Hasler HJ830 Operating Manual

Hide thumbs Also See for HJ830:
Table of Contents

Advertisement

Quick Links

Operating Guide
Mailing Systems
HASLER
And Solutions
®
America's better choice
HJ830 and HJ930
Inkjet Printers
An ISO 9001 Quality System
Certified company
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HJ830 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hasler HJ830

Summary of Contents for Hasler HJ830

  • Page 1 Operating Guide Mailing Systems HASLER And Solutions ® America’s better choice HJ830 and HJ930 Inkjet Printers An ISO 9001 Quality System Certified company...
  • Page 2 Products presented in this guide are conform to requirements of directives nbr 73/23/CEE and 89/336/CEE. Neopost has implemented a program for the recycling of worn machines and machines at the end of their lifetime. Contribute in a responsible way to the environmental protection by consulting your retailer internet site, or by contacting him.
  • Page 3 © Copyright 2008 All rights reserved. This manual may not be reproduced in whole or in part, trans- ferred, stored in a telemetry system or translated into any language, in whatsoever form, without prior written permission. The manufacturer assumes no liability for damages occurring as a result of misuse, repairs and modifications, which are carried out by unauthorized third parties.

  • Page 4: Table Of Contents

    Table of Contents Table of Contents Introduction Pictograms Notes for the Use of this Manual Important Terms and Abbreviations System Requirements Safety Notes General Safety Notes Handling Ink Cartridges Location of the Printer Disposal Transport and Packaging Shipping Unpacking the Printing Assembly Printer Description Machine Overview...
  • Page 5 Inserting the Ink Cartridge 5.3.1 Correctly Inserting the Ink Cartridge 5.3.2 Resetting the Ink Counter 5.3.3 Display for the Change of Ink Cartridge 5.3.4 Set the ink Counter 5.3.5 Cleaning the Ink Jets Print job Setup 5.4.1 Setting Media Widths for the Machine 5.4.2 Setting the Print Format 5.4.3...
  • Page 6 8.2.1 Centronics Parallel Interface 8.2.2 RS-232-C Serial Interface Fonts 8.3.1 Terminology 8.3.2 Character Set 8.3.3 Selection of the Fonts for Printing Character Sets 8.4.1 7-Bit Character Sets 8.4.2 8-Bit Character Side Guide Accessories Technical Data Glossary...

  • Page 7: Introduction

    Introduction With the PRINTER 830/930 you have an innovative digital printer with HP ink jet technology for printing variable data - for printing mass mailings, for example, with addresses, serial numbers or other variable information and graphic elements. The machine has been designed for professional use with high performance. In order to ensure both long service life of PRINTER 830/930 and its components, as well as safe conditions of use, we recommend that you read carefully and comply with the operating instructions and...

  • Page 8: Notes For The Use Of This Manual

    Notes for the Use of this Manual The following sections provide all the general information and explanations re- quired, in order to be able to carry out the subsequent tasks and procedures.. When some action is expected from the assembler or operator, the text is always preceded by a dot, for example: First step.

  • Page 9: Safety Notes

    Safety Notes For your own safety and the proper functioning of the machine, please, read care- fully the following instructions, before starting your machine. Always be aware of all warnings and notes that are affixed to or printed on the machine itself. Store this manual in a safe place where it is easily accessible for future reference, at any time.

  • Page 10: General Safety Notes

    General Safety Notes Caution! Please, read these notes with care. Save this manual for future reference. All notes and warnings found on the machine are to be followed. Installing the A safe, level position is necessary, when installing the machine. Machine Injuries may be caused by tipping, rolling away or falling.
  • Page 11 Allow the In the following cases, you should unplug the machine from the Machine to mains and contact an authorized service technician: be Inspected When the power cord or its plug is worn or damaged. • by the Ser- When water or other liquid has entered the device. vice Partner! •...

  • Page 12: Handling Ink Cartridges

    Handling Ink Cartridges Store ink cartridges out of the reach of children. Normally, no ink leakage can occur. Immediately wash off sprays of ink from the skin under running water. Should ink get into the eyes, rinse it out im- mediately with sufficient water.

