DFI G586IPV User Manual

Hide thumbs Also See for G586IPV:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
G586IPV
G586IPVF
Rev . A+
System Board
User's Manual
- D31060430 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G586IPV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DFI G586IPV

Summary of Contents for DFI G586IPV

  • Page 1 G586IPV G586IPVF Rev . A+ System Board User's Manual - D31060430 -...
  • Page 2 FCC Statement on Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful in- terference when the equipment is operated in a residential installation.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1: Introduction ............5 Features and Specifications ..........6 Package Checklist .............. 8 Chapter 2: Hardware Installation ..........9 Preparing the Area.............. 9 Handling the System Board ..........9 Installing the System Board ..........10 Board Layout ..............12 System Memory ..............14 DIMM ................14 SIMM ................15...
  • Page 4 Supervisor Password ............39 User Password ............40 IDE HDD Auto Detection ..........41 HDD Low Level Detection ..........43 Save & Exit Setup ............44 Exit Without Saving............44 System Error Report ............45 IDE Device Drivers .............47 Chapter 4: Troubleshooting Checklist ..........48 Appendix A: Types of Modules ............49 Appendix B: Memory and I/O Maps ..........

  • Page 5: Chapter 1: Introduction

    16-bit ISA slots, and the G586IPVF has 3 dedicated PCI slots, 3 dediacted 16-bit ISA slots and 1 shared PCI/ISA slot. 2. PCB Size: The size of the G586IPV is 25cm (9.84") x 22cm (8.66"), and that of the G586IPVF is 26cm (10.14") x 22cm (8.66") 3.

  • Page 6: Features And Specifications

    Features and Specifications Processor • Intel Pentium™ 75/90/100/120/133/150/166MHz • Future Pentium™ OverDrive Processor • Cyrix P120+/ P133+/ P150+/ P166+ • AMD 5 86 75/90MHz • Future 200MHz CPUs Chipset • Intel 82430VX PCIset Cache Memory • Supports 0KB, 256KB or 512KB pipeline burst, direct map write- back cache •...
  • Page 7 3 dedicated PCI Slots (G586IPVF only) • 3 dedicated 16-bit ISA slots • 1 shared PCI/ISA slot (G586IPVF only) • 4 layers, Baby AT from factor • 25cm (9.84") x 22cm (8.66") (G586IPV only) 26cm (10.14") x 22cm (8.66") (G586IPVF only)

  • Page 8: Package Checklist

    Package Checklist The G586IPV and G586IPVF package contains the following items: • The G586IPV and G586IPVF system board • The G586IPV and G586IPVF user’ s manual • One 40-pin IDE hard disk cable • One 34-pin floppy disk drive cable •...

  • Page 9: Chapter 2: Hardware Installation

    Chapter 2 Hardware Installation This chapter summarizes the steps to install the G586IPV and G586IPVF system board into your system unit. It also includes a de- scription of the area in which you must work and directions for memory installation. Before installing the system board, obtain the memory you plan to install.

  • Page 10: Installing The System Board

    ESD protection. Installing the System Board If you are installing the G586IPV AND G586IPVF system board, the following outlines the basic installation steps. Before installing the sys- tem board into your system unit, you should prepare the tools you will need.
  • Page 11 Please refer to the handling instructions on pages 9-10 for proper handling techniques. 6. Insert the memory modules into the memory banks on the G586IPV and G586IPVF. The quantity and location of the memory modules depends on the memory configuration and type of modules you in- tend to use.

  • Page 12: Board Layout

    Board Layout Wi n bond Battery SSM1 Intel SB82371SB Bank 0 Bank 1 Pin 1 The G586IPV system board Pin 1 of the jumpers and connectors PBSRAM = Pipeline Burst SRAM...
  • Page 13 Wi n bond SSM1 Intel SB82371SB Bank 0 Bank 1 Battery Pin 1 The G586IPVF system board Pin 1 of the jumpers and connectors PBSRAM = Pipeline Burst SRAM...

  • Page 14: System Memory

    The DIMM (Dual In-line Memory Module) sockets can support 3.3V SDRAM, FPM and EDO DRAM. The G586IPV and G586IPVF system board can support 8MB to 16MB memory of using a 1MBx64 or 2MBx64 168-pin DIMM. The G586IPV and G586IPVF is equipped with one DIMM socket at location DM1 on your system board.

