature only supports on the ActiveX control within Microsoft® Internet Explorer. On the ActiveX control icon, click the Left Mouse Button, then a menu pop-up. This menu provides features that are unique to the ActiveX control.
3.4.2 Record Click Record to activate this function. Press Record button to start recording. The video file is saved as ASF format into your local PC. While you want to stop it, press Stop to stop recording. Select Browser, the pop-up window to select the save path and file name prefix, select OK to continue.
3.4.4 Voice Click Volume to activate this function. These have two control bars for speaker and microphone volume. Scroll this control bar to adjust the audio attribute. Check the volume mute will mute the speaker output. 3.4.5 Statistics Click Statistics to activate this function. A window will be popup to show the statistics information of the streaming status.
3.5 System Setting Use this menu to configure the network to connect the device and the clients. This function is only available for user logged into Camera as administrator. Click on each menu name to display its setting page. Item Action Network Configure Network settings such as DHCP, DDNS, 3GPP, PPPoE and...
3.5.1 Network This section provides the menu of connecting the device through Ethernet cable. MAC address Display the Ethernet MAC address of the device. Note that user cannot change it. Obtain an IP address Enable this checked box when a DHCP server is installed on the automatically (DHCP) network to issue IP address assignment.
Page 38
demonstration 11111111 11111111 11111111 00000000 will usually be shown in the corresponding, more readable form as 255.255.255.0. Gateway A gateway is a piece of software or hardware that passes information between networks. You'll see this term most often when you either log in to an Internet site or when you're transient email between different servers.
3.5.2 HTTPS HTTPS: Stands for Hypertext Transfer Protocol Secure HTTPS is a combination of the Hypertext Transfer Protocol with the SSL/TLS protocol to provide encrypted communication and secure identification of a network web server . HTTPS connections are often used for sensitive transactions in corporate information systems. The main idea of HTTPS is to create a secure channel over an insecure network.
3.5.3 DDNS server DDNS: Stands for Dynamic Domain Name Server The device supports DDNS If your device is connected to xDSL directly, you might need this feature. However, if your device is behind a NAT router, you will not need to enable this feature. Because DDNS allows the device to use an easier way to remember naming format rather than an IP address.
DDNS To enable or disable the DDNS service here. Server name Choose the built-in DDNS server. DDNS Host The domain name is applied of this device. User Name The user name is used to log into DDNS. Password The password is used to log into DDNS. 3.5.4 PPPoE PPPoE: Stands for Point to Point Protocol over Ethernet A standard builds on Ethernet and Point-to-Point network protocol.
PPPoE To enable or disable the PPPoE service here. User Name Type the user name for the PPPoE service which is provided by ISP. Password Type the password for the PPPoE service which is provided by ISP. IP Address / Subnet Shows the IP information got from PPPoE server site.
Page 43
RTSP Port Choose the RTSP port. The RTSP protocol allows a connecting client to start a video stream. Enter the RTSP port number to use. The default value is 554. RTP Port Specify the range of transmission port number of video stream. The default range is 50000 to 50999.
3.5.6 UPnP UPnP is short for Universal Plug and Play, which is a networking architecture that provides compatibility among networking equipment, software, and peripherals. This device is an UPnP enabled Network Camera. If your operating system is UPnP enabled, the device will automatically be detected and a new icon will be added to “My Network Places.”...
3.5.7 Bonjour Bonjour, also known as zero-configuration networking, enables automatic discovery of computers, devices, and services on IP networks. Bonjour uses industry standard IP protocols to allow devices to automatically discover each other without the need to enter IP addresses or configure DNS servers.
3.5.8 Onvif ONVIF is a global and open industry forum with the goal to facilitate the development and use of a global open standard for the interface of physical IP-based security products. Or in other words, to create a standard for how IP products within video surveillance and other physical security areas can communicate with each other.
3.5.9 IP Filter You can enter different user’s IP address which are allowing enter or denying by the device. IP Filter To enable or disable the IP filter function here. IP Filter Policy Choose the filter policy where is denying or allowing.
3.5.10 IP Notification In case the IP address is changed, system is able to send out an email to alert someone if the function is enabled. If enable this function, then the “Send to“ and “Subject” field SMTP Notification (e-mail) need to be filled.
