8300 Stainless Steel Gas Grill Parrilla de Gas de Acero Inoxidable OWNER’S MANUAL / MANUAL DEL PROPIETARIO ASSEMBLY AND OPERATING INSTRUCTIONS INSTRUCCIONES DE ARMADO Y OPERACIÓN SAVE THIS MANUAL FOR FUTURE REFERENCE GUARDE ESTE MANUAL PARA REFERENCIA FUTURA WARNING/ADVERTENCIA NOTICE TO INSTALLER:...
Page 2
IMPORTANT SAFETY WARNINGS WE WANT YOU TO ASSEMBLE AND USE YOUR GRILL AS SAFELY AS POSSIBLE. THE PURPOSE OF THIS SAFETY ALERT SYMBOL IS TO ATTRACT YOUR ATTENTION TO POSSIBLE HAZARDS AS YOU ASSEMBLE AND USE YOUR GRILL. WHEN YOU SEE THE SAFETY ALERT SYMBOL PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS! READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND OPERATING YOUR GRILL.
GENERAL WARNINGS WARNING • Never use natural gas in a unit designed for liquid propane gas. • Never use charcoal or wood briquets in a gas grill. Flavoring chips must be contained in a metal smoking box to contain ash and prevent fires. •...
WARNING • FOR OUTDOOR USE ONLY. DO NOT operate indoors or in an enclosed area such as a garage, shed or breezeway. • Use your grill OUTDOORS in a well ventilated space away from dwellings or other buildings to prevent dangers associated with gas accumulation and toxic vapors. We recommend your grill be situated at least 10 feet (3.1 m) from buildings.
Page 6
CYLINDER SPECIFICATIONS: When purchasing or exchanging a cylinder for your gas grill, it must be constructed and marked in accordance with the specifications for LP gas cylinders of the U.S. Department of Transportation (DOT) or the National Standard of Canada, CAN/CSA-B339 Cylinders, Spheres and Tubes for Transportation of Dangerous Goods;...
WARNING FILLING THE LP GAS CYLINDER: • Allow only qualified LP gas dealers to properly fill or repair your LP gas cylinder. • New tanks should be purged prior to filling; inform LP gas dealer if you are using a new tank. •...
Page 8
DO NOT attempt to connect it to any other fuel supply source such as a natural gas line. • DO NOT use any other pressure regulator/hose assembly other than the one supplied with your grill. Replacement pressure regulator/hose assembly must be part No 155-8300-W, which can be obtained by contacting customer service at 800-527-0717. •...
DANGER LEAK TESTING: To prevent fire or explosion hazard: • DO NOT smoke or permit ignition sources in the area while conducting a leak test. • Perform test OUTDOORS only in a well ventilated area. • Never perform a leak test with a match or open flame. •...
Inspect the gas supply hose for burns, chaffing, kinks, and proper routing before each use. If it is evident there is excessive abrasion or wear, or the hose is cut, it must be replaced prior the grill being used. Replace with hose and regulator, Model No. 155-8300-W, which can be obtained by contacting customer service at 800-527-0717.
WARNING Read, understand and follow all warnings and instructions contained in this manual. DO NOT skip any of the warnings and instructions contained in the preceding sections of this manual. WARNING LIGHTING INSTRUCTIONS: Follow the instructions exactly. 1. OPEN THE GRILL LID before attempting to light a burner so that fumes do not accumulate inside the grill.
LIGHTING THE SIDE BURNER: 1. Open lid before lighting side burner. 2. Make sure control knob is in the "OFF" position. 3. Push and turn side burner control knob to HIGH. 4. Press the electronic igniter and hold for 3-5 seconds to light burner.
WARNING OPERATING THE GRILL: Never use charcoal or wood briquets in a gas grill. Flavoring chips must be contained in a metal smoking box to contain ash and prevent fires. Read and follow all warnings and instructions contained in the preceding sections of this manual. BREAKING IN YOUR GRILL: •...
ROTISSERIE COOKING: • Your grill was pre-drilled from factory to include mounting holes for a rotisserie (sold separately). Do not use a rotisserie not specifically manufactured for this grill. • Read and follow all instructions provided with the rotisserie. Save instructions for future reference. •...
