G586IPBS
Rev . 0+
System Board
User' s Manual
- D29251020 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G586IPBS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DFI G586IPBS

Summary of Contents for DFI G586IPBS

  • Page 1 G586IPBS Rev . 0+ System Board User’ s Manual - D29251020 -...
  • Page 2 The information in this document is subject to change without notice. DFI, Inc. reserves the right to make revisions to this publication and to make changes to any and/or all parts of its content, at any time, without obligation to notify any person or entity of such changes.
  • Page 3 v FCC Statement on Class B his equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential installation.

  • Page 4: Table Of Contents

    v Table of Contents v Introduction ................Features and Specifications ......... Package Checklist ............Installation Overview ............... Preparing the Area .............. Handling the System Board ..........Tips in Handling the System Board ......Hardware Installation ............Memory Installation ............Installing the Modules ..........Board Configuration ............

  • Page 5: Introduction

    SPP/EPP/ECP parallel port, a floppy disk drive controller, one PS/2 mouse port and one PS/2 or AT keyboard connector. The G586IPBS can support 8MB to 128MB of memory using 1Mx36, 2Mx36, 4Mx36 and 8Mx36 72-pin SIM modules.

  • Page 6: Features And Specifications

    G586IPBS Features and Specifications Processor • Intel Pentium 75/90/100/120/133/150MHz • Future Pentium OverDrive Processor System Design • Intel Triton chipset • Four 72-pin SIMM sockets • 8MB to 128MB onboard memory • Uses EDO or fast page mode x32 DRAM, 60 or 70ns, •...
  • Page 7 G586IPBS Integrated I/O • Super I/O controller: - Winbond W83787F, - Winbond W83877F, - SMC FDC37C665GT or - SMC FDC37C669GT • Two NS 16C550-compatible high speed UARTs • One SPP/EPP/ECP parallel port • One 720KB/1.2MB/1.44MB floppy controller (Winbond W83787F only) or One 720KB/1.2MB/1.44MB/2.88MB floppy controller...
  • Page 8 G586IPBS Expansion Slots • Four PCI slots (all bus masters) • Three ISA slots (one shared with PCI slot) CPU Socket • VRM (Voltage Regulation Module) header allows upgrade to future low-voltage CPUs • 321-pin ZIF socket (Intel Socket 7) •...

  • Page 9: Package Checklist

    G586IPBS Package Checklist The G586IPBS package contains the following items: • The G586IPBS system board • The G586IPBS user’ s manual • One set of IDE driver diskettes • One 34-pin floppy disk drive cable • Two 40-pin IDE hard disk cables •...

  • Page 10: Installation Overview

    G586IPBS v Installation Overview This chapter summarizes the steps in installing the G586IPBS system board into your system unit. It also includes a description of the area in which you must work and directions for memory installation. Before installing the system board, obtain the memory you plan to install.

  • Page 11: Handling The System Board

    G586IPBS Handling the System Board It is quite easy to inadvertently damage your system board even before installing it to your system unit. Static electrical discharge can damage computer components without causing any signs of physical damage. You must take extra care in handling the system board to ensure against electrostatic build-up.

  • Page 12: Hardware Installation

    G586IPBS Hardware Installation Memory Installation The G586IPBS system board can support 8MB to 128MB of memory using 72-pin SIMMs (Single In-line Memory Mod- ule). The SIM sockets are divided into two banks on the system board. Each bank consists of 2 SIMM sockets. The G586IPBS system board uses 1Mx36, 2Mx36, 4Mx36 and 8Mx36 SIMMs.
  • Page 13 G586IPBS Bank 0 Bank 1 Memory Size 1Mx36 1Mx36 — — — — 1Mx36 1Mx36 16MB 1Mx36 1Mx36 1Mx36 1Mx36 24MB 1Mx36 1Mx36 2Mx36 2Mx36 40MB 1Mx36 1Mx36 4Mx36 4Mx36 72MB 1Mx36 1Mx36 8Mx36 8Mx36 16MB 2Mx36 2Mx36 — —...
  • Page 14 G586IPBS Pin 1 of the SIMM socket Locations of the SIM Sockets on the System Board...

  • Page 15: Installing The Modules

    G586IPBS Installing the Modules A SIM module simply snaps into a socket on the system board. Pin 1 of the SIM module must correspond with Pin 1 of the socket. 1. Position the SIMM above the socket with the “notch” in the module aligned with the “key”...

  • Page 16: Board Configuration

    G586IPBS Board Configuration Locations of Jumpers and Connectors on the System Board...

  • Page 17: Jumper Settings For Display Type And Cmos Clean

    G586IPBS Jumper Settings Jumper Settings for Display Type and CMOS Clean Locations of Jumpers JP2 and JP3 on the System Board...
  • Page 18 G586IPBS Jumper JP2 Password Clear If you set a password in the “Password Setting” option and forget your password, power off your system and set Jumper JP2 to On to clear the password stored in your CMOS. Now power on your system. After your system has detected the floppy or hard drive, turn it off again and set JP2 to Off.

  • Page 19: Jumper Settings For Super I/O Setting And Irq Select

    G586IPBS Jumper Settings for Super I/O Setting and IRQ Select Locations of Jumpers JP51 and JP52 on the System Board...
  • Page 20 G586IPBS Note: Jumpers JP51 and JP52 are available only on the G586IPBS system board that supports Winbond W83787F or SMC FD37C665GT super I/O controller. Jumper JP51 ECP DRQ/DACK Select The G586IPBS system board supports an ECP parallel port that allows you to use DMA Request (DRQ) Channel 1 or 3 and DMA Acknowledge (DACK) Channel 1 or 3.