  • Page 15: Simm

    0 or Bank 1, but you must populate a bank first before going to the next bank. The G586IPV and G586IPVF system board can support 8MB to 128MB of memory using 1MBx32, 2MBx32, 4MBx32, or 8MBx32 72-pin SIMMs. The table below shows the supported SIM modules and their corre- sponding memory sizes.

  • Page 16: Jumper Settings For Dimm And Simm

    Tilt the module upright until it locks in place in the socket. Warning: The DIMM and SIMM can not exist on the G586IPV AND G586IPVF system board at the same time. You must choose either a DIMM or SIMMs on your system board.

  • Page 17: Cache Memory

    Cache Memory The G586IPV and G586IPVF system board can support 256KB or 512KB pipeline burst, direct map write-back cache SRAM. Your system board may come with 0KB or 256KB cache mounted onboard. The 160- pin cache module slot lets you upgrade your cache memory by install- ing a 256KB or 512KB cache module.

  • Page 18: Installing The Cache Module

    Installing the Cache Module Locate the 160-pin cache module slot on the system board (SSM1). See pages 12 and 13 for the location. Position the cache module above the slot. Make sure pin 1 of the cache module is aligned with pin 1 of the slot.

  • Page 19: Cpu Installation

    CPU Installation The G586IPV and G586IPVF allows for easy installation of CPUs. Make sure all jumpers are set correctly before applying power or you may dam- age the CPU or system board. Please see the jumper settings on the follow- ing pages.

  • Page 20: Cyrix Cpus

    1-3On, 2-4On 1-2On 1-2On 3.3V* 1-2On 3-5On, 4-6On 2.8V 1-3On, 2-4On 3-4On 1-2On 3.52V 3-4On 3-5On, 4-6On 2.9V 1-3On, 2-4On 5-6On 1-2On 3.3V* 3-5On, 4-6On 3-4On For the G586IPV only 1-2On 3.52V 3-5On, 4-6On 3-4On 3-4On For the G586IPVF only...
  • Page 21 1-3On, 2-4On 1-2On 1-2On 3.3V* 1-2On 3-5On, 4-6On 2.8V 1-3On, 2-4On 3-4On 1-2On 3.52V 3-4On 3-5On, 4-6On 2.9V 1-3On, 2-4On 5-6On 1-2On 3.3V* 3-5On, 4-6On 3-4On For the G586IPV only 1-2On 3.52V 3-5On, 4-6On 3-4On 3-4On For the G586IPVF only...

  • Page 22: Installing Upgrade Cpus

    Installing Upgrade CPUs The G586IPV AND G586IPVF is equipped with a 321-pin Zero Insertion Force (ZIF) socket at location U25 of the system board. Refer to page 12 for the location of the ZIF socket. This socket is designed for easy removal of an old CPU and easy insertion of an upgrade CPU.
  • Page 23 To install an upgrade CPU, do the following. 1. Make sure the handle on the side of the ZIF socket is up. To raise the handle, push it down, slightly pull it out to the side, then raise it as far as it will go. It may be necessary to initially apply a small amount of sideways force to free the handle from its retaining “...

  • Page 24: Installing A Fan/Heatsink For Cyrix Cpus

    3. Position the CPU above the ZIF socket. Make sure pin 1 of the CPU is aligned with pin 1 of the socket. Lower the chip until the pins are inserted properly in their corresponding holes. Remember that very little force is needed to install the CPU. If the CPU is not easily inserted, verify whether or not pin 1 of the CPU is aligned with pin 1 of the socket.
  • Page 25 Clearnance Requirements Your CPU comes with a heatsink mounted on top. To maintain proper airflow once the upgrade is installed on the system board, the CPU and heatsink require certain space clearances. The clearance above the CPU's fan/heatsink must be at least 0.4 inches.

  • Page 26: Jumper Settings For Display Type

    2-3 On: Mono (default) Built-in Ports The G586IPV and G586IPVF system board is equipped with two serial ports, one parallel printer port, one FDD connector, two IDE hard disk shrouded headers and one PS/2 mouse connector. Refer to pages 12 and 13 for the locations of the built-in connectors and pin 1 of those connectors.