  • Page 13: Transport And Packaging

    Transport and Packaging Shipping The PRINTER 830/930 is shipped in packaging designed for the purpose of delivery at its intended destination, via regular transportation, in undamaged condition. The forwarding agent is liable for damages occurring in transit. Transport and stor- age should take place under normal conditions, i.e.

  • Page 14: Assembly

    Assembly Assembly of the Paper Support Plate and Side Guide 1. Set the side guide in the lower metal opening and lock in place with a quarter turn of the bayonet coupling. 2. In the same manner, set the guide bracket in the upper metal opening. Illustration 3-1: PRINTER 830/930 assembly...

  • Page 15: Printer Description

    Printer Description Machine Overview Illustration 4-1: PRINTER 830/930 back side 1. USB Connection 4. Printer Parallel Cable Connection 2. Serial Status Connection 5. Power cord Connection 3. ON/OFF Switch 6. Fuse holder...

  • Page 16: Range Of Application

    Illustration 4-2: PRINTER 830/930 front side 1. Control panel with display 8. Knurled screw printing unit car- riage 2. Side guide middle 9. Printing unit height adjustment 3. Side guide short No ill.: Side guide long 10. Knurled screw height adjustment outfeed rollers 4.

  • Page 17: Operation

    Operation The PRINTER 830/930 is designed for operation on an IBM-compatible PC. Printing can be carried out from most word processing, database and address processing programs. The printer has a printing unit with three HP ink cartridges. This allows the printing of addresses with no movement of the printing unit itself.

  • Page 18: Key Combinations

    LED Functions Green LED = Online Blue LED = Offline Orange LED= Warning Red LED = Error In online mode the printer can only be switched to offline by pressing the “Offline” (7) button. 4.4.2 Key Combinations The key combinations have, in connection with the switching on of the machine, the following functions: Power Home Quick...

  • Page 19: The Display

    The Display Meaning of the display information: This is just an example and could looks different, depending on the printer setup. C o u n t. P o w r. O N : I n k C o s t s / J o b : 0 .

  • Page 20: Online Mode

    4.5.2 Online Mode In this type of operation, you can start the machine via command sequences from your computer. Printing is carried out in this type of operation. Brief Instructions In order to be able to quickly carry out a test print with no previous experience, you should follow the operational steps listed in the table below, in the correct order.

  • Page 21: Start-Up And Operation

    Start-Up and Operation Setting Up and Connecting the Printer Install the printer as described in chapter 2.3 - “Location of the Printer“. Power Cord See Illustration 4-2: PRINTER 830/930 front side on page 17 Caution! The PRINTER 830/930 is a device of class 1! The machine may only be operated on electrical circuits with protec- tive grounding conductors (ground)! Connect the power cord to the printer.

  • Page 22: Installing The Driver

    Administrator Privileges. According to the Windows security model, only the Administrator can install the driver. 1. Insert the CD labelled Hasler Address Printer Installation. The installation program should start automatically, if it doesn’t, browse the CD and open the file named Install_Menu.
  • Page 23 3. You will be brought to the welcome screen of the Printer Installation Wizard. The wizard will walk you through the process of installing the driver. Click Next. 4. Select Local printer attached to this computer. Click Next.
  • Page 24 5. Select the appropriate printer port. Click Next. 6. Choose your printer model from the menu. Click Next.
  • Page 25 7. Select wether or not you wish to set this as your default printer. Click Next. 8. You are now given the choice of sharing this printer on your network. Click Next.
  • Page 26 9. Choose wether or not you’d like to print a test page. Click Next. 10. Verify all of your information and click Finish to complete the installation.
  • Page 27 11. You may receive the warning seen below. Click Continue Anyway to complete the installation. 12. Installation is now complete.

  • Page 28: Correctly Inserting The Ink Cartridge

    5.3.1 Correctly Inserting the Ink Cartridge First, you must have access to the cartridge holder. In the event that the printing unit is found on the front sidewall, unscrew the thumb screw on the printing unit and push the printing unit into the middle. 1.