GRILL COOKING TIPS CLEANLINESS • Always wash hands thoroughly with soap and hot water prior to handling food and after handling raw meat, uncooked poultry or seafood. • When using a platter to carry raw meat, uncooked poultry or seafood to the grill, make sure to wash the platter thoroughly with soap and hot water before placing cooked foods back on the platter or use different platters for raw and cooked foods.
CLEANING AND MAINTENANCE: • Keep the appliance free and clear of combustible materials, gasoline and other flammable vapors and liquids. • Keep the ventilation openings of the cylinder enclosure free and clear of debris. • Visually check burner flames for proper operation (see pictorial in "Burner Assembly/Maintenance" under Proper Care and Maintenance).
BURNER ASSEMBLY/MAINTENANCE CONTINUED Note: Follow the "Gas Leak Testing" section of this manual. Relight burners to verify proper operation. 12. Replace heat distribution plates and cooking grills. PROPER BURNER OPERATION COOKING GRILLS • Clean with mild soap detergent and water. A brass bristled brush or a nylon cleaning pad can be used to remove residue from the stainless steel surfaces.
BEFORE STORING YOUR GRILL: • Ensure that the cylinder valve is fully closed. • Clean all surfaces. • Lightly coat the burners with cooking oil to prevent excess rusting. • If storing the grill indoors, disconnect the LP tank and leave the LP tank OUTDOORS. •...
FREQUENTLY ASKED QUESTIONS Your grill's serial number and model number, and the contact information for Brinkmann Customer Service, are listed on a silver label found beneath the control panel, on the back of the grill or on the side of the grill body, under the side shelf.
FREQUENTLY ASKED QUESTIONS Cleaning Stainless Steel Cooking Grills: Wash grills with a mild detergent and rinse with hot water before initial use and as needed. DO NOT use a commercial oven cleaner. For stubborn food residue, use a degreaser and fiber or brass cleaning brush. Cleaning Porcelain-Finished Cast-Iron Cooking Grills: Wash grills with a mild detergent and rinse with hot water before initial use and as needed.
PARTS BAG CONTENTS Make sure you have all items listed under PARTS LIST and PARTS BAG CONTENTS before you begin the installation process. Your Parts Bag will include: Qty. Qty. 29 M6 X 12mm Bolts (Black) M6 Nuts (Black) Wheel Axle Bolts Spring Washers (Silver) AA /1.5V Alkaline Battery Wheel Washers...
BEFORE ASSEMBLING OR OPERATING YOUR GRILL. WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN ASSEMBLING THIS UNIT. ™ The following provided tools are required to assemble this ProSeries 8300 Gas Grill: • Screwdriver • Hex Nut Wrench PARTS LIST: 1 Grill Body Assembly...
Page 23
FOR COVERS, ACCESSORIES AND OTHER PRODUCTS, PLEASE VISIT US ONLINE AT: www.brinkmann.net FOR GRILL WARRANTY REPLACEMENT PARTS, PLEASE VISIT US AT: www.grillpartsonline.com (Proof of purchase will be required.) Inspect contents of the box to ensure all parts are included and undamaged.
Page 24
Choose a good, cleared assembly area and get a friend to help you put your grill together. Lay cardboard down to protect grill finish and assembly area. CAUTION: Some parts may contain sharp edges. Wear protective gloves if necessary. Step 1 Attach cart base to side cart legs.
Page 25
Step 5 Attach tank holder onto cart base by using three M6 X 12mm bolts (black). Note: With the help of a friend, turn the cart assembly over. Try to minimize the stress to the legs. Step 6 Locking Caster Attach locking casters to the bottom of the legs.
Page 26
Note: With the help of a friend, turn Grill Body the cart to its upright position. Assembly Try to minimize the stress to the legs. Lock the Casters to stabilize the grill before performing Step 9. Note: When performing Step 9, lift grill body from front and rear panels to avoid injury to hands and fingers.
Page 27
Step 10 Attach side table front panel to left side table with two M6 nuts (black) and star washers (black). Step 11 Attach hooks to side table towel rack bar. Then attach towel rack bar to side table using two M6 X 12mm hexagonal bolts (silver) and spring washers (silver).