Page 49
HTTP Login name Type the user name for the HTTP server. HTTP Login Password Type the password for the HTTP server. Proxy Address Type the server name or the IP address of the HTTP Proxy. Proxy Port Set port number of Proxy. Proxy Login name Type the user name for the HTTP Proxy.
3.6 Camera Configuration Use this menu to set the function of the camera of Internet camera 3.6.1 Picture Rotation Turn the “Mirror” and “Vertical Flip” On or OFF. The image will be overturned as below. White Balance: Auto: will adjust the white balance automatically. Hold: will hold the white balance.
Page 51
Power Frequency Frequency of power line: 50 or 60Hz Color Level Large value will be colorful. Change the value will result to color tuning. Brightness Large value will brighten camera. Contrast Large value will contrast camera heavily. Sharpness Large value will sharpen camera. IR LEDs (Night Vision) User can turn Auto/Off/On/Schedule of the night mode.
3.6.2 Privacy Mask Use this page to specify privacy mask window 1 to window 8 and set the name and gray level for selected window. Add and Delete To add or delete the privacy mask windows, user can specify up to 7 windows to mask the video captured by this device.
3.6.3 PTZ Setting This page allow user to modify the RS-485 interface according to the P/T scanner. Camera Protocol This device can connect to a PTZ camera or speed dome camera and controls them thru RS-485 interface. Camera Address This is the camera ID set in PTZ camera or speed dome camera. Note that please DO NOT changes the default value if unnecessary.
3.6.4 Preset Setting This page provides the edit tool to modify or delete the “Preset Setting” item by item. 3.6.5 Tour Setting Up to 64 positions can be preset, and the camera can be programming to move to the preset position sequentially.
Page 55
Tour Name The group name of the sequence of camera tour. The maximum number of camera tour is 16. Running Enable or disable this camera tour. Preset Set the sequence of the tour. Maximum 16 points can be assigned. The selected preset position is added in the Sequence list from 1 to 16.
3.7 System Use this menu to perform the principal settings of Internet camera. 3.7.1 System Device title You can enter the name of this unit here. It’s very useful to identify the specific device from multiple units. Software version This information shows the software version in the device. Network LED Switch the LED light of this Internet camera on or off, that Network LEDs will stop working, in case you don’t want other people know the...
3.7.2 Date & Time You can setup the time setting of Internet camera, make it synchronized with PC or remote NTP server. Also, you may select the correct time zone of your country. Server Date Displays the date and time of the device &...
Daylight saving Check this item to enable daylight saving adjustment. Daylight Saving Sets up the date and time of daylight saving start time. Start Time Daylight Saving Sets up the date and time of daylight saving stop time. Stop Time Daylight Saving Sets up the date of daylight saving offset.
Page 59
8. A message will be shown while the firmware upgraded. Once the upgrading process completed, the device will reboot the system automatically. 9. Please wait for 80 seconds, and then you can use PLANET IPWizard II to search the device again. Warning!!! The download firmware procedure cannot be interrupted.
3.8 Video This device provides 2 modes of video profile. The first one is Mega-pixel mode which supports video resolution up to Mega-pixel. However the maximum frame rate of this mode is up to 15fps only. The second one is VGA mode which supports video resolution up to VGA but frame rate can be up to 30fps.
3.8.2 Video Profile It’s H.264 encoder mode in this profile. Name To assign a name to the selected profile. Video Type Video codec of the selected profile. Resolution Resolution of the selected profile. Assign the selected profile as a ROI stream or not. (Only available for the profiles with max resolution) Rate Control Defines the rate control method of this profile.
For ECBR, the video bitrates is based on normal CBR mode. However, the target bitrates can be increased to max target bitrate while lots of motion in video. The max target bitrates will keep a pre-defined time period and then back to normal CBR bitrates. For EVBR, the video bitrates is based on normal VBR mode.
3.9 Audio Configuration It’s M-JPEG mode in this profile. Audio To enable or disable audio function Mute While PT Mute the audio while pan and/or tilt motion Audio Mode To select Simplex or Full duplex (2-way audio) mode. Input Gain To adjust gain of input audio Output Gain To adjust gain of output audio...
3.10 User Privilege Access Configuration Use this menu to set the user names and password of the Administrator and up to 10 users, and access right of each user. Viewer login Select “Anonymous” to allow any one viewing the video once connected.
