LOCATION DESCRIPTION

15
18 19
1. Direct dial memory buttons (MI,M2,M3)
2. Ringer light indication
3. Caller Display List&Scroll Up/Down buttons
4. New Calls LED
5. SET/STO(Store) button
6. Delete button
7. Memory button
8. OUT/R(Recall) button
9. Mute button
10. (Redial)/P(Pause) button
13
16
to Modular Wall jack
11. Speakerphone LED
12. Speakerphone button
13. Handset volume adjust switch
14. LCD Screen
15. Coiled cord jack in base
16. Coiled cord jack in handset
17. SPEAKERPHONE volume switch
18. Ringer HI/LOW switch
19. Line jack
15
ENGLISH
14
1
2
3
4
5
6
7
8
9
10
11
12
17