  • Page 29: Resetting The Ink Counter

    Illustration 5-22: Inserting the ink cartridge Illustration 5-23: Close locking lever 5.3.2 Resetting the Ink Counter If you are online, change to offline mode with the Offline button. Press the Home button. Change to the Printer Configuration menu and confirm with the Arrow Right button.

  • Page 30: Set The Ink Counter

    If less than 5% ink is in the cartridge the ink level bars are not displayed and you get an error message: NO INK !! CHANGE PRINTHEAD In the menu “Error Level” you can select: STOP: Printer should stop if “No Ink” is displayed IGNORE: Printer should print if “No Ink”...

  • Page 31: Cleaning The Ink Jets

    Illustration 5-24: Ink supply display For replacing the cartridge, switch the printer offline using the start key (Off must be indicated on the display). Carry out a “CARTRIDGE RESET“ in the menu. 5.3.5 Cleaning the Ink Jets For time to time, the ink jets need to be cleaned or unclogged. 1.
  • Page 32 Illustration 5-25: Set printer 1. To do this, loosen the thumb screws (1) of the printing unit. 2. Use the scale button (2) to set the width of the print object. The button has a millimetre scale. 3. Screw the thumb screw of the printing unit in tightly. 5.4.1.2 Setting the Media Width for the Sheet Separating System Height adjustment of the pickup rollers Up to a print object width from 1.5 mm to 2 mm, the rollers can remain in the low-...
  • Page 33 Both sheet separators must always be set, even when – for example – a small format print object only lies on one separator. When this is not done, the free separator may drag on the transport rollers. This leads to increased wear on the transport rollers; entry may cause damage. Illustration 5-27: Setting the separating finger 1.

  • Page 34: Setting The Print Format

    Failure to comply with these steps can lead to premature wear on the separation rollers. 3. Allow both separators (1), without exerting pressure, to fall upon the print object and again fix the knurled screws (2) in position. 5.4.2 Setting the Print Format 5.4.2.1 Setting the Print Position of the Address Before setting the desired address position, you must know in which area printing is possible.
  • Page 35 5.4.2.2 Positioning the Address in Height The PRINTER 830/930 is a WYSIWYG printer with limitations. The limitations lie in the vertical position of the address. Heeding the following note is important for your document: 1. In your page layout, set your document to the portrait format. 2.
  • Page 36 Illustration 5-30: Setting the print object format If the lines run parallel to the shorter side, the intake occurs using the longer side. Illustration 5-31: Setting the print object format 1. Push the rear side guide completely to the side wall of the machine. 2.

  • Page 37: Checking The Paper Transport

    Illustration 5-32: Setting the guide bracket 6. Now test the trouble-free feeding of the print object. To do this, allow a stack of the print object to run through with the help of the paper transport in the Offline mode as follows: Caution! When doing this, do not put your hands inside the ma- chine when it is in operation.

  • Page 38: Machine Counters

    Printing the Test Picture 1. Place as many media in the feeder as you would like to use for a test print, e.g. 1 medium. 2. Confirm with the Quick +Arrow Up keys. The test print is carried out. Press the key again, in order to stop the procedure.

  • Page 39: Counting Of Job

    5.6.3 Counting of Job Pages A job page count contains the number of data printouts received by the computer with the accompanying paper ejection. This count is carried out with the machine in the online condition. When you continue data transmission with printouts, counting is resumed. All counters are reset when the machine is switched off! To change the view of the 3 counters you have to be in the Offline mode.

  • Page 40: The Programming Mode

    The Programming Mode Purpose of the Programming Mode The programming mode is used for setting manually a number of parameters via the control panel. Parameters are definitions of set point values for font settings, print quality, papers settings, as well as special and test functions. Since the printer is operated, as a general rule, from a text or address processing program, the factory settings have been optimized for this, and normally no changes are necessary.

