Page 2: Warning Before Install
Warning Before Install Power off the Network Camera Keep the Network Camera away as soon as it is found smoking or from water. If the Network Camera smelt unusual. is wet, power off immediately. Contact your distributor when such Contact your distributor when such cases happen. - Page 3 Do not touch the Network Camera Do not place the Network Camera on unsteady surfaces. when it's lightening. Do not disassemble the Network Do not drop the Network Camera. Camera. Do not insert any object into the Network Camera, such as needles. EN - 2...
-
Page 4: Package Contents
Package Contents IP7251 Power adapter Camera stand CS-mount lens Software CD Quick installation guide Warranty card L-type hex key wrench / C-mount ring (for C-mount lens) EN - 3... -
Page 5: Physical Description
Physical Description Front panel Light sensor Built-in MIC Status LED Back panel External/Internal MIC switch Audio out MIC in Ethernet 10/100 Power cord socket RJ45 socket General I/O Indented reset button terminal block Lens Focus controller Zoom controller EN - 4... -
Page 6: Mounting The Lens To The Camera
Mounting the Lens to the Camera 1. Mount the lens by turning it clockwise onto the camera mount until it stops. If necessary, turn the lens counterclockwise slowly until it gets the best attitude. 2. Connect the lens cable plug to the camera connector. For further setup, please refer to the lens' instruction manual inside the lens package. -
Page 7: Power Over Ethernet (Poe)
Power over Ethernet (PoE) When using a PoE-enabled switch The camera is PoE-compliant, allowing transmission of power and data via single Ethernet cable. See the following illustration to connect the camera to a PoE- enabled switch via Ethernet cable. PoE switch PoE switch When using a non-PoE switch Use a PoE power injector (optional) to connect between the camera and a non-... -
Page 8: Assigning Ip Address
"Next" button to continue the program. Installation Wizard 2 3. The program will search the VIVOTEK Video Receivers, Video Servers or Network Cameras on the same LAN. 4. After searching, the main installer window will pop up. Click on the MAC that matches the one labeled on the bottom of your device to connect the Internet Explorer to the Network Camera. -
Page 9: Ready To Use
Ready to Use 1. Access to the Network Camera from the Internet. 2. Retrieve live video through web browsers or recording software. Network Camera 3. Unscrew the zoom controller to adjust the zoom factor. Upon completion, tighten the zoom controller. 4. -
Page 10: Fine-Tune The Camera Focus
Fine-tune the Camera Focus 1. Detach the CS-mount lens from the camera body. 2. Turn the camera body bottom up. 3. Use the supplied L-type hex key wrench to loosen the lens mounting screw; the CS-mount ring becomes rotatable. 4. Use a coin to turn the CS-mount ring; fine-tune the distance between the sensor and the lens. - Page 11 P/N:625006300G Ver.1.0 Copyright 2008 VIVOTEK INC. All rights reserved.
