The VESA-mount option is used to install the monitor on an articulated arm using an optional bracket. For
a list of available mounts, please contact your Vartech salesperson.
Mounting Guidelines
Observe these guidelines when installing the monitor on an arm.
The mounting surface and the mounting arm must be strong enough to support both the monitor and the
mounting hardware.
The interface between the arm and the monitor must meet VESA FPMPMI 100 mm standards.
The mounting location must provide adequate clearance for positioning and moving the adjustable unit and
routing cables.
Mount the Monitor on a VESA Interface
Follow these steps to mount the monitor on a VESA interface.
1. Mount the arm to the VESA interface with screws, bolts, or clamps so the monitor cannot tip.
2. Align the monitor over the arm and insert four supplied screws through the arm bracket and into the monitor.
RAM Mounting Guidelines
RAM is the only universal ball-and-socket system that holds excessive amounts of weight in high vibration
applications for military, commercial and private use.
Mounting Guidelines
Observe these guidelines when installing the monitor on the provided RAM.
The mounting surface must be strong enough to support both the monitor and the RAM.
The mounting location must provide adequate clearance for positioning and moving the adjustable unit and
routing cables.
Follow these steps to mount the monitor on a RAM.
1. Mount the Base plate to the mounting surface where the monitor is intended to be permanently mounted
2. Mount the Shaft to the RAM interface by prying open the socket and slipping over the mounting ball.
3. Align the RAM monitor plate, attach using the supplied screws into the 3 RAM mounting holes (triangular
pattern)
4. Loosen the socket and slip the ball into the socket. Secure in place by tightening the socket.
Mechanical Drawings
Model
VT121XA4/XB4
VT121XA4/XB4
2.5 Input Video Connections
VT121 All Weather User's Guide 150-183
Description
VESA/RAM Mount Drawing
Flush Mount
Page(s)
19
20
5