  • Page 27: Serial Ports

    The location of the G586IPVF built-in connectors Serial Ports The built-in serial ports are RS-232C asynchronous communication ports with 16C550A-compatible UARTs that can be used with modems, serial printers, remote display terminals, and other serial devices. They use the following system I/O addresses: Port Configuration COM2 COM3...

  • Page 28: Ps/2 Mouse Port

    The PS/2 mouse port is a 6-pin connector on the system board. Attach the 6-pin mouse port cable, which came with the G586IPV and G586IPVF, to connector J3 or CN3 (for the G586IPV only). Make sure the brown wire on the PS/2 mouse connector is aligned with pin 1 of connector J3 or CN3 (for the G586IPV only).

  • Page 29: Ide Hard Disk Interface

    IDE Hard Disk Interface The G586IPV and G586IPVF system board is equipped with two PCI IDE shrouded headers that will interface four Enhanced IDE (Integrated Drive Electronics) hard disk drives. Note: Only Enhanced IDE hard drives or ATAPI CD-ROMs can be connected to the IDE interface.
  • Page 30 In a few cases, drives from two different manufacturers will not function properly when used together. The problem lies in the hard drives, not the G586IPV and G586IPVF system board. Preparing an IDE Drive for Use IDE disk drives are already low-level formatted, with any bad-track er- rors entered, when shipped by the drive manufacturer.

  • Page 31: Installing Expansion Cards

    Installing Expansion Cards The G586IPV and G586IPVF system board is equipped with 4 dedi- cated PCI slots and 3 dedicated 16-bit ISA slots. All PCI slots are bus masters. Due to the size of the CPU with its accompanying heatsink/fan compo- nent, the length of the add-in cards in PCI slot 4 and ISA slot 1 is limited to 18cm (7.07",measured from the bracket of the card).

  • Page 32: Chapter 3: Software Installation

    Chapter 3 Software Installation After you power up your system, the BIOS message appears on your screen and the memory count begins. After the memory test, the following message will appear on the screen: Press DEL to enter setup If the message disappears before you respond, restart your system or press the “...

  • Page 33: Standard Cmos Setup

    ROM PCI/ISA BIOS (2A59GD49) CMOS SETUP UTILITY AWARD SOFTWARE, INC. STANDARD CMOS SETUP INTEGRATED PERIPHERALS SUPERVISOR PASSWORD BIOS FEATURES SETUP USER PASSWORD CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP IDE HDD AUTO DETECTION HDD LOW LEVEL FORMAT PNP/PCI CONFIGURATION SAVE & EXIT SETUP LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS EXIT WITHOUT SAVING...
  • Page 34 you can select Auto, User, one of 46 predefined drive specifications or None. Auto: This option indicates that the parameters for your hard disk drive(s) will be automatically detected and displayed when you boot your system. By default, the LBA mode is selected for a hard disk drive larger than 528 megabytes.

  • Page 35: Bios Features Setup

    No Errors: The system boot will not stop for any detected errors. All Errors: The system will stop whenever the BIOS detects a non-fatal error. All, But Keyboard: The system will stop for any error except a keyboard error. All, But Diskette: The system will stop for any error except a disk error. All, But Disk/Key: The system will stop for any error except a keyboard or disk error.

  • Page 36: Chipset Features Setup

    Chipset Features Setup The G586IPV AND G586IPVF uses the Intel 82430VX chipset. The Chipset Features Setup allows you to modify some functions to optimize system performance. If you press <Enter>, a screen similar to the one...

  • Page 37: Chipset Features Setup

    ROM PCI/ISA BIOS (2A59GD49) CHIPSET FEATURES SETUP AWARD SOFTWARE, INC. Auto Configration :Enabled DRAM Timing :60 ns DRAM RAS# Precharge Time DRAM R/W Leadoff Timing Fast RAS To CAS Delay DARM Read Burst (EDO/FP) :x222/x333 DRAM Write Burst Timing :x222 Fast MA to RAS# Delay CLK Fast EDO Path Select :Disabled...

