A-4
RealPort CardBus Ethernet 10/100+Modem 56 User's Guide
Appendix B. Specifications
General Specifications
Type III CardBus PC Card
Ethernet:
Connectors:
Size:
Weight:
Temperature range:
Operating:
Storage:
Humidity:
Memory:
Power Requirements:
10Base-T
100Base-TX
Modem only
10Base-T+Modem
100Base-TX+Modem 3.3V DC, 340 mA active
Power Management: Supports ACPI, CardBus Power Management
Approvals:
Modem Specifications
Data modulation:
Fax modulation:
IEEE 802.3 10Mbps Ethernet; 802.3u 100Mbps
RJ-45 (100Base-TX/10Base-T Ethernet), RJ-11
(modem), RJ-11 (phone set pass-through),
Mini D-sub (GSM/PCS 1900/cellular)
86.0 mm x 54.0 mm x 10.5 mm (3.37 in x 2.13
in x 0.413 in)
36 g (1.3 oz)
32°F to 149°F (0°C to 65°C)
-4°F to 185°F (-20°C to 85°C)
95% maximum noncondensing
4 megabits memory for dual V.90 and K56flex
3.3V DC, 75 mA idle, 130 mA active, 110 mA
typical
3.3V DC, 150 mA idle, 165 mA active, 160 mA
typical
3.3V DC, 40 mA sleep, 240 mA active
3.3V DC, 280 mA active
Specification, MAGIC PACKET™ WAKE-UP
Technology, Wake on LAN
FCC Part 15, Part 68, CE Mark/CTR 21
V.90/K56flex up to 56000 bps; V.34 from
33,600 down to 2400 bps; V.32terbo at 19200
and 16800 bps; V.32bis at 14400, 12000,
9600, and 7200 bps, uncoded at 4800 bps;
V.32 at 9600 bps, uncoded at 4800 bps; V.23
at 1200/75 and 75/1200 bps; V.22bis at 2400
bps; V.22 at 1200 bps; Bell 212A at 1200 bps
V.17 at 14400, 12000, 9600, 7200, and 4800
bps; V.29 at 9600, 7200, and 4800 bps;
V.27ter at 4800 and 2400 bps