Page 28
Step 13 Attach side table to left side of cart frame assembly. Insert two M6 X 12mm bolts (black) into both left legs halfway. Place table over bolts and slide toward back of grill, then tighten securely. Fasten side table front panel to grill body with one M6 X 12mm bolt (black).
Page 29
Step 16 Burner Venturi Loosen the two M4 bolts with washers from the bottom of the burner assembly bracket. This will allow the burner to move freely Side while performing Step 17. Burner Valve Step 17 Remove two M4 bolts and washers from the side burner Valve valve.
Page 30
Step 19 Attach side burner igniter lead wire to the electrode as illustrated. Step 20 Place the side burner grate onto the side burner table. Grease Cup Grease Tray Step 21 Insert grease tray into tracks on backside of grill. Hang grease cup from brackets on bottom of grease tray.
Page 31
Warming Rack Step 22 Place the heat distribution plates Cooking Grills on lower level of grill body assembly directly above burners. Heat Distribution Plates Step 23 Place cooking grills on support ribs directly above heat distribution plates. Grooves Step 24 Place warming rack in grooves so that it sits above the cooking grills.
Page 33
IMPORTANTES ADVERTENCIAS DE SEGURIDAD ES NUESTRO DESEO QUE ARME Y UTILICE SU PARRILLA EN LA FORMA MÁS SEGURA POSIBLE. EL PROPÓSITO DE ESTE SÍMBOLO DE ALERTA DE SEGURIDAD ES QUE USTED PRESTE ATENCIÓN A LOS POSIBLES PELIGROS CUANDO ARME Y UTILICE SU PARRILLA. ¡CUÁNDO VEA ESTE SÍMBOLO DE ALERTA DE SEGURIDAD PRESTE ESPECIAL ATENCIÓN A LA INFORMACIÓN A CONTINUACIÓN!
Page 34
ÍNDICE Advertencias generales ............34 Instalación, especificaciones y uso seguro del cilindro de propano líquido .
ADVERTENCIAS GENERALES ADVERTENCIA • Nunca use gas natural en una unidad diseñada para gas de propano líquido. • Nunca use briquetas de carbón en una parrilla de gas. Los pedacitos de madera para dar sabor se deben colocar en una cajita de fumar de metal para contener la ceniza y para prevenir fuegos. •...
ADVERTENCIA PARA USO EXTERIOR ÚNICAMENTE. NO opere la parrilla en áreas interiores o en un área cerrada • como un garaje, cobertizo o pasadizo. Use la parrilla AL AIRE LIBRE en un espacio bien ventilado alejado de viviendas u otros edificios para •...
Page 37
ESPECIFICACIONES DEL CILINDRO Cuando compre o cambie un cilindro para la parrilla de gas, debe estar construido y marcado de acuerdo con las especificaciones para cilindros de gas de propano líquido del Departamento de Transporte (DOT) de EE.UU. o la Norma Nacional de Canadá, CAN/CSA-B339: Cilindros, esferas y tubos para el transporte de artículos peligrosos;...
ADVERTENCIA LLENADO DEL CILINDRO DE GAS DE PROPANO LÍQUIDO: • Sólo los distribuidores de gas de propano líquido capacitados deben llenar o reparar su cilindro. • Los tanques nuevos deben ser purgados antes de llenarlos; dígale al distribuidor de gas que está usando un tanque nuevo.
Page 39
NO use ningún otro conjunto de regulador de presión/manguera que no sea el suministrado con la parrilla. El número de parte del conjunto de regulador de presión/manguera de repuesto debe ser Brinkmann Nº 155-8300-W y puede obtenerse comunicándose con Brinkmann al 800-527-0717. •...
PELIGRO PRUEBAS DE DETECCIÓN DE FUGAS: Para impedir los peligros de incendio o explosión: • NO fume ni permita que haya fuentes de encendido en el área mientras realiza la prueba de detección de fugas. • Realice la prueba AL AIRE LIBRE únicamente, en un área bien ventilada. •...
Si hay evidencia de abrasión o desgaste excesivo, o si la manguera está cortada, debe reemplazarse antes de usar la parrilla. Reemplácela con una manguera y regulador Modelo Nº 155-8300-W que puede obtenerse comunicándose con el servicio de atención al cliente al 800-527-0717.