3.11 E-Mail Configuration You may setup SMTP mail parameters for further operation of Event Schedule. That’s, if users want to send the alarm message out, it will need to configure parameters here and also add at least one event schedule to enable event triggering. SMTP Server Type the SMTP server name or the IP address of the SMTP server.
e-mails. E-mail To Type the receiver’s e-mail address. E-mail Subject Type the subject/title of the e-mail. 3.12 Object Detection Use this menu to specify motion detection window 1 to window 4 and set the conditions for detection while observing a captured image. Add and Del To add or delete the motion windows.
Object Size Defines the object size of motion detection. The higher object size will only larger objects trigger motion detection. The lower object size will even small objects trigger motion detection too. Generally speaking, the smaller size will be easier to trigger event. Sensitivity Defines the sensitivity value of motion detection.
FTP Login Password Type the password for the FTP server. FTP Port Set port number of FTP service. FTP Path Set working directory path of FTP server. FTP Passive Mode Select passive or active mode connecting to FTP server. 3.13.2 TCP Server In addition to send video file to FTP server, the device also can send event message to specified TCP server.
3.13.3 HTTP Server The device also can send event message to specified HTTP server. Name User can specify multiple HTTP servers as wish. Therefore, user needs to specify a name for each HTTP server setting. Type the server name or the IP address of the HTTP server. Test Check the HTTP server whether it is available or not.
3.13.4 SAMBA Server The device also can send video stream to specified SAMBA server. Most of the time, the SAMBA server will be another PC or NAS server. Name User can specify multiple HTTP servers as wish. Therefore, user needs to specify a name for each HTTP server setting. SAMBA Server Type the server name or the IP address of the SAMBA server.
3.14 Event Schedule Configuration This menu is used to specify the schedule of Events and activate the some actions provided by this device. Name Name of the Event or Schedule. Enable Enable or disable this Event or Schedule. Type Schedule start with Event trigger or Schedule trigger. Enable Time Define the feasible time slot.
Page 72
Example1. Send file to FTP server by motion triggered always: Select event trigger Enable time: start from 00:00 to 24:00 every day Trigger by: Motion Area (Added in Object Detection page) Action : Send FTP (Add in Event Server -> FTP Server page)
Page 73
Example2. Send file to E-Mail server by motion triggered from Friday 18:00 to Saturday 06:00 Select event trigger. Enable time: start from Friday 18:00 and keep work in 12 hours, so it will stop on Saturday 06:00. Trigger by : Motion Area (Added in Object Detection page) Action : Send e-mail (Add in E-Mail page) To email address: You need to input the receiver email address.
Page 74
Example3. Send file to E-Mail server by motion triggered from Friday 18:00 to 24:00 from Monday to Friday. 1. Type: Select schedule trigger and interval is 10-minute. 2. Enable Time: Select Monday to Friday, and set start time from 18:00 and keep work in 6 hours.
3.15 Record Configuration User can choose the type of record file for event or schedule application. Record File Type Choose AVI or JPEG file format for record file. Record File Prefix Define the prefix of recorded filename. Pre-Trigger Duration Define the maximum duration of pre-alarm. Best Effort Duration Define the best effort duration of post-alarm.
Appendix A: Alarm I/O Connector Some features of the Camera can be activated by the external sensor that senses physical changes in the area Camera is monitoring. These changes can include intrusion detection or certain physical change in the monitored area. For examples, the external sensor can be a door switch or an infrared motion detector.
Page 77
CAUTION! The low voltage/current circuits and high voltage/current circuits are in the network camera circuit. The qualified electrician should do the wring not by yourself incorrect wiring could damage network camera. You could receive the fatal electric shock. The external I/O is not capable of connecting directly to devices that require large amounts of current.
Appendix B: PING IP Address The PING (stands for Packet Internet Groper) command is used to detect whether a specific IP address is accessible by sending a packet to the specific address and waiting for a reply. It’s also a very useful tool to confirm Internet camera installed or if the IP address conflicts with any other devices over the network.
Appendix C: 3GPP Access To use the 3GPP function, in addition to previous section, you might need more information or configuration to make this function work. That to use the 3GPP function, it strongly recommends to install the Networked Device Note with a public and fixed IP address without any firewall protection.
Appendix D: Bandwidth and Video Size Estimation The frame rate of video transmitted from the Internet camera depends on connection bandwidth between client and server, video resolution, codec type, and quality setting of server. Here is a guideline to help you roughly estimate the bandwidth requirements for your Internet camera. The required bandwidth depends on content of video source.