  • Page 41: Keyboard Layout In The Programming Mode

    Keyboard Layout in the Programming Mode Illustration 6-1: Keyboard layout for the programming mode In online mode, the printer can only be switched to offline mode by pressing the „Offline“ button. Quick Button The Quick button can only be used in offline mode. Function when singly applied: By pressing the Quick button, the quick menu can be directly called up at any time;...
  • Page 42 Quick – Arrow Left = Run Paper (Supply Paper) • If you press the button shortly, only one sheet is transported; afterwards you re- turn to the previous display. If you press the button for a prolonged time, a con- tinuous paper run is started.

  • Page 43: Menu Overview

    Menu Overview If the printer is Offline, press the H O M E - k e y and the display will show the main menu from the printer. With the Arrow up and Arrow down keys you can navi- gate through this menu. With the O K o r A r r o w r i g h t y o u a r e a b l e t o c o n f i r m t h e s u b m e n u .
  • Page 44 Main menu Submenu Options Job Parameter Quality 6x6D, 6x3D, 3x6D, 3x3D, 2x6D, 2x3D, 1x6D, 1x3D Transport Param. Paper Speed Auto. Pap. Speed Paper Time Out Layout Orientation Paper Size Left Margin (mm) Offs. Edge (mm) Font Parameter Font Character Spacing Character Set Typ of Barcode Zip, bpo4, Kix,2/5i, EAN,...

  • Page 45: Explanation Of The Individual Menus

    Correction Pattern Cart. Print Pattern Check Cartridges LED/ Beeper Configuration Info Firmware: (X.X.XX) SerNr.: (XXXXXXXXXXX) Page Cnt.: (XXXX) RAM: (64 MB) Hardware: (V16-0) DC: (x A) Printing Setting Dump Printing Input Dump Print Character Set Main menu Submenu Options Englisch, Deutsch Language Franz., Ital., Esp Main menu...

  • Page 46: Printer Configuration

    Language Different languages can be selected. Settings Selection of a configuration. Printer Configuration Maintenance Auto Clean Heads Off is the factory setting. In the setting „1st“, prior to each print job, a page with a black bar is printed to purge the cartridges. Auto Prime off = no cleaning of the jets before printing or by means of a test print on = Jets are cleaned before printing, when no paper lies beneath the light barrier...
  • Page 47 Cartridge Optimizing Optimizing the cartridge temperature (TTOE) Selection possibilities: • all: all three cartridges are optimized Crt1: only cartridge 1 is optimized Crt2: only cartridge 2 is optimized Crt3: only cartridge 3 is optimized no action is carried out Check: Testing and display of the condition for each cartridge For the optimization, no paper may lie underneath the cartridges.

  • Page 48: Job Parameter

    Volume Cart. (ml): Capacity of the cartridge Volume Drop (pl): Capacity of the drop Costs/ Cartridge: Costs for one cartridge Currency: Euro, Dollar, Pound, Yuan, other Error Handling Error Level Font Low = Printer doesn’t stop if it gets an undefined character during transfer from the High = Printer stops printing if it gets an undefined character during transfer.
  • Page 49 PRINT QUALITY Speed Level Max. Speed in mm/s / inch/s 2x3, 2x6 1520 / 59.84 1320 / 51.97 3x3, 3x6 1080 / 42.5 920 / 36.2 720 / 28.3 6x6, 6x3 540 / 21.26 420 / 16.5 270 / 10.6 120 / 4.72 Auto.
  • Page 50 DIN A4 Paper 8 1/4 x 11 11/16 210 x 297 DIN A5 Paper 5 13/16 x 8 1/4 148 x 210 MONA Monarch Envelope 3 7/8 x 7 1/2 98 x 190,5 Com-10 (Business) Envelope 4 1/8 x 9 1/2 105 x 241 INTD International DL...
  • Page 51 Font Parameter Font 13 fonts or font sized have been built into the machine. A font selection can be made here. Character Spacing Increase the character spacing in dots of 0 to 90. Character Set National character sets with some special symbols for the applicable foreign lan- guage.