ADVERTENCIA Lea, entienda y siga todas las advertencias e instrucciones indicadas en este manual. NO pase por alto ninguna de las advertencias o instrucciones indicadas en las secciones anteriores de este manual. ADVERTENCIA INSTRUCCIONES DE ENCENDIDO: Siga las instrucciones al pie de la letra. ABRA LA TAPA DE LA PARRILLA antes de tratar de encender una hornilla para que no se acumulen vapores dentro de la parrilla.
ENCENDIDO DE LA HORNILLA LATERAL: 1. Abra la tapa antes de encender la hornilla lateral. 2. Verifique que la perilla de control esté en la posición "OFF" (apagado). 3. Empuje y gire la perilla de control de la hornilla lateral a la posición "HIGH"...
ADVERTENCIA OPERACIÓN DE LA PARRILLA: Nunca use briquetas de carbón en una parrilla de gas. Los pedacitos de madera para dar sabor se deben colocar en una cajita de fumar de metal para contener la ceniza y para prevenir fuegos. Lea y siga todas las advertencias e instrucciones indicadas en las secciones anteriores de este manual.
Page 45
COCCIÓN ESTILO ROTISSERIE: • La parrilla viene preparada de la fábrica con agujeros de montaje para instalar un asador estilo rotisserie (vendido aparte). No use un asador estilo rotisserie que no haya sido fabricado especialmente para esta parrilla. • Lea y siga todas las instrucciones incluidas con el asador estilo rotisserie. Guarde las instrucciones para referencia futura.
RECOMENDACIONES PARA COCINAR EN LA PARRILLA LIMPIEZA • Siempre lávese bien las manos con agua caliente y jabón antes de manipular alimentos y después de tocar carne, pollo o mariscos crudos. • Cuando utilice una fuente para llevar carne, pollo o mariscos crudos a la parrilla, asegúrese de lavar bien la fuente con agua caliente y jabón antes de colocar alimentos cocidos en ella, o utilice fuentes distintas para los alimentos crudos y cocidos.
LIMPIEZA Y MANTENIMIENTO: • Mantenga el artefacto alejado de materiales combustibles, gasolina u otros vapores o líquidos inflamables. • Mantenga los orificios de ventilación del gabinete del cilindro sin residuos. • Observe las llamas de las hornillas para verificar que estén funcionando bien (consulte el dibujo en "Instalación/Mantenimiento de las Hornillas"...
CONTINUACION DE INSTALACIÓN/MANTENIMIENTO DE LAS HORNILLAS Nota: Siga la sección “Verificación de Ausencia de Fugas” de este manual. Vuelva a encender las hornillas para verificar la operación apropiada) 12. Reinstale las placas de distribución del calor y las rejillas para cocinar. OPERACION APROPIADA DE HORNILLA REJILLAS PARA COCINAR •...
ANTES DE GUARDAR LA PARRILLA: • Verifique que la válvula del cilindro está bien cerrada. • Limpie todas las superficies. • Aplique una capa ligera de aceite para cocinar a las hornillas para evitar la oxidación excesiva. • Si va a guardar la parrilla en un área interior, desconecte el tanque de propano líquido y déjelo AFUERA.
PREGUNTAS FRECUENTES El número de modelo y número de serie de la parrilla y la información para contactarse con el Servicio de atención al cliente de Brinkmann se incluyen en una etiqueta plateada abajo del panal de control o en el costado de la caja de la misma, debajo del estante lateral y tambien atras del assador en el panal.
Page 51
PREGUNTAS FRECUENTES Limpieza de las rejillas para cocinar de acero inoxidable: Lave las rejillas con un detergente suave y enjuáguelas con agua caliente antes del uso inicial y según sea necesario. NO use un limpiahornos comercial. Para residuos de alimentos persistentes, utilice un desgrasador y un cepillo de limpieza de fibra o latón. Limpieza de rejillas para cocinar de hierro fundido con acabado de porcelana: Lave las rejillas con un detergente suave y enjuáguelas con agua caliente antes del uso inicial y según sea necesario.