  • Page 38: Pnp/Pci Configuration Setup

    PNP/PCI Configuration Setup Use the arrow keys to highlight “ PNP/PCI Configuration Setup” and press <Enter>; a screen similar to the one below will appear. ROM PCI/ISA BIOS (2A59GD49) PNP/PCI CONFIGURATION SETUP AWARD SOFTWARE, INC. Resources Control By :Auto PCI IRQ Active By Level PCI IDE IRQ Map To PCI-AUTO...

  • Page 39: Load Setup Defaults

    Load Setup Defaults The “ Load Setup Defaults” option loads optimized settings from the BIOS ROM. Use the Setup default values as standard values for your system Highlight this option on the main menu and press <Enter>. The mes- sage below will appear. Load Setup Defaults (Y/N)? N Type <Y>...

  • Page 40: User Password

    If you want to protect access to setup only, but not your system, set a supervisor’ s password with the “ Setup” option selected in the BIOS Features Setup. You will not be prompted for a password when you cold boot the system. Use the arrow keys to highlight the “...

  • Page 41: Ide Hdd Auto Detection

    Standard CMOS Setup. Hard Drive Mode The G586IPV AND G586IPVF supports three HDD modes: Normal, LBA and Large. If your hard disk drive does not support LBA mode, the “ LBA” option will not be displayed. If your HDD has 1024 or fewer cylin- ders, the “...
  • Page 42 Large Mode The Large mode is the extended HDD access mode supported by the G586IPV AND G586IPVF system board. Some IDE HDDs have more than 1024 cylinders without LBA support (in some cases, you may not want the LBA mode). This system board provides another alternative to support these kinds of HDDs.

  • Page 43: Hdd Low Level Detection

    The BIOS tells the operating system that the number of cylinders is half of the actual number and that the number of heads is double the actual number. During disk access, the reverse conversion is done by the INT13h routine. Example of Large mode: CYLS.

  • Page 44: Save & Exit Setup

    ROM PCI/ISA BIOS (2A59GD49) CMOS SETUP UTILITY AWARD SOFTWARE, INC. Hard Disk Low Level Format Utility No. CYLS HEAD SELECT DRIVE BAD TRACK LIST PERFORMAT Current select drive is : C DRIVE: C CYLINDER: 0 HEAD: 0 LANDZ SECTOR SIZE CYLS HEAD RECOMP...

  • Page 45: System Error Report

    Quit Without Saving (Y/N)? N Type “ Y” and press <Enter>. The system will reboot and you will once again see the initial diagnostics on the screen. If you wish to make any changes to the setup, press <Ctrl> <Alt> <Esc> simultaneously or <Del>...
  • Page 46 DISPLAY SWITCH IS SET INCORRECTLY The display switch on the system board can be set to either mono- chrome or color. This error indicates the switch is set to a different setting than indicated in Setup. Determine which setting is correct and either turn off the system and change the jumper or enter Setup and change the VIDEO selection.

  • Page 47: Ide Device Drivers

    Press and hold down the CTRL, ALT and DEL keys simultaneously. IDE Device Drivers To install the IDE device drivers supported by the G586IPV and G586IPVF system board, please refer to the “ Readme” file contained in the provided diskette.

  • Page 48: Chapter 4: Troubleshooting Checklist

    Chapter 4 Troubleshooting Checklist If you experience difficulty with the G586IPV and G586IPVF system board, please refer to the checklist below. If you still cannot identify the problem, please contact your dealer. 1. Check the jumper settings to ensure that the jumpers are properly set.

  • Page 49: Appendix A: Types Of Modules

    Appendix A Types of Modules The G586IPV and G586IPVF system board allows you to populate memory with 1MBx64 or 2MBx64 DIMM, and 1MBx32, 2MBx32, 4MBx32 and 8MBx32 SIMMs. The following modules have been tested with this board. Most untested brands will work but a few may fail to do...