  • Page 21: Cache Configuration

    G586IPBS Cache Configuration The G586IPBS system board supports 3.3V pipeline burst or asynchronous cache SRAM installed in the 160-pin cache module slot. The board can be configured to the following cache sizes: 256KB and 512KB. Installing the Cache Module Cache Module Slot 1.
  • Page 22 G586IPBS 2. Once the cache module has been installed, make sure the “External Cache” option in the “BIOS Features Setup” menu of the Award BIOS CMOS Setup Utility is set to “Enabled”. Note: With the cache module installed in the cache module slot, the...

  • Page 23: Vrm Header

    G586IPBS VRM Header Your G586IPBS system board is equipped with a VRM (Voltage Regulation Module) header shown below. It allows you to upgrade to future low-voltage CPUs by installing a Voltage Regulation Module. VRM Header and 3.3V Pentium Processor A DVRM (Dummy Voltage Regulation Module) must be installed if you are using a 3.3V Pentium processor.
  • Page 24 G586IPBS To Remove: Press the handles on the header simultaneously. The module will be forced out of the VRM header.

  • Page 25: Vrm Header And Future Low-Voltage Cpus

    G586IPBS VRM Header and Future Low-Voltage CPUs The types of VRM supported and installation procedures will be described in a future edition of the G586IPBS manual.

  • Page 26: Cpu Installation

    G586IPBS CPU Installation The G586IPBS is equipped with a 321-pin Zero Insertion Force (ZIF) socket at location U31 of the system board. The ZIF socket allows for easy installation of upgrade CPUs as your system needs grow. Make sure all jumpers are set correctly before applying power, or you may damage the CPU or system board.

  • Page 27: Jumper Settings For Cpu

    G586IPBS Jumper Settings for CPU Locations of Jumpers JP5, JP6 and JP15 on the System Board...
  • Page 28 G586IPBS 3.3V Pentium Processor (75MHz) System (External) Bus Speed: 50MHz Pin 1 3.3V Pentium Processor JP15...
  • Page 29 G586IPBS 3.3V Pentium Processor (90MHz) * System (External) Bus Speed: 60MHz Pin 1 3.3V Pentium Processor JP15 * Default Setting...
  • Page 30 G586IPBS 3.3V Pentium Processor (100MHz) System (External) Bus Speed: 66MHz Pin 1 3.3V Pentium Processor JP15...
  • Page 31 G586IPBS 3.3V Pentium Processor (100MHz) System (External) Bus Speed: 50MHz Pin 1 3.3V Pentium Processor JP15...
  • Page 32 G586IPBS 3.3V Pentium Processor (120MHz) System (External) Bus Speed: 60MHz Pin 1 3.3V Pentium Processor JP15...
  • Page 33 G586IPBS 3.3V Pentium Processor (133MHz) System (External) Bus Speed: 66MHz Pin 1 3.3V Pentium Processor JP15...
  • Page 34 G586IPBS 3.3V Pentium Processor (150MHz) System (External) Bus Speed: 50MHz Pin 1 3.3V Pentium Processor JP15...
  • Page 35 G586IPBS 3.3V Pentium Processor (150MHz) System (External) Bus Speed: 60MHz Pin 1 3.3V Pentium Processor JP15...

  • Page 36: Jumpers Jp11 And Jp50

    G586IPBS Jumpers J1, JP11 and J50 The following jumpers are for factory testing only and should always be set to their default configurations. Reconfiguring these jumpers will cause problems with your system board. J1, JP11, J50: Off...

  • Page 37: Installing Upgrade Cpus

    G586IPBS Installing Upgrade CPUs The G586IPBS is equipped with a 321-pin Zero Insertion Force (ZIF) socket at location U31 of the system board. This socket is designed for easy removal of the old CPU and easy insertion of the upgrade CPU. The socket allows you to carefully place the new CPU into its position.
  • Page 38 G586IPBS Zero Insertion Force (ZIF) Socket To install an upgrade CPU, do the following. 1. Make sure the handle on the side of the ZIF socket is up. To raise the handle, push down, pull it out to the side a little and raise it as far as it will go.
  • Page 39 G586IPBS Lifting the Handle 2. Once the lever is completely up, remove the old CPU by carefully lifting it straight out of the socket. You are now ready to insert the new CPU.
  • Page 40 G586IPBS 3. Position the CPU above the ZIF socket. Make sure pin 1 of the CPU is aligned with pin 1 of the socket. Lower the chip until the pins are inserted properly in their corresponding holes. Remember that very little force is needed to install the CPU.
  • Page 41 G586IPBS Clearance Requirements The 3.3V Pentium Upgrade Processor comes with a heat sink mounted on top. To maintain proper airflow once the upgrade is installed on the system board, the processor and sink require certain space clearances. The clearance above 3.3V Pentium Upgrade Processor's fan/ heat-sink must be at least 0.4 in.
  • Page 42 G586IPBS Built-in Ports The G586IPBS system board is equipped with two serial ports, one SPP/EPP/ECP parallel printer port, one FDD connector, one PS/2 mouse connector and two IDE hard disk shrouded headers. Locations of the Built-in Ports on the System Board...

  • Page 43: Serial Ports

    G586IPBS Serial Ports The built-in serial ports are RS-232C asynchronous commu- nication ports with 16C550-compatible UARTs that can be used with modems, serial printers, remote display terminals, and other serial devices. They use the following system I/O addresses: Port Configuration...
  • Page 44 G586IPBS...