E INSTRUCCIONES ANTES DE ARMAR Y USAR LA PARRILLA RECOMENDAMOS QUE ESTA UNIDAD SEA ARMADA POR DOS PERSONAS Se necesitan las siguientes herramientas incluidas para armar esta Parrilla de Gas ProSeries ™ 8300: • Destornillador • Llave para Tuercas Hexagonales...
Page 53
PARA CUBIERTAS, ACCESORIOS Y OTROS PRODUCTOS, FAVOR DE VISITARNOS POR LA RED MUNDIAL EN: www.brinkmann.net PARA PARTES DE REEMPLAZO DE PARRILLA BAJO GARANTIA, FAVOR DE VISITARNOS POR LA RED MUNDIAL EN: www.grillpartsonline.com (Se requerirá el comprobante de compra.) Inspeccione el contenido de la caja para verificar que todas las partes estén incluidas e intactas.
Page 54
CONTENIDO DE LA BOLSA DE PARTES Verifique que tiene todos los artículos indicados en la LISTA DE PARTES y en el CONTENIDO DE LA BOLSA DE PARTES antes de comenzar con el proceso de instalación. La bolsa de partes incluirá lo siguiente: Cant.
Page 55
Elija un lugar adecuado y despejado para armar la parrilla y pídale a un amigo que le ayude. Tienda cartón sobre el suelo para proteger el acabado de la parrilla y el área de armado. PRECAUCIÓN: Algunas partes pueden tener bordes afilados. Póngase guantes de protección si es necesario.
Page 56
Paso 5 Ate el soporte para el tanque a la base del carro con tres pernos M6 X 12mm (negros). Nota: Voltee el conjunto del carro con la ayuda de un amigo. Trate de minimizar la tensión sobre las piernas. Paso 6 Rueda Trabable Instale las ruedas trabables en el...
Page 57
Conjunto Nota: Voltee el conjunto del carro del Cuerpo para que este de pie con la de la Parrilla ayuda de un amigo. Trate de minimizar la tensión sobre las piernas. Trabe las ruedas para estabilizar la parrilla antes de llevar a cabo Paso 9.
Page 58
Paso 10 Instale el panel frontal de la mesa lateral izquierda a la mesa lateral izquierda con dos tuercas M6 (negras) y arandelas de estrella (negras). Paso 11 Ate los ganchos de la rejilla para toallas a la barra de la mesa lateral. Entonces conecte la barra de la toalla a la mesa lateral usando dos pernos M6 X 12mm hexagonales...
Page 59
Paso 13 Instale la mesa lateral en el lado izquierdo del asamblaje del carro. Inserte dos pernos M6 X 12mm (negros) en ambas piernas izquierdas a mitad. Coloque la mesa sobre los pernos y deslícela hacia atras de la parrilla, luego apriete bien. Conecte el panel frontal de la mesa lateral al cuerpo de la parrilla con un perno M6 X 12mm (negro).
Page 60
Paso 16 Válvula Con las arandelas, afloje los dos de la pernos M4 desde la parte inferior Venturi de la Hornilla Hornilla del soporte de ensamblaje del Lateral quemador. Gracias a ello, el quemador podrá moverse libremente mientras lleva a cabo el Paso 17.
Page 61
Paso 20 Coloque la rejilla de la hornilla lateral sobre la mesa de la hornilla lateral. Paso 21 Inserte la bandeja de grasa en la abertura en el lado trasero de la parrilla. Cuelgue la gaveta para grasa desde los soportes de bajo de la bandeja de grasa.
Page 62
Paso 21 Rejilla para Coloque las placas de distribución Calentar de calor en el nivel inferior de la caja de la parrilla, directamente Rejillas para sobre las hornillas. Cocinar Cubiertas Térmicas Revestidas Paso 22 Coloque las rejillas para cocinar sobre las costillas de apoyo directamente sobre las placas de distribución de calor.
Page 64
ANY LIABILITY FOR INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING FROM THE FAILURE OF THE BRINKMANN PROSERIES 8300 TO COMPLY WITH THIS WARRANTY OR ANY IMPLIED WARRANTY IS EXCLUDED. CUSTOMER ACKNOWLEDGES THAT THE PURCHASE PRICE CHARGED IS BASED UPON THE LIMITATIONS CONTAINED IN THE WARRANTY SET OUT ABOVE. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