  • Page 52: Service

    Dos Mode Linemode This makes possible address separation, through a certain number of line breaks. HEX to ASCII Conversion from HEX to ASCII. When the conversion is switched on, then the printer interprets the percent sign “%“ as an unprintable control character. Both characters following the % character will be interpreted as HEX values, e.g.
  • Page 53 Alignment Vertic. = Printing a special test page to test the vertical alignment. Correction Pattern = Printout to determine the correction value in order to calibrate the car- tridges. Cart. Print Pattern In several test prints for the cartridges. The contacts to the jets are shown in a grid. (See following page) Illustration 6-2: Test Print of all cartridges The contacts for all jets are controlled sequentially and made visible in a continuous slanting line.

  • Page 54: Configuration Info

    Illustration 6-4: Test print with defective jets a.1 = no connection at contact “K“ (with printhead H1) • a.2 = no connection at contact “B“ (with printhead H3) b.1 = no connection at contact “10“ (with printhead H1) • b.2 = no connection at contact “16“ (with printhead H3) c = these jets are not clean •...

  • Page 55: Language

    print. The required data is now at the front of the buffer. Stop the procedure using the end key. Print Character Set Printout of the character set. 6.8 Language The displayed text can be shown in different languages: English, German, French, Italian and Spanish.

  • Page 56: Initialization Of The Machine

    Press the "OK" key. The changed value is saved in the configuration under the se- lected "Setting No", and the machine is again in offline mode press the "Online" key. The machine is again in online mode, so that the print job can be resumed immediately.

  • Page 57: Troubleshooting

    Troubleshooting The Meaning of Some of the Display Notes ??? blinks • Data/Addresses were transmitted, but there is no print object. NoD blinks. • The last data/addresses are incomplete (FormFeed is missing) Wait blinks. • Printing has halted, because the control character EOT was sent. Printing can be resumed with the start key.

  • Page 58: Error Messages

    Error Messages Error Messages Cause Remedy No paper Insert paper NO PAPER !! PAPER JAM OR Paper jam Check paper width WRONG PAPER LENGTH! Insert a new cartridge and NO INK !! The cartridge is empty. CHANGE CARTRIDGE reset the counter. Factory setting CHECKSUM ERROR! Error in the buffered RAM...
  • Page 59 Error Messages Cause Remedy Error of the HP PEN Check plug connection ERROR PEN BOARD# U# CALL SERVICE board# #=1,2,3 Replace PEN board CPU board with small RAM RAM ERROR Replace CPU board. memory CALL SERVICE PRINTER ERROR Install correct board and firmware WRONG BOARD/FIRMWARE Reload firmware;...

  • Page 60: Warning Messages

    Warning Messages Warning Message Cause Remedy Warning:Non-Existent Selected font does not Printer is switched off and Font Selected! exist in the printer the PC sends remaining data Warning:Non-Existent Selected macro does not After the job has ended, Macro Selected! exist in the printer the addresses cannot be repeated.

  • Page 61: Appendix

    Appendix Maintenance Notes 8.1.1 Cleaning the Ink Cartridge ® Clean the jets of the ink cartridge with a cleaning wipe like the TexWipe brand. The following materials are NOT suitable for the cleaning of the printhead and the ink cartridge! Paper towels •...

  • Page 62: Centronics Parallel Interface

    8.2.1 Centronics Parallel Interface The PRINTER 830/930 is equipped with a standard Centronics parallel interface. This interface is most frequently used as a connection to a personal computer. Unlike the RS-232-C serial connection, there are usually no special commands or configurations for the printer or computer necessary here.
  • Page 63 8.2.1.2 Signal Description Corresponding Signal Signal- Meaning STROBE This pulse 0.5µs) reports that data bits are valid 20-27 DATA 1-8 Data bits D0-D7 ACKNOWLEDGE Printer reports: Data has been processed (is ready to receive) BUSY Printer reports: Data received, data being processed PE (Paper Printer reports to the com- empty)