Appendix E: DDNS Application 1. Preface If you have a Cable modem or xDSL, this is a great way to host your own Networked Device or other TCP/IP Service. Get your own domain like www.yourname.com, www.yourname.com.tw etc. (Note: This domain must be registered with Internic via registration authorities such as Network Solutions, DirectNIC, Register.com etc).
Page 82
(3). After the columns show up at the left side, click “Create Account”. (4). Fill the application agreement and necessary information. a. Username b. E-mail address and confirmation c. Password and confirmation d. Submit all the input information and finish creating an account...
Page 83
Click these two options (5). Check your e-mail mailbox. There will be an e-mail with a title “Your DynDNS Account Information“. Click the hyperlink address to confirm the DDNS service that you just applied. Click to confirm Then DDNS you applied activated.
Page 84
(6). Enter the web page http://www.dyndns.org/ again. Input your username and password that you just applied to login administration interface of DDNS server. Input your account (7). If the correct username and password are input, you can see the following picture at the top-right of the login page.
Page 85
(9). Click the “ Dynamic DNS ”. (10). Click the “Create Hosts”. (11). We could create a domain name without any charge at this step. First, we input the host name. (No.1) Then we pick a domain that is easy to remember. Finally (No.2), click the “Add Host”...
Manually setup the device with a fixed IP address, for example, 192.168.0.100. 2. Access the Router with Your Web browser The following steps generally apply to any router that you have on your network. The PLANET WNRT-620 is used as an example to clarify the configuration process. Configure the initial settings of the router by following the steps outlined in the router’s Quick Installation Guide.
Page 87
Your WAN IP Address will be listed here. 3. Open/set Virtual Server Ports to enable remote image viewing The firewall security features built into the router and most routers prevent users from accessing the video from the device over the Internet. The router connects to the Internet over a series of numbered ports.
Page 88
Enter valid ports in the Virtual Server section of your router. Please make sure to check the box on this line to enable settings. Then the device can be access from WAN by the router’s WAN IP Address. By now, you have finished your entire PC configuration for this device.
Appendix G: Troubleshooting & Frequently Asked Questions Features The video and audio codec is The device utilizes H.264, MPEG-4 and M-JPEG triple compression adopted in the device. to providing high quality images. Where H.264 and MPEG-4 are standards for video compression and M-JPEG is a standard for image compression.
Page 90
2. Reconfigure the device. Forgot the IP address of the Check IP address of device by using the IPWizard program or by device. UPnP discovery or set the device to default by Reset button. IPWizard program cannot find the Re-power the device if cannot find the unit within 1 minutes. device.
Page 91
The IP address and Subnet Mask of the PC and Network Camera must be in the same class of the private IP address on the LAN. Make sure the http port used by the Network Camera, default=80, is forward to the Network Camera’s private IP address. The port number assigned in your Network Camera might not be available via Internet.
Page 92
to be accessible outside your LAN. Make sure that the device isn’t conflicting with any other web server running on your LAN. Check the configuration of the router settings allow the device to be accessed outside your local LAN. Check the bandwidth of Internet connection. If the Internet bandwidth is lower than target bit rate, the video streaming will not work correctly.
Page 93
50 or 60Hz format of your device. If the object is dark, the image will flicker. Make the condition around the Camera brighter. Miscellaneous Can not play the recorded ASF file Please installed Microsoft®’s DirectX 9.0 or later and uses the Windows Media Player 11.0 or later to play the AVI filed recorded by the Device.
IPv4, TCP, UDP, HTTP, HTTPS, SMTP, FTP, NTP, DNS, DDNS, DHCP, DIPS, Network Protocol ARP, Bonjour, UPnP, RTSP, RTP, RTCP, IGMP, PPPoE, 3GPP, Samba, ICMP Microsoft ® Internet Explorer 6.0 or later Browser / Software PLANET Cam Viewer 3 Lite/Pro Motion Detection 10 areas definable Environment Specifications Power Requirement 12V DC, 1A IEEE 802.3af...
Page 95
Illumination LED 88pcs IR LED, 35M IR Distance Heater Blower Heater & Fan ON: 15 Degree C ON: 37 Degree C OFF:25 Degree C OFF:25 Degree C Protection Class IP-66 classification with Weather proof Operating Temperature -30 ~ 60 Degree C Operating Humidity 0 ~ 95% (non-condensing) Emission...