  • Page 50: Appendix B: Memory And I/O Maps

    Appendix B Memory and I/O Maps Memory Address Map Address Name Function 0000000 to 640KB System System Board Memory 009FFFF Board RAM 00A0000 to 128KB Video Reserved for Graphics 00BFFFF Display Memory Display Memory 00C0000 to 160KB I/O Reserved for ROM on 00E7FFF Expansion ROM I/O Adapter Card...
  • Page 51 I/O Address Map I/O Address Function 0000-001F DMA Controller 1, 8237A-5 0020-003F Interrupt Controller 1, 8259A, Master 0040-005F Timer, 8254-2 0060-006F 8742 (Keyboard Controller) 0070-007F Real-time Clock, NMI (Non-maskable Interrupt) Mask 0080-009F DMA Page Memory, 74LS612 00A0-00BF Interrupt Controller 2, 8259A 00C0-00DF DMA Controller 2, 8237A-5 00E8...

  • Page 52: Appendix C: Pci I/O Pin Assignments

    Appendix C PCI I/O Pin Assignments Component Side Solder Side -12V - 01 - TRST# - 02 - +12V Ground - 03 - - 04 - - 05 - INTA# - 06 - INTB# - 07 - INTC# INTD# - 08 - PRSNT1# - 09 - Reserved...

  • Page 53: Appendix D: Isa I/O Pin Assignments

    Appendix D ISA I/O Pin Assignments -I/O Chck - 01 - Reset Drv - 02 - +5V DC - 03 - IRQ9 - 04 - -5V DC - 05 - DRQ2 - 06 - -12V DC - 07 - O W S - 08 - +12V DC - 09 -...

  • Page 54: Appendix E: Connector Pin Assignments

    Appendix E Connector Pin Assignments Connector J3, CN3(for the G586IPV only) PS/2 Mouse Connector Function Mouse Data Reserved Ground Mouse Clock Reserved J4 (COM1) and J5 (COM2) COM 1 and COM 2 Serial Ports Function DCD (Data Carrier Detect) RX (Receive Data)
  • Page 55 Function Functon Ground Ground Read Data Write Gate Ground Ground Head Select Track 0 Ground MSEN Disk Change Wr Protect Connector J7 Parallel Printer Port Function Function -Strobe -Autofd Data 0 -Error Data 1 -Init Data 2 -Slctin Data 3 Ground Data 4 Ground...
  • Page 56 Function Function HCS0 IOCS16 HCS1 Reserved Ground Connector J10 Fan Connector Function Ground +12V Ground Connector J11 Power LED/Keylock Connector Function IRTX G N D IRRX Reserve Connector J13 Infrared Connector Function Signal Connector J14 Green LED Connector Function Signal...
  • Page 57 Connector J15 Green Button Connector Function Ground Signal Connector J16 Reset Switch Connector Function Ground Reset Connector J17 Speaker Connector Function Signal Reserved G N D Connector J18 Power LED/Keylock Connector Function LED Signal Reserved Ground Keylock Signal Ground...
  • Page 58 Connector CN1 PS/2 Keyboard Connector Function Keyboard Data Reserved Ground Keyboard Clock Reserved Connector CN2 AT Keyboard Connector Function Keyboard Clock Keyboard Data Reserved Ground Connector PL1 Power Connector Function Power Good +12V -12V Ground Ground Ground Ground...
  • Page 59 Connector SSM1 Cache Module Slot Function Function Ground TIO0 Ground TIO2 TIO6 TIO4 RSVD VCC3 VCC3 TWE# CADS#/CAA3 Ground Ground HBE4# HBE6# HBE0# HBE2# VCC3 VCC3 CCS#/CAB4 GWE# Ground BWE# Ground VCC3 VCC3 Ground Ground VCC3 ADSP# ECS1#/(CS#) ECS2# Ground Ground Ground TIO1...
  • Page 60 Function Function HBE7# HBE1# Ground VCC5 HBE3# CAB3 CALE VCC5 Ground RSVD Ground VCC5 VCC5 Ground Ground RSVD VCC5 Ground CLK0 Ground Ground VCC5 VCC5 Ground Ground...

  • Page 61: Appendix F: Row Address Of The Dram Nad Sdram

    Appendix F Row Address Strobe of the DRAM and SDRAM After you power up your system, the BIOS message appears on your screen and the memory count begins. After the memory test, the screen will appear as below: Award Software, Inc. System Configurations CPU Type :6x86-P166+...