  • Page 64: Rs-232-C Serial Interface

    8.2.1.3 Pulse Diagram Illustration 8-3: Parallel interface pulse diagram 8.2.2 RS-232-C Serial Interface This segment describes the RS-232-C serial plug connection and the concept of a serial interface connection. The PRINTER 830/930 has a standard RS-232-C serial interface, which is compatible with most computers and terminals. 8.2.2.1 Connector Socket The PRINTER 830/930 has a standard DB-9 serial connector socket...
  • Page 65 8.2.2.2 Plug Assignment Signal Signal Meaning Input/Output free R x d Received data T x d Transmitted data Data Terminal Ready Signal Ground free +12V Clear to Send free Pin 2 Received Data (RxD): Serial transfer of data from the computer to the printer. Pin 3 Transmitted Data (TxD): Serial transfer of data from the printer to the computer system or the terminal (e.g.

  • Page 66: Fonts

    Fonts 8.3.1 Terminology A font is a collection of characters and symbols having the same typeface, spacing size (height), line width and font slant. 8.3.1.1 Typeface Typeface is a set of characters and symbols with a certain design. 8.3.1.2 Serif or Sans Serif Typefaces Serifs are small lines on the top or bottom of a character (so-called “feet”...

  • Page 67: Proportional Spacing

    Fixed Spacing With fixed character spacing, every letter of a font takes up the same width space and has the same spacing as neighbouring letters. Cour and LetGot are fonts with fixed character spacing. Illustration 8-5: Fixed character spacing Proportional Spacing With proportional character spacing, the spacing depends upon the width of the let- ter.
  • Page 68 8.3.1.6 Character Size Character size (character height) refers to the height of a printed capital letter. It is measured in pica points. A point is 1/72 of an inch. The height for both fonts, with fixed and proportional character spacing, is meas- ured in pica points.
  • Page 69 1x3 corresponds to 150x300 1x6 corresponds to 150x600 2x3 corresponds to 200x300 2x6 corresponds to 200x600 3x3 corresponds to 300x300 3x6 corresponds to 300x600 6x3 corresponds to 600x300 6x6 corresponds to 600x600 8.3.1.11 Print Direction The print direction refers to the (readable) address position on the print object. It can be turned around 180°.

  • Page 70: Character Set

    8.3.2 Character Set A character set consists of characters and symbols, which contain all elements of a language or discipline (country-specific characters), including punctuation marks and numbers. 8.3.2.1 7-Bit Character Set A 7-Bit character set corresponds to definitions of the ”International Standards Or- ganisation“...

  • Page 71: Selection Of The Fonts For Printing

    8.3.2.2 8-Bit Character set In the 8-Bit character set there are 256 characters. Many national characters are available with this. The following is a depiction of the most frequently used 8-Bit character set. Illustration 8-10: 8-Bit character set PC8 8.3.3 Selection of the Fonts for Printing The fonts are selected via the software or printer commands.

  • Page 72: Character Sets

    8.3.3.2 Sans Serif Typefaces The following example shows an address with the Helv12 typeface: Test print ADDRESS PRINTER 830/930 PRINTER LAND Character Sets Note for the depiction of character sets: Character set name: The information in parentheses (e.g. USA7) corresponds •...
  • Page 73 England (= UK7) ( 1 E ASCII: Decimal: 27 40 49 69 Hexadecimal: 1B 28 31 45 France (= Fra7) ( 1 F ASCII: Decimal: 27 40 49 70 Hexadecimal: 1B 28 31 46...
  • Page 74 Germany (= Ger7) ( 1 G ASCII: Decimal: 27 40 49 71 Hexadecimal: 1B 28 31 47 Italy (= Ita7) ( 0 I ASCII: Decimal: 27 40 48 73 Hexadecimal: 1B 28 30 49...
  • Page 75 Spain (= Spa7) ( 2 S ASCII: Decimal: 27 40 50 83 Hexadecimal: 1B 28 32 53 Denmark (= Den7) ( 1 D ASCII: Decimal: 27 40 49 68 Hexadecimal: 1B 28 31 44...
  • Page 76 Norway (= Nor7) ( 0 D ASCII: Decimal: 27 40 48 68 Hexadecimal: 1B 28 30 44 Sweden (= Swe7) ( 3 S ASCII: Decimal: 27 40 51 83 Hexadecimal: 1B 28 33 53...
  • Page 77 Sweden/Names (= SwN7) ( 0 S ASCII: Decimal: 27 40 48 83 Hexadecimal: 1B 28 30 53 Portugal (= Por7) ( 4 S ASCII: Decimal: 27 40 52 83 Hexadecimal: 1B 28 34 53...

  • Page 78: 8-Bit Character

    8.4.2 8-Bit Character PC-8 (= PC8) ( 10 U ASCII: Decimal: 27 40 49 48 85 Hexadecimal: 1B 28 31 30 55 Roman8 (= Rom8) ( 8 U ASCII: Decimal: 27 40 56 85 Hexadecimal: 1B 28 38 55...
  • Page 79 PC-850 (= P850) ( 12 U ASCII: Decimal: 27 40 49 50 85 Hexadecimal: 1B 28 31 32 55 ECMA-94 Latin 18 (= ECMA) ( 0 N ASCII: Decimal: 27 40 48 78 Hexadecimal: 1B 28 30 4E...
  • Page 80 PC-8 Denmark/Norway (= P8DN) ( 11 U ASCII: Decimal: 27 40 49 49 85 Hexadecimal: 1B 28 31 31 55 ICEL (= ICEL) ( 33 O ASCII: Decimal: 27 40 51 51 79 Hexadecimal: 1B 28 33 33 4F...
  • Page 81 PC-852 (= P852) ( 17 U ASCII: Decimal: 27 40 49 55 85 Hexadecimal: 1B 28 31 37 55 PC-860 (= P860) ( 20 U ASCII: Decimal: 27 40 50 48 85 Hexadecimal: 1B 28 32 30 55...

  • Page 82: Side Guide

    Side Guide Side guide short (2x) (standard) • Side guide middle (standard) • Side guide long (accessory) • Adjustable width of the Side guide The data (in mm/inches) refers to the print object width crosswise to the transport direction. Rear + frontal side guides, short x 2 •...

  • Page 83: Accessories

    Accessories The following accessories are available (must be purchased separately): Illustration 8-11: Divert mechanism Pos. Description Pieces Divert mechanism The divert mechanism changes the transport direction of the ejected print object 90° on the conveyor belt.

  • Page 84: Technical Data

    Technical Data Throughput For Printer 830: max. 11,000 postcards /hour at 1x3, 1x6 For Printer 930: max. 39,000 post cards /hour at 1x3, 1x6 Printheads Printing speed For the Printer 830: 0.54 m/s For the Printer 930: Minimum 0.15 m/s Maximum 1.84 m/s Throughput For the Printer 830:...

  • Page 85: Glossary

    Glossary ASCll: ASCll is the abbreviation for "American Standard Code for Informa- tion Interchange". The printer commands used in this manual have been entered with ASCII characters. Decimal and hexadecimal char- acters can also be used. Barcode: Data for a print object is converted to a one-line, language- and symbol-neutral barcode.
  • Page 86 inch for the in character density. Data transfer: Data transfer is the transfer of information between the computer and the printer. Character size: The character size is measured in pica points. A point is 1/72 of an inch. DPl: DPI (= Dots Per Inch) is the measuring unit of dots per inch for the image definition.
  • Page 87 LPI: LPI (= Lines Per Inch) is a unit measuring lines per inch for the ver- tical line spacing. Printing is most frequently in 6 lpi line spacing. Offline: In the offline condition, the printer cannot receive data from the computer.
  • Page 88 "sans serif" font. Serial interface: With a serial interface, the data is sequentially transferred (bit by bit), from the computer to the printer. The connection is made by a RS-232-C socket. Serif font: Serifs are "feet" on Bodoni book type. The typeface Cour is a "serif" font, for example.
